3.3

Technical Specifications

The design and implementation of the SRCZCRX controller minimizes electromagnetic
emissions, susceptibility to radio frequency energy, and the effects of electrostatic discharge.
The SRCZCRX controller carries the CE mark, C-Tick mark, FCC Self-Certification logo,
Canadian Compliance Statement, Korean MIC, Taiwan BSMI, and Japan VCCI, and they
meet the requirements of CISPR Class B.
3.3.1

Storage Adapter Specifications

Table 3-3 lists the specifications for the SRCZCRX controller.
Table 3-3
Specification
Processor (PCI Controller) Intel GC80321 64-bit RISC processor @ 400 MHz
Operating Voltage
Card Size
Array Interface to Host
PCI Bus Data Transfer
Rate
Serial Port
SCSI Controller(s)
SCSI Bus Termination
Termination Disable
Cache Configuration
Memory on board
(DIMMs)
Size of Flash ROM for
Firmware
Nonvolatile Random
Access Memory (RAM)
Technical Specifications

Storage Adapter Specifications

Description
3.3 V, 5 V, +12 V, -12 V
Low-profile, half-length PCI adapter card size (6.6" X 2.536")
MROMB-enabled slot
Up to 1023 Mbytes/second at 64-bit/133 MHz (theoretical maximum)
3-pin RS232C-compatible connector (for manufacturing use only)
Utilizes the LSI Logic* 53C1020 or LSI Logic 53C1030 SCSI controller
on the server board
Active, single-ended or LVD
Automatic through cable and device detection
Integrated 64-bit 128 Mbyte PC 200 DDR SDRAM
128 Mbyte
1 Mbyte flash ROM
32 Kbyte for storing RAID configuration
25
