3.2

Intel RAID Controller SRCU42X Characteristics

Table 3-2 shows the general characteristics for the SRCU42X controller.
Table 3-2
1. For boot code and firmware
2. For BIOS configuration storage
3.3

Technical Specifications

The design and implementation of the SRCU42X controller minimizes electromagnetic
emissions, susceptibility to radio frequency energy, and the effects of electrostatic discharge.
The SRCU42X controller carries the CE mark, C-Tick mark, FCC Self-Certification logo,
Canadian Compliance Statement, Korean MIC, Taiwan BSMI, and Japan VCCI, and they
meet the requirements of CISPR Class B.
3.3.1

Storage Adapter Specifications

Table 3-3 lists the specifications for the SRCU42X controller.
Table 3-3
Specification
Processor (PCI
Controller)
Operating Voltage
Card Size
Array Interface to
Host
PCI Bus Data
Transfer Rate
Serial Port
SCSI Controller(s)
SCSI Connectors
SCSI Bus
Termination
Intel RAID Controller SRCU42X Characteristics

Storage Adapter Characteristics

Flash Serial LVD/SE
1 2
ROM EEPROM Signaling
Yes Yes 16-bit SE
or LVD
interfaces

Storage Adapter Specifications

Description
Intel GC80321 64-bit RISC processor @ 400 MHz
3.3 V, 5 V, +12 V, -12 V
Half-length PCI Adapter card size (6.875" X 4.2")
PCI Rev 2.2,
PCI-X Rev 1.0a
Up to 1064 Mbytes/s at 64-bit/133 MHz
3-pin RS232C-compatible connector (for manufacturing
use only)
One LSI* 53C1030 Dual SCSI controller
Two 68-pin internal high-density connectors for SCSI
devices. Two very high-density 68-pin external
connectors for Ultra320 and Wide SCSI.
Active, single-ended or LVD
Ultra320 SCSI
Data Transfers
Up to 320 Mbytes/s as well
as Fast, Ultra, Ultra2, and
Ultra160 speeds;
Synchronous offsets up to
62.
SCSI SCSI
Features Termination
Plug n Play Active, Single
Scatter/Gather Ended, or LVD
Activity LED
27
