P-XX1595
ISSUE 1
RAVEL 1500 & 1720 MEDIA WALL BF
ROOM SEALED GAS LOG FIRE
USER INSTRUCTIONS
INSTALLATION INSTRUCTIONS
SERVICE INSTRUCTIONS
Do not use this appliance if the front glass panel is broken, removed or fi ed incorrectly.
This product is designed to be installed into a false chimney breast or wall
to create a media wall feature in the home.
It is a regula on that these instruc ons be handed to the customer a er installa on is
complete. It is also the responsibility of the installa on engineer to ensure that the customer is
Model number: F-171XX2 SLIDE For use on Natural Gas (G20) at a supply pressure of 20 mbar in GB/IE
THIS INSTRUCTION MANUAL MUST BE LEFT
WITH THE CUSTOMER AFTER INSTALLATION
