Summary of Contents for Alcatel-Lucent OmniAccess 700 (Vers. 2.2, 2.2-R02, 2.3)

Page 1 2.2-R02 Notes on numbered items on banner & legal pages u26801 West Agoura Road Calabasas, CA 91301 (818) 880-3500 FAX (818) 880-3505 support@ind.alcatel.com Beta US Customer Support—(800) 995-2696 International Customer Support—(818) 878-4507 Internet—service.esd.alcatel-lucent.com Website: www.alcatel-lucent.com Part No: 060221-00, Rev. C...
Page 2 In no event shall Alcatel-Lucent be liable for any indirect, special, consequential, or incidental damages, including, without limitation, lost profits or loss or damage to data arising out of the use or inability to use this manual, even if Alcatel-Lucent have been advised of the possibility of such damages.
Page 3: Table Of Contents
Table of Contents Package Contents........................1 Required Tools and Equipment ..................2 Connecting AC Input Power...................... 3 Connecting to the OA-700 Console Port................... 5 Starting the OA-700 ........................8 Performing Basic Configuration Tasks..................12 Accessing the OA-700 Through CLI ................. 12 Accessing the OA-700 Through GUI ................
Page 4: List Of Figures
List of Figures Connecting the Power Cord on OA-740 3 Connecting the Power Cord on OA-780 4 Connecting to the OA-740 System Console 5 Connecting to the OA-780 System Console 6...
Page 5 List of Tables Console Properties 7 OA-740 LED Status 8 OA-780 LED Status 9 Cable Connection 20...
Page 6: Package Contents
Flash • 4-port T1E1 Line Card • Product Documentation • 8-port 10/100/1000 Mbps Gigabit Ethernet CD ROM (GigE) Line Card • 4-port Universal Serial Port (USP) Line Card (V.35/X.21/RS-232) Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 7: Required Tools And Equipment
OA-700. Refer to the warnings and safety notes that are given in the “OmniAccess 740/780 Hardware Users Guide” provided with this device. Refer to the “Rack Mounting the OA-740/OA-780” section in the “OmniAccess 740/780 Hardware Users Guide” to install the OA-700 in the rack. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 8: Connecting Ac Input Power
740 consumes approximately 250W of power. For more details on power supply specifications, see the “AC Power Specifications” chapter in the “OmniAccess 740 Hardware Users Guide”. Figure 1: Connecting the Power Cord on OA-740 Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 9: Connecting The Power Cord On Oa-780
Step 5: Ensure that the cable is not left in a hazardous position that could impair movement of personnel or be frayed due to the movement of other equipment in the vicinity. Warning: Read the installation instructions before you connect the OA-700 to its power source. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 10: Connecting To The Oa-700 Console Port
DTE (computer/terminal). For additional connector details, refer to “Pin Connector Details for OA-740/OA-780” in the “OmniAccess 740/780 Hardware Users Guide”. Figure 3: Connecting to the OA-740 System Console Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 11: Connecting To The Oa-780 System Console
Chapter name (automatic) Connecting to the OA-700 Console Port Figure 4: Connecting to the OA-780 System Console Note: Ensure that the OA-700 is powered off before connecting the console cable to the system. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 12: Console Properties
Table 1: Console Properties Parameter Value Baud rate 9600 Parity None Data Bits Stop Bit Flow control None Step 4: Watch for console message output or press the Enter key to get the device prompt. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 13: Starting The Oa-700
Power up status. This is the default display when the system is first powered on and before the software is loaded. Green SE card is active. Yellow Indicates transient conditions (e.g., booting). Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 14: Oa-780 Led Status
Green Bootup completed, and system is ready to use. Fan Tray LEDs (3 Uni-color Port LEDs) representing USB, Console, and Modem ports System is not working. Console LED Green Console is accessible. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 15 == Initiating startup sequence == Mounting internal storage medium...OK. Checking storage medium...OK ################################################## Alcatel-Lucent Software, Version 2.3.1.30 Copyright (c) 2003-2008 by Alcatel-Lucent Inc. Built on Tue Dec 2 17:26:09 IST 2008 ################################################# Services Engine [3] Starting daughter processor Services Engine [3] Installing image package Services Engine [3] (SE) Installing image package Loading Startup Config ...
Page 16 Services Engine [3] (SE) Installing image package Loading Startup Config ... /-------- Percent Complete -------- |********************************* Services Engine [3] (SE) Initialization Complete Username :superadmin Password : ALU> Step 4: Configure the system. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 17: Performing Basic Configuration Tasks
By default, the host name is “ALU”. (To configure a different host name, use the configure “hostname <name>’ command in the Configuration mode.) Step 3: At the ALU prompt, enter the enable command to enter the Super User Mode (SUM). Example: ALU> enable ALU# Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 18 Step 7: Establish authentication for new users by configuring new user accounts. To configure a new user account, use the following command: username <user-name> {password [5] <password>|nopassword| secret [5] <password>} Example: ALU(config)# username user1 password pass1 Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 19 Telnet is a user command and an underlying TCP/IP protocol for accessing remote computers. Telnet is a program that enables connection to foreign or remote host computers, and provides access to information on them. telnet {enable|disable} Example: ALU(config)# telnet enable Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 20 Serial number: DD0520001606 Version: 01 Revision: A00 LoL firmware version: 2.2.68 Loader version: 2.33 ALU-OS version: 2.3.1.30 Serial number: WL0544000297 Revision: A00 Version: 01 SE - Services engine (active) Slot number: 3 Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 21 Loader version: 2.33 ALU-OS version: 2.3.1.30 Serial number: WL0544000288 Revision: A00 Version: 01 SE - Services engine (active) Slot number: 3 Part number: 902601-90 Manufacturer: Description: Services engine Serial number: DD0538002047 Version: 01 Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 22 Loader version: 2.33 ALU-OS version: 2.3.1.30 FP - Fan tray (passive) Slot number: 26 Part number: 902614-90 Manufacturer: Description: Fan tray Serial number: DD05XX000000 Version: 00 Revision: A00 BP - ALU OA780 chassis (passive) Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 23 Be sure to save the running configuration. If this is not done, when the system reboots, the configuration is lost. For further configuration of your OA-700, refer to the OmniAccess 700 CLI Configuration Guide provided in the OA-700 Documentation CD along with your system. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 24: Accessing The Oa-700 Through Gui
Step 4: Enter the user name and password, and press the Enter key. This will launch a web interface to configure your OA-700. For further configuration of your OA-700, refer to the “OmniAccess 700 Web GUI Users Guide” provided in the OA-700 Documentation CD. Alcatel-Lucent OmniAccess 700 Getting Started Guide Beta Beta...
Page 25: Cable Connection
BTAINING ECHNICAL UPPORT For all customers, partners, resellers, and distributors who hold valid Alcatel-Lucent service contracts, the Alcatel-Lucent Technical Support Team provides 24-hour-a-day, technical support services online and over the phone. For Customer issues and help, contact: Alcatel-Lucent US Customer Support: (800) 995-2696 International Customer Support: (818) 878-4507 E-mail: support@ind.alcatel.com...
