Tomcat i7230W
S5162
Version 1.0
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN, Tomcat i7230W are trademarks of TYAN Computer Corporation.
Intel, Prescott, and combinations thereof are trademarks of Intel Corporation.
Phoenix, Phoenix-AwardBIOS are trademarks of Phoenix Technologies.
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE,is a trademark of SuSE AG.
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Notice
Information contained in this document is furnished by TYAN Computer
Corporation and has been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN products including liability or
warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications
at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
1
http://www.tyan.com
Advertisement
Table of Contents
Related Manuals for TYAN TOMCAT I7230W
Summary of Contents for TYAN TOMCAT I7230W
- Page 1 In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
BIOS Main Menu…………………………………………………………. 34 Advanced Menu………………………………………………………….. Security Menu…………………………………………………………….. 60 Power Menu………………………………………………………………. 61 Boot Menu………………………………………………………………… 63 Exit Menu…………………………………………………………………. Chapter 4: Diagnostics Beep Codes………………………………………………………………. Flash Utility……………………………………………………………….. BIOS Post Code………………………………………………………….. 66 Appendix I: SMDC Information Appendix II: How to Make a Driver Diskette Glossary http://www.tyan.com... -
Page 3: Check The Box Contents
1 x USB2.0 cable 1 x S5162 user’s manual 1 x S5162Quick Reference guide 1 x TYAN driver CD 1 x I/O shield 1 x Serial & Parallel Port cable set If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. -
Page 4: Chapter 1: Introduction
ATA ports. This motherboard represents the best choice for a server platform product. Remember to visit TYAN’s Website at http://www.TYAN.com. There you can find information on all of TYAN’s products with FAQs, online manuals and BIOS upgrades. 1.2 - Hardware Specifications... - Page 5 Two USB 2.0 ports (via cable) One COM port (via cable) Regulatory Tyan 2x9 front-panel pin header FCC Class B (DoC) Tyan 2x6 front-panel pin header for European Community CE (DoC) LAN LED and ID LED/Switch BSMI 2x25 connector for optional Tyan IPMI SMDC *8GB not validated at time of print.
-
Page 6: Software Specifications
SUSE LINUX Enterprise Server 9.0 SP2 (32-bit & 64-bit) SUSE LINUX Professional 9.3 (32-bit & 64-bit) RHEL3 Update 5 (32-bit & 64-bit) RHEL4 Update 1 (32-bit & 64-bit) TYAN reserves the right to add support or discontinue support for any OS with or without notice. http://www.tyan.com... -
Page 7: Chapter 2: Board Installation
Chapter 2: Board Installation You are now ready to install your motherboard. The mounting hole pattern of the Tomcat i7230W S5162 matches the ATX specification. Before continuing with installation, confirm that your chassis supports an ATX motherboard. How to install our products right… the first time The first thing you should do is reading this user’s manual. -
Page 8: Board Image
2.1- Board Image This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above picture. http://www.tyan.com... -
Page 9: Block Diagram
2.2 - Block Diagram Tomcat i7230W S5162 http://www.tyan.com... -
Page 10: Board Parts, Jumpers And Connectors
This diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above diagram. Jumper Legend OPEN - Jumper OFF, without jumper cover CLOSED – Jumper ON, with jumper cover http://www.tyan.com... - Page 11 82573E NVM (Non-Volatile Memory) Protection JP36 Select 82573V NVM (Non-Volatile Memory) Protection JP38 Select JP40 PXH Channel B speed setting JP41 PXH Channel A PCI BUS speed setting JP42 PXH Channel B PCI BUS speed setting JP43 Onboard VGA controller Enable/Disable select http://www.tyan.com...
- Page 12 JP43 JP30 JP25 JP24 JP16 http://www.tyan.com...
- Page 13 Power on system JP24/JP25: SM BUS Select 1-2: Connect LAN SM BUS to mother board SM BUS 2-3: Connect LAN SM BUS to SMDC SM BUS JP43 Onboard VGA controller Enable/Disable select 1-2: Enable by HW 2-3: Enable/Disable by BIOS http://www.tyan.com...
- Page 14 JP38 JP36 JP35 JP35 82573E SPI Shared Select 1-2 Off: Not shared SPI 1-2 On: shared SPI JP36 82573E SPI Shared Select http://www.tyan.com...
- Page 15 1-2 Off: Protection Enable 1-2 On: Protection Disable JP38: 82573V NVM(Non-Volatile Memory) Protection Select 1-2 Off: Protection Enable 1-2 On: Protection Disable http://www.tyan.com...
- Page 16 JP40 JP14 JP42 JP41 http://www.tyan.com...
- Page 17 1-2: Enable 133MHz 2-3: Disable 133MHz JP41: PXH Channel A PCI BUS speed setting 1-2: Selected by plug-in card 2-3: set to 33MHz JP42: PXH Channel B PCI BUS speed setting 1-2: Selected by plug-in card 2-3: set to 33MHz http://www.tyan.com...
- Page 18 Use these headers to connect the chassis cooling fans to your motherboard to keep the system stable and reliable. S peed Con trol Tacho mete r These connectors support the tachometer Speed Control monitoring and auto fan speed control. http://www.tyan.com...
- Page 19 Connects to the Serial ATA ready drives via the Serial ATA cable J20: SATA1 J21: SATA3 J22: SATA2 J23: SATA4 You can use any of the four Serial ATA ports for RAID 0, 1, 5, and 10 from the onboard ICH7R chipset http://www.tyan.com...
-
Page 20: Tips On Installing Motherboard In Chassis
Some chassis’ include plastic studs instead of metal. Although the plastic studs are usable, TYAN recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. -
Page 21: Installing The Processor & Cooling Fan
2.5 - Installing the Processor & Cooling Fan Your Tomcat i7230W S5162 supports the latest processor technologies from Intel. Check the TYAN website for latest processor support: http://www.tyan.com Processor Installation The processor should be installed carefully. Make sure you are wearing an antistatic strap and handle the processor as little as possible. - Page 22 Align the heatsink with the four holes around the processor socket. Press the heatsink down until the four screws are securely seated in the holes. Use screw drive to secure the four screws. http://www.tyan.com...
- Page 23 Turn the motherboard the right way up, holding the bracket in place. Place the heat sink assembly on top of the processor. It should match up with the mounting holes on the rear bracket. http://www.tyan.com...
- Page 24 Screw the heat sink assembly into place. If there is a fan on the heat sink you will need to connect the power lead for the fan to one of the fan power supply pin headers on the motherboard. http://www.tyan.com...
-
Page 25: Installing The Memory
• All installed memory will automatically be detected and no jumpers or settings need changing. • The Tomcat i7230W S5162 supports up to 8GB of memory. Notes Standard DDR memory modules are not supported. Registered Memory Module is NOT supported. - Page 26 Memory Installation Procedure Follow these instructions to install memory modules into the Tomcat i7230W S5162. Press the locking levers in the direction shown in the following illustration. Align the memory module with the socket. The memory module is keyed to fit only one way in the socket.
-
Page 27: Attaching Drive Cables
Attaching Serial ATA Cables The Tomcat i7230W is also equipped with 4 Serial ATA (SATA) channels. Connections for these drives are also very simple. There is no need to set Master/Slave jumpers on SATA drives. - Page 28 Tyan has supplied two SATA cables and one SATA power adapter. If you are in need of other cables or power adapters please contact your place of purchase. The following pictures illustrate how to connect an SATA drive 1.SATA drive cable connection 2.
-
Page 29: Connecting External Devices
The chart below illustrates the different LED states. 10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED Link Green 10 Mbps Active Blinking Green Link Green Green 100 Mbps Active Blinking Green Green Link Green Orange 1000 Mbps Active Blinking Green Orange No Link http://www.tyan.com... -
Page 30: Installing The Power Supply
2.9 - Installing the Power Supply There are two power connectors on your Tomcat i7230W S5162. The Tomcat i7230W S5162 requires that you use an EPS12V power supply that has a 24- pin and an 8-pin power connector. Please be aware that ATX 2.x, ATX12V and ATXGES power supplies are not compatible with the motherboard and can damage. -
Page 31: Finishing Up
In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com... - Page 32 NOTE http://www.tyan.com...
-
Page 33: Chapter 3: Bios Setup
Changes settings. 3.1.2 Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [F1] key again. http://www.tyan.com... -
Page 34: Bios Main Menu
Chipset section unless you are absolutely sure of what you are doing. The Chipset defaults have been carefully chosen either by TYAN or your system manufacturer for best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable. - Page 35 Press Enter on any of the Primary/Master, Primary/Slave options to view advanced details of the corresponding drive. The system displays advanced details like the number of heads/cylinders/sectors on the detected disk and the maximum storage capacity of the disk. http://www.tyan.com...
- Page 36 Ultra DMA uses Cyclical Redundancy Checking (CRC), offering a new level of data protection. Disabled / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4 / Mode 5 http://www.tyan.com...
- Page 37 3.2.2 SATA Port 1/2/3/4 Press Enter on any of the Primary/Master, Primary/Slave options to view advanced details of the corresponding drive. http://www.tyan.com...
- Page 38 BIOS ROM at C0000h-C7FFFh via the L2 cache. This greatly speeds up accesses to the video BIOS. However, this does not necessarily make the system perform better because the OS bypasses the BIOS and uses the graphics driver to access the video card's hardware directly. http://www.tyan.com...
- Page 39 USMC Caching / Disabled / Write Through / Write Protect / Write Back Cahe C8000-CBFF/Cache CC00-CFFF/Cahe D000-D3FF/Cahe D400- D7FF/Cache D800-D8FF/Cahe DC00-DFFF These feature allows you to control caching of C8000-CBFF/CC00-CFFF/D000- D3FF/D400-D7FF/D800-D8FF/DC00-DFFF memory. Disabled / Write Through / Write Protect / Write Back http://www.tyan.com...
- Page 40 (POST). The summary screen lists many of the system setup settings. When this option is set to Disabled, the summary screen does not appear. Enabled / Disabled Boot-time Diagnostic Screen This feature is used to display the diagnostic screen during the boot process. Enabled / Disabled http://www.tyan.com...
- Page 41 Quick Boot's abbreviated testing scheme. After a few error-free test runs, you should enable this feature for much faster booting. Enabled / Disabled Error Halt in POST Select Disabled if user don't want stop POST with any error. Enabled / Disabled http://www.tyan.com...
-
Page 42: Advanced Menu
This is where the Reset Configuration Data BIOS feature comes in. This BIOS feature allows you to manually force the BIOS to clear the previously saved ESCD data and reconfigure the settings. All you need to do is enable this http://www.tyan.com... - Page 43 When enabled, the BIOS takes control of the USB ports. Enable this only if you run an OS that does not support USB (e.g. DOS) or when you have USB hardware like USB mice that you want to use even before the operating system loads. Enabled / Disabled http://www.tyan.com...
- Page 44 This feature is used to configure the function of clock spread spectrum. Enabled / Disabled ECC Condition This feature is used to select ECC Error condition to be detected. Multiple bit / None / Single bit / Both ECC Error Handler http://www.tyan.com...
- Page 45 Native IDE mode. Compatible / Enhanced (non-AHCI) SATA RAID Enable This feature is used to enable SATA RAID functionality. Disabled / Enabled SATA AHCI Enable This feature is used to enable SATA AHCI functionality. Disabled / Enabled http://www.tyan.com...
- Page 46 Enable or Disable these 3 USB Functions by setting item to the desired value. Enabled / Disabled USB Device 29, Function 0 & 1 & 2 & 3: Enable or Disable these 4 USB Functions by setting item to the desired value. Enabled / Disabled http://www.tyan.com...
- Page 47 USB Device 29, Function 7: Control USB 2.0 functionality through this Setup Item. Enabled / Disabled 3.3.1.2 PCI Express Sub-Menu These items are for debugging the PCI Express Ports. http://www.tyan.com...
- Page 48 3.3.1.2.1 Slot 1 (x8 Port) Sub-Menu These items are for PCI Express MCH Dev1 port control options. PCI Express MCH Dev 1 This feature is used to enable PCI Express MCH Dev1 port control. Enabled / Disabled http://www.tyan.com...
- Page 49 3.3.1.2.2 Integrated PXH Sub-Menu These items are for PCI Express Root Port #1 control options. PCI Express Port #1 This feature is used to enable PCI Express Port #1 control. Auto / Enabled / Disabled http://www.tyan.com...
- Page 50 These items are for Integrated LAN1/LAN2 control option. Integrated LAN Control This feature is used to enable Integrated LAN control. Auto / Enabled / Disabled Option ROM Scan This feature is used to enable the functionality of option ROM scanl. Disabled / Enabled http://www.tyan.com...
- Page 51 By allowing the processor to use on-die resources that would otherwise have been idle, Hyper- Threading Technology provides a performance boost on multi-threading and multi-tasking operations for the Intel NetBurst® microarchitecture. Enabled / Disabled http://www.tyan.com...
- Page 52 This feature is used to enable the function of No Execute Mode Mem Protection. Enabled / Disabled Frequency Ratio This feature is used to set the Frequency Ratio Default / X 8 / 19 /14 /15 / 16 / 17 / 18 http://www.tyan.com...
- Page 53 This defines how the parallel port is detected and configured. Disabled / Enabled Mode This field allows the user to select the parallel port mode. The default value is Standard that automatically selects the correct mode to use. The other modes are explained as follows: http://www.tyan.com...
- Page 54 ECP mode. DMA 1 / DMA 3 Floppy Disk Controller This defines how the floppy disk controller is detected and configured. Enabled / Disabled http://www.tyan.com...
- Page 55 3.3.4 Hardware Monitor http://www.tyan.com...
- Page 56 3.3.4.1 Voltage Monitoring http://www.tyan.com...
- Page 57 This feature is used to set function of Auto Mode Fan Control. Disabled / Enabled J22/J31/J23/J8&J17 Number of Pins Select These features are used to select 3 or 4 pin fan connector. After the setting, then you can use the function of “Auto Fan Control”. 4 Pin / 3 Pin http://www.tyan.com...
- Page 58 Select Enabled to allow logging of DMI events Disabled / Enabled ECC Event Logging Select Enabled to allow logging of ECC events Disabled / Enabled Clear all DMI event logs Setting this to ‘Yes’ will clear the DMI event log after rebooting. No / Yes http://www.tyan.com...
- Page 59 This feature is used to enable the flow control. None / XON/XOFF / CTS/RTS Console Connection This feature is used to indicate whether the console is connected directly to the system or a modem is used to connect. Direct / Via modem http://www.tyan.com...
-
Page 60: Security Menu
This option allows the user to control access to diskette drives. Supervisor / Disabled Fixed disk boot sector This option allows the user to write protect boot sector on hard disk to protect against viruses. Normal / Write Protect http://www.tyan.com... -
Page 61: Power Menu
Disabled / Enabled FirstWare Authentication Level This feature is used to select FirstWare Authentication Level. High / Medium / Low 3.5 Power Menu These settings allow you to configure the power options for your system. http://www.tyan.com... - Page 62 BIOS will record the event. Disabled / Enabled S5 Wake-Up by PCI Card If enabled, this option awakens the system from the S5 (power-off) state with an input signal from PME on the PCI card, Enabled / Disabled http://www.tyan.com...
-
Page 63: Boot Menu
3.6 Boot Menu Use this screen to select options for the Boot Settings Configuration. http://www.tyan.com... -
Page 64: Exit Menu
Exit Discarding Changes This exits BIOS setup after discarding the changes made. Load Setup Defaults Loads the factory default values. Discard Changes Discards all changes made without exiting BIOS setup. Save Changes Saves all changes made without exit BIOS. http://www.tyan.com... -
Page 65: Chapter 4: Diagnostics
The most common type of error is a memory error. Before contacting your vendor or TYAN Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution. -
Page 66: Bios Post Code
Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. 16h: Initial onboard clock generator if Early_Init_Onboard_Generator is defined. See also POST 26h. 18h: Detect CPU information including brand, SMI type (Cyrix or Intel) and CPU level (586 or 686). http://www.tyan.com... - Page 67 Test DMA Channel 0. 37h: Test DMA Channel 1. 39h: Test DMA page registers. 3Ch: Test 8254 3Eh: Test 8259 interrupt mask bits for channel 1. 40h: Test 8259 interrupt mask bits for channel 2. 43h: Test 8259 functionality. http://www.tyan.com...
- Page 68 6Fh: 1. Initialize floppy controller 2. Set up floppy related fields in 40:hardware. 75h: Detect & install all IDE devices: HDD, LS120, ZIP, CDROM….. 76h: (Optional Feature) Enter AWDFLASH.EXE if: -AWDFLASH.EXE is found in floppy drive. -ALT+F2 is pressed. http://www.tyan.com...
- Page 69 Program P6 class write combining 95h: Update keyboard LED & typematic rate 96h: Build MP table Build & update ESCD Set CMOS century to 20h or 19h Load CMOS time into DOS timer tick Build MSIRQ routing table FFh: Boot attempt (INT 19h) http://www.tyan.com...
- Page 70 NOTE http://www.tyan.com...
-
Page 71: Appendix I: Smdc Information
Tyan SMDC is not a peripheral card. Unlike regular peripheral card such as AGP card, Network card or SCSI card, SMDC does not require any hardware specific driver. As long as a standby power comes into the system, SMDC will begin looking after the system. -
Page 72: Features Of Tyan Server Management
Features of Tyan Server Management Monitor various system components remotely - such as fans, processor temperature, and more Remote power on and power off Console redirect -the ability to view system remotely Alert and error actions -such as audible beep, e-mail, power down and reboot... -
Page 73: Appendix Ii: How To Make A Driver Diskette
CD. You will see the following menu. Then press [1] and [Enter] to boot the system to Tyan diskette maker. (If you would like to boot from hard disk, press 0 and Enter or just wait for 10 seconds to boot automatically from hard disk.). - Page 74 Follow the instruction on menu to insert a diskette and press [ENTER]. Please insert a formatted diskette into A:/ and press [ENTER] Writing image to drive A: Track: 36 Hoad: 8 Sector: 1 Using "ESC" key to quit the Tyan diskette maker. The system will automatically restart. http://www.tyan.com...
- Page 75 --- there is also the possibility of losing your data should the system crash. Information stored in a buffer is temporarily stored, not permanently saved. http://www.tyan.com...
- Page 76 DMA (Direct Memory Access): channels that are similar to IRQs. DMA channels allow hardware devices (like soundcards or keyboards) to access the main memory without involving the CPU. This frees up CPU resources for other http://www.tyan.com...
- Page 77 Form factor: an industry term for the size, shape, power supply type, and external connector type of the Personal Computer Board (PCB) or motherboard. The standard form factors are the AT and ATX, although TYAN also makes some Baby-AT and ATX Footprint boards.
- Page 78 PCI (Peripheral Component Interconnect): a 32 or 64-bit local bus (data pathway) which is faster than the ISA bus. Local buses are those which operate within a single system (as opposed to a network bus, which connects multiple systems). http://www.tyan.com...
- Page 79 0+1 is both striping and mirroring, providing fault-tolerance, striping, and faster access all at the same time. RAIDIOS: stands for RAID I/O Steering, a type of RAID technology from Intel. RAIDIOS is a specification used to enable an embedded I/O controller, http://www.tyan.com...
- Page 80 SRAM (Static RAM): unlike DRAM, this type of RAM does not need to be refreshed in order to prevent data loss. Thus, it is faster and more expensive. SSI (Server System Infrastructure): an industry initiative intended to provide ready-to-use design specifications for common server hardware elements http://www.tyan.com...
- Page 81 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shift the processor over and down, guiding into the board and locking it into place. http://www.tyan.com...
-
Page 82: Technical Support
(which can have expensive consequences). If these options are not available for you then Tyan Computer Corporation can help. Besides designing innovative and quality products for over a decade, Tyan has continuously offered customers service beyond their expectations. - Page 83 Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you...
- Page 84 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1702-100 http://www.tyan.com...
