10-2 Rear Panel's Inputs/Outputs

Terminals
During
CAM SW OUT
recording
Camera switching
During
signal output
standby
ALARM IN
Alarm signal input
ALARM RST IN
Alarm signal reset
input
ALARM REC OUT
Alarm recording
mode signal output
Record mode:
TAPE END OUT
repeat recording ON/auto rewind ON
Tape end signal
output
WARNING OUT
Warning signal
output
CLOCK RESET IN
Clock reset input
CLOCK RESET
OUT
Clock reset output
SERIES REC IN
Series recording
signal input
SERIES REC OUT
Series recording
signal output
SERIES REC IN
External automatic
recording signal input
Signal levels
(Timelapse recording)
1 field
5m sec
GND
Camera switching signal output
Min. 400 msec.
Min. 400 msec.
Alarm
Record mode
HV: 12 V
LV: 0 V
Max. 10 mA
About 2
seconds
Warning
About 100 msec.
About 100 msec.
2.5 - 3 sec.
2.5 - 3 sec.
External recording
Min. 400 msec.
The switching interval
can be set to "1 field"
or "1 frame" with the
<CAMERA SW> in the
<IN/OUT> setting
screen.
(With the menu switch
Time set to "1 field")
HV: 5 V
LV: 0 V
HV: 5 V ~ 12 V
HV:12 V
(output impedance: 4.7 kohms)
Record mode:
repeat recording OFF/auto rewind OFF
Manual
Tape end
operation
HV: 12 V
(output impedance: 4.7 kohms)
Warning reset
HV: 5 V
LV: 0 V
LV: 0 V
HV: 5 V
LV: 0 V
HV: 5 V
LV: 0 V
HV: 5 V
Remarks
Open-collector
output
Input at ground
level
Input at high
level
Output at high
level
Output at ground
level
Output at high
level
Input at ground
level
Output at ground
level
Input at ground
level
Output at ground
level
Input at ground
level
