OmniAccess 740
Hardware Users Guide
1
2
Release 2.2
Notes on numbered items on banner & legal pages
1
26801 West Agoura Road
Calabasas, CA 91301
(818) 880-3500
FAX (818) 880-3505
support@ind.alcatel.com
Beta
US Customer Support—(800) 995-2696
International Customer Support—(818) 878-4507
Internet—service.esd.alcatel-lucent.com
Website: www.alcatel-lucent.com
Part No: 032288-00, Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNIACCESS 740 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel-Lucent OMNIACCESS 740

Summary of Contents for Alcatel-Lucent OMNIACCESS 740

  • Page 1 Do not import other template elements such as page layout. To return to the draft version, import color def’ns from draft-colors.fm. To switch to the beta version, import color def’ns from beta-colors.fm OmniAccess 740 Hardware Users Guide Release 2.2 Notes on numbered items on banner & legal pages...
  • Page 2 The following information is for the Users of the OmniAccess 740: If it is not installed in accordance with the installation instructions, it may not function exactly to the said specifications. Modifying the equipment without Alcatel-Lucent's written authorization may result in the equipment no longer complying with the said dimensions.

  • Page 3: Table Of Contents

    Document Organization ... 2 Document Conventions...2 Obtaining Documentation... 3 Reference Publications ...3 Obtaining Technical Assistance Documentation Feedback ... 3 2 OmniAccess 740 Overview Introduction ...5 OA-740 Overview... 6 Package Contents... 6 Hardware Overview... 7 The OA-740 ... 7 User Modules ...
  • Page 4 Class A Warning for Taiwan and Other Chinese Markets Translated Safety Warnings... 10 Instrucciones de seguridad en Appendix B AC Power Specifications...19 Appendix C Pin Connector Details for OmniAccess 740 RJ-11 Modem Connector Pin RJ-45 Console Connector Pin Assignments T1E1 Connector Pin Assignments... 23 SE/L2GE Connector Pin Assignments Serial Card (V.35/X.21) Connector Pin Assignments...
  • Page 5 List of Figures The OA-740 Chassis 8 Air Flow Through the OA-740 9 Front Panel 10 Rear Panel 10 OA-740 (4-Slot Chassis) 11 Services Engine 13 4-port T1E1 Line Card 15 GigE Line Card 17 Serial Line Card (V.35/X.21) 20 Ports on the Front Panel 23 Connecting Power Cord 33 Rack Mounting the OA-740 38...
  • Page 7 List of Tables OA-740 Chassis Physical Specifications 9 Slot Numbers 11 LED Status 11 Cable Connections 12 SE Card LEDs 14 LEDs for Ethernet Port on SE Card 14 T1E1 Card LEDs 16 T1E1 Port LEDs 16 T1E1 Mode LEDs 17 GigE Card LEDs 18 LEDs for each Port on GigE Card 18 Serial Card (V.35/X.21) LEDs 21...

  • Page 9: Preface

    UIDE This hardware users guide explains the initial hardware installation and the configuration procedures for the OmniAccess 740 (OA-740). It contains procedures for unpacking and installing the OA-740 system hardware, starting up the system, and creating a basic configuration. After completing the installation and basic configuration procedures covered in this guide, use the appropriate companion publications to more completely configure your system.

  • Page 10: Document Organization

    Chapter 4 Starting the OmniAccess 740 provides procedure for starting the OA- 740, performing basic configuration tasks, and connecting the system to internal and external networks.

  • Page 11: Obtaining Documentation

    We value your comments and suggestions about our documentation. If you have any comments about this book, please enter them through the feedback link on the Alcatel-Lucent Website. We will use your feedback in our plans to improve the documentation.
  • Page 12 Left running head: Chapter name (automatic) OmniAccess 740 Hardware User’s Guide Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 13: Omniaccess 740 Overview

    HAPTER OmniAccess 740 O NTRODUCTION This chapter provides physical and functional overview of the OmniAccess 740 (OA-740). It contains the functional description of OA-740 hardware, its major components, and related features. Descriptions and examples of software commands are included only when they are necessary for replacing, installing, configuring, or maintaining the OA-740 hardware.

  • Page 14: Oa-740 Overview

    4-port Serial Line Card (V3.5/X.21) 3. Miscellaneous • AC Power Cord • Console Cable • Rack Mount Screws • 19-inch Rack Mount Ears • 512 MB USB Memory Flash • Product Documentation CD ROM Beta Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 15: Hardware Overview

    (such as the SE). All the OA-740 cards support Online Insertion and Removal (OIR) feature. The OA-740 has the following components: • OA-740 Chassis • OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Hardware Overview Beta...
  • Page 16 1. SE 2. 4-port T1E1 Line Card 3. Rack Mount Flange Figure 1: The OA-740 Chassis Beta O A 7 - 6 E - 8 O A 7 - T 1 E 1 Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 17 OA-740 components. (Refer to the power supply specifications.) The chassis also has built-in fans for efficient cooling of the OA-740, which prevents damages due to overheating of the OA-740 components. OmniAccess 740 Hardware User’s Guide Beta 1.73-inch (4.4 cm) 17.5-inch (44.5 cm) 19-inch (48.3 cm) with rack mount...

  • Page 18: Front Panel

    19-inch rack. OA7-T1E1-4 OA7-6E-8 Figure 3: Front Panel The rear panel provides power supply connectivity to the OA-740. Figure 4: Rear Panel Beta OA7-SE Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 19: Slot Numbers

    Figure 5: OA-740 (4-Slot Chassis) LED I NFORMATION The following table shows the state of the main LEDs after startup. Table 3: LED Status SE LEDs Active OmniAccess 740 Hardware User’s Guide Beta Card Associated With the Slot Slot Type Single Line Card Single...
  • Page 20 The back panel in the OA-740 provides docking slots for the SE card, the line cards, and performs switching functions. Beta Port Type Ethernet hub or switch. T1E1 network. PC or VT100 Telephone Line V.35/X.21 modem Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Connect To Beta...

  • Page 21: User Modules

    Activity. The SE card is a dual slot line card, and is installed in slots 2, 3. OA7-SE 1. SE LEDs 2. GigE Ports 3. Thumb Screw 4. Left LED on the Ethernet Port 5. Right LED on the Ethernet Port Figure 6: Services Engine OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Hardware Overview Beta...

  • Page 22: Se Card Leds

    SE card is active. Reload in progress. Status Green Link Speed is 1000/10 Mbps. Yellow Link Speed is 100 Mbps. Link is not active Amber Traffic is active. Traffic is not active. Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Description Description Beta...
  • Page 23 The figure below shows the 4-port T1E1 Line Card. OA7-T1E1-4 1. T1E1 Card LEDs 2. T1E1 Mode LEDs 3. T1E1 Port LEDs 4. RJ-45 Interfaces 5. Thumb Screw Figure 7: 4-port T1E1 Line Card Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 24: T1E1 Card Leds

    Remote system is not transmitting any alarm. Carrier detected (cable plugged in). Carrier not detected (cable plugged out). Indicates port is in any of the local or network Loopback mode. Port is not in Loopback mode. Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Description Description Beta...

  • Page 25: Gige Line Card

    OA7-GE-8 1. GigE Card LEDs 2. RJ-45 Interfaces 3. Thumb Screw Figure 8: GigE Line Card OmniAccess 740 Hardware User’s Guide Beta Line card configured in the T1 mode. Line card Configured in the E1 balanced mode. Line card configured in the E1 unbalanced mode.

  • Page 26: Gige Card Leds

    Blinking Green Port 3 link and traffic is active. Port 4 link is not active. Solid Green Port 4 link is active. Blinking Green Port 4 link and traffic is active. Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Description Description Beta...
  • Page 27 LED 5 LED 6 LED 7 OmniAccess 740 Hardware User’s Guide Beta Status Port 5 link is not active. Solid Green Port 5 link is active. Blinking Green Port 5 link and traffic is active. Port 6 link is not active.
  • Page 28 DTE and the local PSE. It can operate at data rates from 600bps. OA7-USP-2 1. V.35/X.21 Card LEDs 2. V.35/X.21 Port LEDs 3. 68 pin VHDCI Connector 4. Thumb Screw Figure 9: Serial Line Card (V.35/X.21) Beta Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 29 Table 12: Serial Card (V.35/X.21) LEDs Active Fault Table 13: Serial (V.35/X.21) Port LEDs Active/LB DTE/DCE RX Clk TX Clk OmniAccess 740 Hardware User’s Guide Beta Status Green Serial card is active. Yellow Indicates transient conditions (e.g., booting). Reload in progress.
  • Page 30 OmniAccess 740 Overview Serial Card (V.35/X.21) Cable Details The following table lists the part numbers for the Alcatel-Lucent specific V.35/X.21 cables: Table 14: Serial Card (V.35/X.21) Cable Part Numbers Part No. 5100-0010-00 5100-0011-00 5100-0012-00 5100-0013-00 Beta Description Cable ASSY V.35 DTE Cable with Male Connector (68 Pin SCSI Connector to V.35 DTE Male Connector)
  • Page 31 9600 baud. Figure 10: Ports on the Front Panel OOLING The cooling unit is integrated in the chassis. The cooling unit houses speed fan for efficient chassis cooling. OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Hardware Overview Beta...

  • Page 32: System Specifications

    10,000 ft 15,000 ft Value 100-240 Volts 3 AMP 250 Watts Value (1.73 x 17.5 x 17) in. (4.4 x 44.5 x 43.2) cm. 26.4 lbs (12.8 kgs) 1 Rack Unit (1 RU) Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 33 HAPTER OmniAccess 740 NSTALLING THE This chapter guides you through the process of preparing your OmniAccess 740 (OA-740) for installation. This chapter describes the equipment, tools, power, and site requirements for installing the OA-740. It contains the following sections: •...

  • Page 34: Installing The Omniaccess 740

    Verify that the contents are included in the shipping container (the accessories box might be separate): • One OA-740, fully assembled • One or more accessories boxes (some or all may be shipped separately) Beta Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 35: Safety Measures

    Note: The entire OA-740 documentation set is shipped with each system. These documents can also be downloaded from the Alcatel-Lucent Website. Step 3: Verify the cards installed. Verify that the line cards installed in your OA-740 match the card types on the packing list.

  • Page 36: Equipment Guidelines

    The following guidelines will help to ensure your safety and protect the equipment. This list does not cover all potentially hazardous situations. However, Alcatel-Lucent advices you to observe caution while working with the system. Warning: To avoid hazard from electrical shock and/or fire, adhere to safety practices listed in this section and identified within instructions of this document.

  • Page 37: Lifting Safely

    Lift the chassis from the bottom; grasp the underside of the chassis exterior with both hands. AFETY WITH LECTRICITY Alcatel-Lucent advices you to follow the guidelines given below as a measure of safety. Warning: To avoid shock, do not open or attempt to service the unit or its associated power supply cards.

  • Page 38: Preventing Electrostatic Discharge Damage

    Ensure the line cards are fully inserted in their respective chassis slots and the thumb screws are tightened. Warning: For safety, periodically check the resistance value of the antistatic strap. The measurement should be in 1 and 10 mega ohms range. Beta ISCHARGE AMAGE Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 39: Site Requirement Guidelines

    Ensure that the cooling vents are not blocked and there is adequate air flow due to ample clearances around the OA-740. • Alcatel-Lucent recommends keeping the OA-740 off the floor and out of any area that tends to collect dust. •...

  • Page 40: Power Supply Overview

    For more details on power supply specifications, see Specifications”. The following section provides the procedure for connecting input power to your OA-740. Warning: Read the installation instructions before you connect the system to its power source. Beta “AC Power Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 41 Be sure that the power cable is not left in a hazardous position that may restrict movement of personnel or that may fray due to movement of other equipment near the system. OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Power Supply Overview...

  • Page 42: Plant Wiring

    Check the power at your site before installation and periodically after installation to ensure that you are receiving uninterrupted power. • Install a power conditioner if necessary. • Install proper grounding to avoid damage from lightning and power surges. Beta PECIFICATIONS IXING OWER ABLES Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 43: General Installation

    The OA-740 receives adequate ventilation (it should not be installed in an enclosed cabinet where ventilation is inadequate). • Adequate ground (earth) connection for your OA-740 is provided. OmniAccess 740 Hardware User’s Guide Beta section of this document. Please follow the guidelines Alcatel-Lucent General Installation “Site...

  • Page 44: Rack-Mounting The Oa-740

    You can also mount the OA-740 on an equipment shelf provided that the rack dimensions allow you to secure the system to the shelf. However, Alcatel-Lucent recommends rack-mounting the OA-740. To rack-mount the OA-740, consider the following guidelines: •...

  • Page 45: Parts Required

    Two hex nuts and M4 screws • Four 10-32 x 3/8-inch slotted screws • 3/8-inch nut driver • No. 2 Phillips screwdriver • 1/4-inch flat-blade screwdriver • Cable ties, if necessary OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Rack-Mounting the OA-740 Beta...

  • Page 46: Installing The Oa-740 In The Rack

    Tighten all the screws. T 1 E 1 O A 7 - Figure 12: Rack Mounting the OA-740 Beta “Safety Measures” O A 7 - 6 E - 8 O A 7 - Alcatel-Lucent OmniAccess 740 Hardware User’s Guide section Beta...

  • Page 47: Installing User Modules

    Step 3: Push the line card firmly and ensure that the card is fully inserted in its respective slot and tighten the thumb screws. O A 7 - Figure 13: Installing Services Engine OmniAccess 740 Hardware User’s Guide Beta 6 E - 8 O A 7 -...

  • Page 48: Installing Fillers

    Beta O A 7 - 6 E - 8 O A 7 - T 1 E 1 O A 7 - ARDS Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 49: Starting The Omniaccess 740

    HAPTER OmniAccess 740 TARTING THE NTRODUCTION This chapter explains the procedure for starting the OmniAccess 740 (OA-740), and connecting to the system console port for Command Line Interface (CLI) access for performing basic configuration tasks. • Checking Conditions Prior to System Startup •...

  • Page 50: Led Status

    Status Power up status. This is the default display when the system is first powered on and before the software is loaded. Green SE card is active. Alcatel-Lucent OmniAccess 740 Hardware User’s Guide TARTUP Description Beta...
  • Page 51 “OmniAccess 700 CLI Configuration Guide”. Step 4: If all the activities have proceeded normally and if the initial configuration is complete, the OA-740 is installed and is now ready for deployment in your network. Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 52: Connecting To The System Console

    OA-740 and the DB-9 end to the serial-port (COM) on your computer/ terminal. Figure 15: Connecting to the System Console Beta YSTEM ONSOLE for detailed information on cable pin connection. RJ-45 Console Port Alcatel-Lucent OmniAccess 740 Hardware User’s Guide “Pin Connector RJ-45 Connector Beta...
  • Page 53 Parity Data Bits Stop Bit Flow control Step 4: Watch for console message output or press the Enter key to get the device prompt. OmniAccess 740 Hardware User’s Guide Beta Connecting to the System Console Port Value 9600 None None...

  • Page 54: Performing Basic Configuration Tasks

    By default, the host name is “ALU”. (To configure a different host name, use the configure “hostname <name>’ command in the Configuration mode.) Step 3: At the ALU prompt, enter the enable command to enter the Super User Mode (SUM). Example: ALU> enable ALU# Beta ONFIGURATION ASKS Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 55 {secret|password} [5] <password> Example: ALU(config)# enable secret test Secret for level 15 is set Note: By default, only the console session is available without the enable password configuration. OmniAccess 740 Hardware User’s Guide Beta Performing Basic Configuration Tasks Alcatel-Lucent Beta...
  • Page 56 Telnet is a user command and an underlying TCP/IP protocol for accessing remote computers. Telnet is a program that enables connection to foreign or remote host computers, and provides access to information on them. telnet {enable|disable} Example: ALU(config)# telnet enable Beta Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 57 Description: Service engine Serial number: Version: 01 Revision: 02 Deviation: 0001 Opteron CPU Version: 10 Opteron CPU Frequency: 1994 MHz LoL firmware version: 2.2.56 Loader version: 2.29 OmniAccess 740 Hardware User’s Guide Beta Performing Basic Configuration Tasks ND0533001165 DD0538002041 Alcatel-Lucent Beta...
  • Page 58 For further configuration of your OA-740, refer to the OmniAccess 700 CLI Configuration Guide provided in the OA-740 Documentation CD along with your system. Beta Serial number: WL0534000130 Deviation: 0002 Revision: A1 Version: 01 WL0537000210 Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 59: Connecting The System To The Network

    OA-740. For further configuration of your OA-740, refer to the OmniAccess 700 Web GUI User Guide provided in the OA-740 Documentation CD. OmniAccess 740 Hardware User’s Guide Beta Connecting the System to the Network...
  • Page 60 From the Unix/Linux host, from the terminal window, type telnet 192.168.1.1 and press the Enter key. Step 3: Enter the username and password at the prompt. You are now ready to access the OA-740, using a Telnet session. Beta Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 61 <username>@192.168.1.1, and press the Enter key. Step 3: Enter the username and password at the prompt. You are now ready to access the OA-740 using an SSH session. OmniAccess 740 Hardware User’s Guide Beta Connecting the System to the Network...

  • Page 62: Connecting Through External Network

    RJ-11 jack from the external modem to the modem port provided in the front panel of the OA-740. Figure 17: Connecting through External Network Beta ETWORK RJ-11 Modem Port Alcatel-Lucent OmniAccess 740 Hardware User’s Guide RJ-11 Connector Beta...

  • Page 63: Site Log

    • Any line card removed and replaced • Power supply removals and changes • Configuration changes • Software upgrades • Corrective maintenance procedures performed • Related comments. OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Site Log Beta...
  • Page 64 Left running head: Chapter name (automatic) Starting the OmniAccess 740 Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 65: Appendix A Regulatory Compliance And Safety Information

    Appendix A Regulatory Compliance and Safety Information This appendix provides information on regulatory agency compliance and safety for the OmniAccess 740 (OA-740). ECLARATION OF ONFORMITY This equipment is in compliance with the essential requirements and other provisions of Directive 73/23/EEC and 89/336/EEC as amended by Directive 93/ 68/EEC.
  • Page 66 Treatment applied at end of life of the product in these countries shall comply with the applicable national laws implementing directive 2002/96EC on waste electrical and electronic equipment (WEEE). Beta (WEEE) S QUIPMENT TATEMENT Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 67: China Rohs: Hazardous Substance Table

    对销售之日的所售产品,本表显示, 阿尔卡特朗讯公司供应链的电子信息产品可能包含这些物质。注意:在所售产 品中可能会也可能不会含有所有所列的部件。 This table shows where these substances may be found in the supply chain of Alcatel-Lucent electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 68 Left running head: Chapter name (automatic) Regulatory Compliance and Safety Information Products are packaged using one or more of the following packaging materials: Corrugated Cardboard Corrugated Fiberboard Low-Density Polyethylene Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 69: Standards Compliance

    CS 03 Issue 8, Part II • TBR 12 AND TBR 13 • AS/ACTF S016: 2001 • T1(DS1) JATE - 1.544 Mbit/sec Digital Interface • E1 JATE - 2.048 Mbit/sec Digital Interface OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Standards Compliance Beta...

  • Page 70: Declaration Of Conformity Addendum

    EN 61000-4-2:2001 EN 61000-4-3:2002 EN 61000-4-4:1995+A1:2000+A2:2001 EN 61000-4-5:2001 EN 61000-4-6:2001 EN 61000-4-8:2001 EN 61000-4-11:2001 EN 55024:1998+A1:2001 EN60555-2: 1995 EN 60950-1:2001+A11 CB Scheme ETSI EN 300 386 v1.4.1(2000-2003) ETSI TBR 012 ETSI TBR 013 Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 71: Fcc Class A, Part

    Plug the equipment into a different outlet so that equipment and receiver are on different branch circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. OmniAccess 740 Hardware User’s Guide Beta Alcatel-Lucent Standards Compliance...

  • Page 72: Canada Classa Statement

    Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. Beta OMMUNICATIONS DU Alcatel-Lucent OmniAccess 740 Hardware User’s Guide ANADA Beta...
  • Page 73 AIWAN AND This is a Class A Information Product. When used in a residential environment, it may cause radio frequency interference. Under such circumstances, the user may be requested to take appropriate countermeasure. OmniAccess 740 Hardware User’s Guide Beta THER HINESE...

  • Page 74: Translated Safety Warnings

    Español: Las tapaderas blancas regulan la circulación de aire y ayudan a proteger componentes internos del chasis y siempre deben estar instaladas en las ranuras vacías del chasis y fuentes de alimentación. Beta ARNINGS Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 75 Español: Debido a que la apertura del puerto puede emitir radiación invisible cuando no hay un cable de fibra conectado, procurar no mirar directamente a las aperturas para no exponerse a la radiación. OmniAccess 740 Hardware User’s Guide Beta Translated Safety Warnings...
  • Page 76 Deshágase de las pilas usadas según las instrucciones del fabricante. Devuelva el módulo con la pila de litio a Alcatel-Lucent. La pila de litio será substituida en la fábrica de Alcatel-Lucent.
  • Page 77 • Cualquier otro equipo a cual se conecte este producto también debe estar conectado a tomas de alimentación adecuadamente cableadas. OmniAccess 740 Hardware User’s Guide Beta ARNING Alcatel-Lucent Translated Safety Warnings...
  • Page 78 Español: Este equipo se debe instalar en un sitio con acceso restrinjido. Un sitio con el acceso restrinjido es uno seguro y con acceso limitado al personal de servicio que tiene una clave especial u otros medios de seguridad. Beta ARNING ARNING Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...
  • Page 79 Because electrostatic discharge (ESD) can damage switch components, you must ground yourself properly before continuing with the hardware installation. For this purpose, Alcatel-Lucent provides a grounding wrist strap and a grounding lug located near the top-right of the chassis. For the grounding wrist strap to be effective in eliminating ESD, the power supplies must be installed in the chassis and plugged into grounded AC outlets.

  • Page 80: Instrucciones De Seguridad En Español

    Deseche las baterías usadas según las instrucciones del fabricante. Las instrucciones del fabricante son como sigue: Devuelva el módulo con la batería del litio a Alcatel-Lucent. La batería del litio será substituida en la fábrica de Alcatel-Lucent.
  • Page 81 Cumple con 21CFR 1040.10 y 1040.11 ó sus equivalentes. DVERTENCIA DE FUENTES DE PODER Las unidades OmniAccess 740 pueden estar equipadas con tres cordones para fuente de poder. Para reducir el riesgo de un choque electrico, desconecte todos los cordones de fuente de poder antes de dar servicio a la unidad.
  • Page 82 Left running head: Chapter name (automatic) Regulatory Compliance and Safety Information Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta Beta...

  • Page 83: Appendix B Ac Power Specifications

    Power output Efficiency Environmental Characteristics Temperature, operating Temperature, non- operating (storage and shipping) Humidity OmniAccess 740 Hardware User’s Guide Beta Beta Specification 100 to 240 VAC 50 to 60 Hz 250W 65% at minimum measured at nominal AC main voltage and frequency with maximum load on all output 0 to 40°C...
  • Page 84 Agency approvals Beta Specification UL 1950, CSA C22.2 Level 3, TUV EN60950 or VDE EN60950, NEMKO EN60950 (CB Report), Complies with FCC part 15 subpart J Class B and CISPR 22 Class B Alcatel-Lucent OmniAccess 740 Hardware User’s Guide Beta...

  • Page 85: Table

    Appendix C Pin Connector Details for OmniAccess 740 This section describes pin connection details for the OmniAccess 740 (OA-740). RJ-11 M ODEM ONNECTOR This section details modem connector pin (RJ-11) details for the OA-740. Figure 1: RJ-11 Connector Table 1: Pin Connector Details for RJ-11 Connector RJ-11 Connector Pin Number OmniAccess 740 Hardware User’s Guide...

  • Page 86: Console Connector Pin Assignments

    Pin Connector Details for OmniAccess 740 RJ-45 C ONSOLE ONNECTOR This section details the console connector pin (RJ-45) details for the OA-740. Figure 2: RJ-45 Connector Table 2: Pin Connector Details for RJ-45 Connector RJ-45 Connector Pin # Beta SSIGNMENTS...

  • Page 87: T1E1 Connector Pin Assignments

    The following table details the T1E1 connector pin details for the OA-740: Table 3: T1E1 Card Port Connector Pin Assignment Pin # OmniAccess 740 Hardware User’s Guide Beta Pin Connector Details for OmniAccess 740 Signal Name Receive Ring Receive Tip NC (No Connection)

  • Page 88: Se/L2Ge Connector Pin Assignments

    Pin Connector Details for OmniAccess 740 SE/L2GE C ONNECTOR The following table details the SE/L2GE connector pin details for OA-740 system. Table 4: 10/100/1000 Mbps Port Connector Pin Assignment on SE/L2GE Card In 10 Base-T and 100 Base-Tx Pin #...

  • Page 89: Serial Card (V.35/X.21) Connector Pin Assignments

    PORT1_DCD_B PORT1_DTR_B PORT1_RI PORT1_TM PORT1_RxD_B No Connect PORT1_TxD_B No Connect PORT1_RxTiming_B No Connect PORT1_TxTiming_B OmniAccess 740 Hardware User’s Guide Beta Pin Connector Details for OmniAccess 740 SSIGNMENTS Pin# Signal Ground PORT1_RTS_A PORT1_CTS_A PORT1_DSR_A PORT1_DCD_A PORT1_DTR_A PORT1_RL PORT1_LL PORT1_RxD_A No Connect...
  • Page 90 Pin Connector Details for OmniAccess 740 Pin# Signal Name Signal Ground PORT1_TXC_B CHASSIS_GND PORT0_RTS_B PORT0_CTS_B PORT0_DSR_B PORT0_DCD_B PORT0_DTR_B PORT0_RI PORT0_TM PORT0_RxD_B P0P1_CMODE0 PORT0_TxD_B P0P1_CMODE2 PORT0_RxTiming_B P0P1_CMODE4 PORT0_TxTiming_B Signal Ground PORT0_TXC_B CHASSIS_GND PORT2_RTS_B PORT2_CTS_B PORT2_DSR_B PORT2_DCD_B PORT2_DTR_B PORT2_RI PORT2_TM PORT2_RxD_B P2P3_CMODE0...
  • Page 91 PORT3_TM PORT3_RxD_B No Connect PORT3_TxD_B No Connect PORT3_RxTiming_B No Connect PORT3_TxTiming_B Signal Ground PORT3_TXC_B OmniAccess 740 Hardware User’s Guide Beta Pin Connector Details for OmniAccess 740 Pin# PORT2_TxD_A P2P3_CMODE3 PORT2_RxTiming_A Signal Ground PORT2_TxTiming_A Signal Ground PORT2_TXC_A Signal Ground PORT3_RTS_A PORT3_CTS_A...

  • Page 92: Connector

    Pin Connector Details for OmniAccess 740 V.35 DTE C ERIAL ABLE The following table lists the V.35 DTE cable pin out at the M-34 Winchester connector: Table 6: Serial Card V.35 DTE Cable Pin-out Signal Name TxD(A) V.35 TxD(B) V.35 TT(A) (DTE supplied V.35...
