Table 3-1Intel RAID Controller SRCZCRX Headers and Connectors (Cont.)
Connector Description
3.2

Intel RAID Controller SRCZCRX Characteristics

The SRCZCRX controller ensures data integrity by intelligently validating the compatibility
of the SCSI domain. The storage adapter uses Fusion-MPT architecture that allows for
thinner drivers and better performance.
Table 3-2 shows the general characteristics for the SRCZCRX controller.
Table 3-2
1. For boot code and firmware
2. For BIOS configuration storage
Intel RAID Controller SRCZCRX Characteristics
J3 Universal Asynchronous
Receiver/Transmitter (UART)
debugging
J4 Mode select
J5 Clear NVRAM
J6 Write-pending Indicator (dirty
cache) LED
J7 Onboard BIOS disabled
J8 Serial EEPROM
J9 Non-maskable interrupt (NMI)

Storage Adapter Characteristics

Flash Serial LVD/SE
1 2
ROM EEPROM Signaling
Yes Yes 16-bit SE
or LVD
interfaces
Type
3-pin connector
2-pin connector
2-pin connector
2-pin header
2-pin header
2-pin connector
2-pin connector
Ultra320 SCSI
Data Transfers
Up to 320 Mbytes/s as well
as Fast, Ultra, Ultra2, and
Ultra160 speeds;
Synchronous offsets up to
62.
Comments
Reserved
Reserved
Used to clear the contents of the
non-volatile random access memory
(RAM)
Connector for an LED mounted on
the system enclosure. THe LED
indicate when data in the cache has
not been written to the storage
devices.
Disables the BIOS so it will not run
on the firmware. When no jumper is
installed (default), the BIOS is
enabled. When jumpered, the BIOS
is disabled.
Provides board information, such as
the serial number, OEM number,
revision number, and manufacturing
data, eliminating the need to open
the server chassis to obtain this
board information.
Reserved
SCSI
Features Termination
Plug n Play Active, Single
Scatter/Gather Ended, or LVD
Activity LED
