9 OPTIONAL SA-K97U RS-232C INTERFACE BOARD
After transmitting the VISS SEARCH command (18), transmit the appropriate 2-byte numeric data (from 30H to 39H), the data input command
(40H), and either FF (ABH) or REW (ACH). All commands should be transmitted separately one byte at a time with "ACK" (0AH) confirmation
from the VCR after each transmission. * Execute in the Stop mode.
(18) VISS SEARCH (B3H)
The VCR starts search after returning "ACK". When the specified point is reached, the VCR returns COMPLETION (01H). If the end or
beginning of the tape is reached before the specified point, the VCR returns NOT TARGET (05H).
This command differs from commands (16) and (17) only in that the FF (ABH) or REW (ACH) command is included separately.
2 VCR setting commands
Commands available include control of recording/playback mode setting, timelapse VCR operation mode setting, date and time setting, timer
programming, on-screen setting, and others.
5 Recording/playback mode setting commands
Two commands are available. One allows you to rotate through recording/playback modes, the other permits you to directly select the
mode.
(1) MODE SHIFT (7DH) : Switches from one recording/playback mode to the next each time the command is transmitted. Use the TL
STATUS SENSE (D6H) command to check the current mode.
Transmit 1 byte at a time with "ACK" (0AH) confirmation from the VCR after each transmission.
(2) MODE (7EH) : Sets recording/playback mode directly.
After transmitting this command, transmit the appropriate 2-byte ASCII codes (from 30H to 39H) and the data
input command (40H). Correspondence of ASCII codes with recording/playback modes is as shown below.
Eg: To set to "24H".
TXD
7EH 31H
0AH
RXD
5 Timelapse VCR operation mode setting commands
(1) TL STATUS SET (86H)
1st byte
BIT When the bit is "1"
0 Repeat recording function ON
1 Unused
2 POWER ON REC mode ON
3 Auto rewind ON
4 Unused
5 Series recording function ON
6 Tape end buzzer ON during recording
7 Alarm recording buzzer ON
3rd byte
BIT When the bit is "1"
0 Unused
1 Summer time compensation ON
2 Unused
3 Unused
4 HDR mode ON
5 Auto record check function ON
6 Unused
7 Unused
: To search for a designated alarm-input point on the tape.
36H 40H
0AH 0AH 0AH
: Set the timelapse VCR operation mode with 3-byte data. Send one byte at a time by checking
ACK (0AH) from the VCR.
TXD 86H 1st byte
0AH
RXD
• The setting details for the first to the third bytes are shown below.
Mode 1st byte
2H 30H
6H 30H
Time
24H 31H
48H 30H
72H 30H
120H 30H
168H 30H
240H 30H
480H 31H
960H 31H
2nd byte
0AH 0AH
2nd byte
BIT When the bit is "1"
0 Unused
1 Alarm recording function ON
2 Unused
3 Sensor recording function ON
4 External recording function ON
5 Unused
6 Unused
7 Warning buzzer ON
2nd byte
30H
31H
36H
34H
35H
37H
38H
39H
31H
33H
3rd byte
Time
0AH
