5 PREPARATION

5-2 Recording/Playback Speed Mode Selection

REC STOP REC
CHECK
REW REVERSE PAUSE PLAY FF
TRACKING
+
–
FIELD REV FIELD ADV
[HDR] indicator
1
Press the [OPERATE] button to turn the operating mode on.
2
Select whether or not the HDR mode is engaged with the <HDR> menu switch on the <VTR MODE> screen. When the
During HDR recording or HDR playback, the [HDR] indicator lights.
3
Select the Record or Playback speed with the [TIME MODE +/–] button. Refer to the table below.
The selected recording or playback speed mode is shown on the display.
• Available modes differ depending on whether HDR is ON or OFF.
Recording/playback
Display
interval (sec.)
HDR OFF
2H —
6H —
24H 0.2
48H 0.4
72H 0.6
120H 1
168H 1.4
240H 2
480H 4
960H 6
• HDR ON/OFF can be activated in any recording mode except the 2H/6H mode.
• Available recording time may vary depending on the type of cassette used.
• For best results, use a T-120 tape.
• Replace the cassette at least once every 15 days when using the 2H - 168H modes. In the 240 - 960H modes,
replace the cassette with a new one at the completion of recording.
High-Density Recording
HDR is performed with the EP heads. When HDR is set to "OFF", recording is performed with the SP heads.
In the HDR mode, the interval between frames (fields) is reduced by about a third, allowing three 3 times as many frames
to be recorded as in the ordinary timelapse mode. This does not affect the actual recording time of the tape (the recording
time is the same as it would be if recorded in the normal (SP) Timelapse mode).
The quality of the picture recorded in the HDR mode is inferior to that in ordinary timelapse recording (equivalent to the EP
mode).
28
OPERATE
HDR
RESET/
CANCEL ON SCREEN
SHIFT
V. LOCK TIMER SEARCH DISPLAY LOCK CNT RESET MENU TIME MODE
+
– – S E T +
[TIME MODE +/–] buttons
Mode
HDR ON
— Standard (SP)
— 3x (EP)
0.08 24-hour timelapse
0.15 48-hour timelapse
0.2 72-hour timelapse
0.35 120-hour timelapse
0.5 168-hour timelapse
0.7 240-hour timelapse
1.35 480-hour timelapse
2.7 960-hour timelapse
SR-9090U
REC
EJECT OPERATE
Available recording
time (hours)
T-30
T-60
0.5 1
1.5 3
6 12
12 24
18 36
30 60
48 96
60 120
120 240
240 480
Record/playback speed
indication
Audio
recording
T-90 T-120
1.5 2 Possible
4.5 6 Possible
18 24 Impossible
36 48 Impossible
54 72 Impossible
90 120 Impossible
144 168 Impossible
180 240 Impossible
360 480 Impossible
720 960 Impossible
