Summary of Contents for RAIS JUNO 160 L

  • Page 2 The production number can be found underneath the burning chamber.

  • Page 3: Table Of Contents

    Fitting the smoke outlet spigot installation with swivel base Mounting of the stones for Juno 120 L Mounting of the stones for Juno 120 L G Mounting of the stones for Juno 160 L Mounting of the stones for Juno 160 L G...

  • Page 4: Installation Manual

    INSTALLATION MANUAL INSTALLATION MANUAL stalled on a flammable floor, national and local regulations must be com- Thank you for choosing your new RAIS plied with, including for the size of the product! This installation manual will non-flammable plate, which must cover...

  • Page 5: Technical Data

    TECHNICAL DATA The technical data given below includes specifications, dimensional drawings and the information plate. SPECIFICATIONS KIWA ref.: 61589 JUNO 120 L JUNO 160 L Nominal output (kW) Min./Max. Output (kW): 3–7* 3–7* Heating area (m Fireplace insert width/depth/height Ø468 X 1223 Ø468 X 1673...

  • Page 6: Dimensional Sketches

    DIMENSIONAL SKETCHES...
  • Page 7 DIMENSIONAL SKETCHES...
  • Page 8 DIMENSIONAL SKETCHES...
  • Page 9 DIMENSIONAL SKETCHES...

  • Page 10: Information Plate

    RAIS A/S, Industrivej 20, 9900 Frederikshavn, Danmark Juno 120 L / Juno 120 L CA / Juno 120 L Classic / Juno 120 L CLASSIC CA Juno 160 L / Juno 160 L CA / Juno 160 L Classic / Juno 160 L CLASSIC CA AFSTAND TIL BRÆNDBART, BAGVÆG...
  • Page 11 RAIS A/S, Industrivej 20, 9900 Frederikshavn, Danmark Juno 120 L G / Juno 120 L G CA / Juno 120 L G Classic / Juno 120 L G CLASSIC CA Juno 160 L G / Juno 160 L G CA / Juno 160 L G Classic / Juno 160 L G CLASSIC CA AFSTAND TIL BRÆNDBART, BAGVÆG...

  • Page 12: Installation

    INSTALLATION INSTALLATION The following section explains how to install the stove and includes information about the packaging, installation distances etc. DELIVERY PACKAGING Upon delivery, the stove is secured to a transport pallet using four transport safety fittings, one in each corner (A). The safety fittings are secured with screws, which must be unscrewed.

  • Page 13: Installation Distances

    INSTALLATION DISTANCES INSTALLATION DISTANCES. IMPORTANT: Please bear in mind that the installation distances on the following pag- es only apply to the wood-burning stove. The final choice of Chimney solution may have a larger safety distance to the flammable material. The Chimney solution must always be installed in accordance with current building regulations and in a manner that ensures CE-marking compliance.
  • Page 14 INSTALLATION DISTANCES INSTALLATION DISTANCE TO FLAMMABLE MATERIAL: The installation distances applicable to the wood-burning stove are shown below. Bear in mind that the final choice of chimney may have a different safety distance. All dimensions are in mm. Juno L without side glass without side glass Right-angle installation...
  • Page 15 Juno L with side glass INSTALLATION DISTANCES uninsulated chimney 4716509 INSTALLATION DISTANCE TO FLAMMABLE MATERIAL WITH SIDE GLASSES e glass Right-angle installation Corner installation...

  • Page 16: Height Adjustment

    HEIGHT ADJUSTMENT HEIGHT ADJUSTMENT The stove is equipped with four adjustment screws (1) un- der the stove. Use the adjustment screws to ensure the wood-burning stove stands level. 4716510 Juno L Stillesko...

  • Page 17: Fitting/Changing The Handle

    FITTING THE HANDLE FITTING/CHANGING THE HANDLE The wood-burning stove comes with a tem- porary handle (1). To remove it, undo the screws (2). and the washers (3) The new han- dle (4) can now be fitted to the stove using the screws (2) and the washers (3).

  • Page 18: Removing The Combustion Chamber Lining

    REMOVING THE COMBUSTION CHAMBER LINING REMOVING THE COMBUSTION CHAMBER LINING The combustion chamber lining protects the body of the stove from the heat of the fire. The large differences in temperature can lead to cracks in the combustion chamber lining. This will not affect the functionality of the stove.

  • Page 19: Lubricating Hinges

    LUBRICATING THE HINGES 4716513 Juno L LUBRICATING THE HINGES & LOCK Smøring af hængsler The fireplace must be lubricated regularly using the four moving parts on the lock and og lukketøj hinges (see image). Use heat-resistant oil.

  • Page 20: Fitting The Smoke Outlet Spigot

    4716514 Juno L Røgstuds montering Smoke outlet spigot MOUNTING OF THE SMOKE OUTLET SPIGOT THE SMOKE OUTLET SPIGOT CAN BE TURNED TWO WAYS. YOU CAN CHOOSE EI- THER WAY. Version A uses the three free holes: 1) Ø8 Slits 2) M6 Nuts 3) M6 Washers 4) M6X20mm cylinder screws Version B uses the three threaded holes:...
  • Page 21 Smoke outlet to rear outlet INSTALLATION OF THE SMOKE OUTLET FOR REAR OUTLET. The stove is ready for top exit on delivery, but can be changed to rear exit in the fol- lowing way. 1. Remove the cover (1) and gasket (2) from the rear outlet and mount it on the top outlet, with the three M6 nuts(3).

  • Page 22: Installation With Swivel Base

    installation with swivel base 4716516 Juno L Installation with swivel base The wood-burning stove can be supplied with a swivel base. To make installation easier, the wood-burning stove is delivered turned 45° to the left. This ensures easier access to the transport screws, which must be removed when setting up.
  • Page 23 REMOVAL OF SAFETY TRANSPORT FITTINGS The swivel base is fitted below the wood-burning stove and locked during transport using two wing screws. See below for how to remove these. The swivel base setting options: · to turn 90° (45° on each side) - (set to this on delivery) ·...

  • Page 24: Mounting Of The Stones For Juno 120 L

    4718608 Juno 120 L Mounting of stones Mounting of the stones for Juno 120 L STEP 1. To mount the bottom side stones in the bottom row. Place the stones over the pins, on the bottom plate of the stove. Place the...
  • Page 25 Mounting of the stones for Juno 120 L STEP 2. To mount the back stones in the bot- tom row. Place the stones on the pins on the bottom plate as shown. Fix the stones in the top, by inser- ting the four pins through the steel ring.
  • Page 26 Mounting of the stones for Juno 120 L STEP 3 - TOP OUTLET To mount the stones in the middle row. Step 2 Step 3 Place the stones over the pins in the lower steel ring, place the steel bracket (4730101sv) on top of the burning chamber to fix the stones.
  • Page 27 Mounting of the stones for Juno 120 L STEP 3 - BACK OUTLET To mount the stones in the middle row. Place the two back stones (4717004 & 4717005) over the pins in the lower steel ring, Fix them to the bottom ring with the locking brackets (4710111) by loosening the...
  • Page 28 Mounting of the stones for Juno 120 L STEP 4. Step 3 Step 4 To mount the left front stone in the bottom row. Fix the bracket (4710115) to the bracket (4710103sv) with the M5x12 screw, and place them on the stone. Place the bracket and stone on the bottom plate, and fix the 4710115 bracket to the stove with the other M5x12 screw.
  • Page 29 Mounting of the stones for Juno 120 L Step 5 Step 4 STEP 5. To mount the right front stone in the bottom row. Place the bracket (4710108sv) on the stone. Place the bracket and stone on the bot- tom plate, and fix the bracket to the stove with the M5x12 screws.
  • Page 30 Mounting of the stones for Juno 120 L STEP 6. TOP OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on the bottom of the top stone. Plase the steel bracket 4310115 in the slit in the top plate, and place the small part of the top plate on the bracket.
  • Page 31 Mounting of the stones for Juno 120 L STEP 6. BACK OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on the bottom of the top stone.

  • Page 32: Mounting Of The Stones For Juno 120 L G

    4718610 Juno 120 L G Mounting of stones Mounting of the stones for Juno 120 L G STEP 1. To mount the side stones in the bot- tom row. Place the stones over the pins, on the bottom plate of the stove. Place the...
  • Page 33 Mounting of the stones for Juno 120 L G STEP 2. To mount the back stones in the bottom row. Place the stones on the pins on the bottom plate as shown. Fix the stones in the top, by inser- ting the four pins through the steel ring.
  • Page 34 Mounting of the stones for Juno 120 L G STEP 3 - TOP OUTLET ep 2 Step 3 To mount the rear stones in the middle row. Place the back stones (4717008) over the pins in the lower steel ring. Place the steel bracket (4740101sv) on top of the burning chamber, fixing the stones.
  • Page 35 Mounting of the stones for Juno 120 L G 4730116sv STEP 3 - BACK OUTLET 4740101sv To mount the rear stones in the middle row. Step 3 Place the two back stones (4717004 & 4717005) over the pins in the lower steel ring, Fix them to the bottom ring with the locking brackets (4710111) by loosening the M5 Hex bolt then slide the locking brackets down into the slits in the bottom ring.
  • Page 36 Mounting of the stones for Juno 120 L G Step 3 Step 4 STEP 4. 717009 To mount the left front stone in the bottom row. 4717010 Fix the bracket (4710115) to the bracket (4710103sv) with the M5x12 screw, and place 4730116sv them on the stone.
  • Page 37 Mounting of the stones for Juno 120 L G Ø8 Pin Step 5 Step 4 STEP 5. To mount the right front stone in the bottom row. Place the bracket (4710108sv) on the stone. Place the bracket and stone on the bot- tom plate, and fix the bracket to the stove with the M5x12 screws.
  • Page 38 Mounting of the stones for Juno 120 L G STEP 6. TOP OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on the bottom of the top stone. Plase the steel bracket 4310115 in the slit in the top plate, and place the small part of the top plate on the bracket.
  • Page 39 Mounting of the stones for Juno 120 L G STEP 6. BACK OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on Step 6 the bottom of the top stone.

  • Page 40: Mounting Of The Stones For Juno 160 L

    Mounting of the stones for Juno 160 L 4718606 STEP 1. Juno 160 L Step 1 To mount the bottom side stones in the bottom row. Place the stones over the pins, on the bottom plate of the stove. Place the steel brackets on the stones and put in the Ø8 pins.
  • Page 41 Step 2 Step 1 Mounting of the stones for Juno 160 L STEP 2. To mount the back stones in the bottom row. Place the stones on the pins on the bottom plate as shown. Fix the stones in the top, by inser- ting the four pins through the steel ring.
  • Page 42 Mounting of the stones - Juno 160 L STEP 3 - TOP OUTLET To mount the stones in the middle row. Step 2 Step 3 Place the side stones (4717007) over the pins in the lower steel ring, place the steel bracket (4710101sv) on top of the burning chamber to fix the stones.
  • Page 43 Mounting of the stones - Juno 160 L STEP 3 - BACK OUTLET To mount the stones in the middle row. Place the two back stones (4717004 & 4717005) over the pins in the lower steel ring, Fix them to the bottom ring with the locking brackets (4710111) by loosening the M5 Hex bolt then slide the locking brackets down into the slits in the bottom ring.
  • Page 44 Mounting of the stones - Juno 160 L STEP 4. To mount the left front stone in the bottom row. Fix the bracket (4710115) to the bracket (4710103sv) with the M5x12 screw, and place Step 4 Step 3 them on the stone. Place the bracket and stone on the bottom plate, and fix the bracket to the stove with the other M5x12 screw.
  • Page 45 4710101sv Ø8 Pin Mounting of the stones - Juno 160 L 4717007 STEP 5. Step 5 Step 4 To mount the right front stone in the bottom row. Place the bracket (4710108sv) on the stone. Place the bracket and stone on the bot- Ø8 Pin tom plate, and fix the bracket to the stove with the M5x12 screws.
  • Page 46 Mounting of the stones - Juno 160 L Step 6 Step 4 Step 5 STEP 6. 4710107sv 4717008 To mount the back stones in the top row. Step 6 Step 5 4717012 Mount the bracket (4710116sv) to the stove with the four M5x10 screws.
  • Page 47 Mounting of the stones - Juno 160 L Step 6 Step 5 Step 4 Step 7 STEP 7. 4710107sv To mount the side and front stones in the top row. 4717012 Place the side and front stones on the pins in the steel bracket. Fix the stones with the steel bracket (4710106sv) 4717009...
  • Page 48 Mounting of the stones - Juno 160 L STEP 8. TOP OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on the bottom of the top stone. Plase the steel bracket 4310115 in the slit in the top Step 8 plate, and place the small part of the top plate on the bracket.
  • Page 49 Mounting of the stones - Juno 160 L STEP 8. BACK OUTLET To mount the top stone. Place the top stone on the two guiding bolts on the steel bracket using the holes on the bottom of the top stone. Step 8 4717001 Guides for top plate...
  • Page 50 Mounting of the stones - Juno 160 L G STEP 1. To mount the bottom side stones in the bottom row. 4718604 Step 1 Place the stones over the pins, on the Juno 160 L G bottom plate of the stove. Place the steel brackets on the stones and fix the brackets to the stove with the two screws.
  • Page 51 Mounting of the stones - Juno 160 L G Step 2 STEP 2. To mount the back stones in the bottom row. Place the stones on the pins on the bottom plate as shown. Fix the stones in the top, by inser- ting the four pins through the steel ring.

  • Page 52: Mounting Of The Stones For Juno 160 L G

    Mounting of the stones - Juno 160 L G STEP 3 - TOP OUTLET To mount the stones in the middle row. Place the backstones (4717008) over the pins in the lower steel ring, place the steel Step 3 bracket (4720101sv) on top of the combustion chamber. Make sure the bracket is engaged on both contact surfaces.
  • Page 53 Mounting of the stones - Juno 160 L G STEP 3 - BACK OUTLET To mount the stones in the middle row. Place the two back stones (4717004 & 4717005) over the pins in the lower steel ring, Fix them to the bottom ring with the locking brackets (4710111) by loosening the M5 Hex bolt then slide the locking brackets down into the slits in the bottom ring.
  • Page 54 Mounting of the stones - Juno 160 L G STEP 4. To mount the left front stone in the bottom row. 717006 Step 4 Fix the bracket (4710115) to the bracket (4710103sv) with the M5x12 screw, and place them on the stone. Place the bracket and stone on the bottom plate, and fix the bracket to the stove with the other M5x12 screw.
  • Page 55 4717009 Mounting of the stones - Juno 160 L G STEP 5. To mount the right front stone in the bottom row. Place the bracket (4710108sv) on the stone. Place the bracket and stone on the bot- Step 5 tom plate, and fix the bracket to the stove with the M5x12 screws. 4717006 4717006 M5x12 screws...
  • Page 56 4720102sv Mounting of the stones - Juno 160 L G 4717009 Socket low head 4717011 STEP 6. 4717010 To mount the back stones in the top row. Mount the bracket (4710116sv) to the stove with the four M5x10 Step 6 screws.
  • Page 57 Mounting of the stones - Juno 160 L G 4717011 STEP 7. 4717010 To mount the side and front stones in the top row. Place the side and front stones on Step 7 the pins in the steel bracket. Fix the stones with the steel bracket (4710106sv) 4710106sv...
  • Page 58 Mounting of the stones - Juno 160 L G STEP 8. TOP OUTLET To mount the top stone. Place the top stone on the three guiding bolts on the steel bracket using the holes on the bottom of the top stone. Plase the steel bracket 4310115 in the slit in the top plate, and place the small part of the top plate on the bracket.
  • Page 59 Mounting of the stones - Juno 160 L G 4717006 STEP 8. BACK OUTLET To mount the top stone. Place the top stone on the three guiding bolts on the steel bracket using the holes on the bottom of the top stone. Step 8 4710106sv 4717009...

  • Page 60: Air Inlet Cover

    Air inlet cover 4718605 The air inlet cover is not mounted at delivery, and needs to be mounted. when the stones are mounted, the air inlet cover can be mounted with the two delivered M5x12 screws. 4710113 M5x12...

  • Page 61: Alternate Top Plate Location

    Alternate top plate location The top plate can be mounted without a gap between the top plate and the wood burning stove, if no convection dampers are mounted on the wood burning stove. DO NOT REMOVE ALL THE SCREWS AT ONCE Remove the top plate and then loosen one of the 3 screws (1) remove the bushing (2), reposition the screw (1)
  • Page 62 Brændeovne m sideruder; Juno 120 L G, Juno 120 L G CA, Juno 120 L G Classic, Juno 120 L G Classic CA, Juno 160 L G, Juno 160 L G CA, Juno 160 L G Classic, Juno 160 L G Classic CA Brændeovne uden sideruder;...
  • Page 64 SPARE PART LIST JUNO L xx: optional colour code POS. Item number Title 1712090 Glass door - Single glass 17121XX Classic door - Single glass 61-00 Flue collar 6” 7301026 BA 1 spring 1711890 Locking mechanism - Top 1711891 Locking mechanism - Bottom 1712200 Skamol set 1313800...
  • Page 65 SPARE PART DRAWING JUNO L...
  • Page 66 SPARE PART LIST JUNO L G xx: optional colour code POS. Item number Title 1711090 Glass door - Double glass 17111XX Classic door - Double glass 61-00 Flue collar 6” 7301026 BA 1 spring 1711890 Locking mechanism - Top 1711891 Locking mechanism - Bottom 1313800 Shaking grate...
  • Page 67 SPARE PART DRAWING JUNO L G...
  • Page 68 SOAPSTONE SET JUNO 160 L BACK OUTLET Soapstone set Juno 160 L B/O - 471700001 Mounting kit Juno 160 L - 4717501XX xx: optional colour code...
  • Page 69 SOAPSTONE SET JUNO 160 L TOP OUTLET Soapstone set Juno 160 L T/O - 471700002 Mounting kit Juno 160 L - 4717501XX xx: optional colour code...
  • Page 70 SOAPSTONE SET JUNO 160 L G BACK OUTLET Soapstone set Juno 160 L G B/O - 472700001 Mounting kit Juno 160 L G - 4717502XX xx: optional colour code...
  • Page 71 SOAPSTONE SET JUNO 160 L G TOP OUTLET Soapstone set Juno 160 L G T/O - 472700002 Mounting kit Juno 160 L G - 4717502XX xx: optional colour code...
  • Page 72 SOAPSTONE SET JUNO 120 L BACK OUTLET Soapstone set Juno 120 L B/O - 473700001 Mounting kit Juno 120 L G - 4717503XX xx: optional colour code...
  • Page 73 SOAPSTONE SET JUNO 120 L TOP OUTLET Soapstone set Juno 120 L T/O - 473700002 Mounting kit Juno 120 L G - 4717503XX xx: optional colour code...
  • Page 74 SOAPSTONE SET JUNO 120 L G BACK OUTLET Soapstone set Juno 120 L G B/O - 474700001 Mounting kit Juno 120 L G - 4717504XX xx: optional colour code...
  • Page 75 SOAPSTONE SET JUNO 120 L G TOP OUTLET Soapstone set Juno 120 L G T/O - 474700002 Mounting kit Juno 120 L G - 4717504XX xx: optional colour code...
  • Page 76 POSITIV OUTLINE NEGATIV RAIS A/S ATTIKA FEUER AG Industrivej 20 Brunnmatt 16 DK-9900 Frederikshavn CH-6330 Cham Denmark Switzerland www.rais.com www.attika.ch...
  • Page 77 Juno 160 L Juno 120 L INSTALLATION MANUAL (UK)
  • Page 78 Dato Tekst 11-07-2022 Tegning 4718606 rettet. 25-10-2022 Reservedelstegninger tilføjet. 12-12-2022 Nye CE labels med UKCA tilføjet 01-05-2023 Test institute changed to KIWA...
