Summarization of Contents
Safety Information
General Safety Precautions
Read and follow all safety precautions before installing, operating, or servicing. Ensure understanding of warnings.
Lamp Fitting
Lamp Assembly Procedure
Guidance on fitting lamps using M10 bolts, washers, and locking nuts. Fit top bolts first.
Rain Protection Housing Fitting
Housing Installation
Instructions for fitting the rain protection housing using M8 hardware. Ensure seals are intact.
Lamp Fitting When Using Rain Protection Housing
Integrated Lamp Fitting
Steps for fitting lamps with the rain protection housing installed, including panel removal.
Rain Protection Housing Effective Tilt Range
Tilt Angle Limitations
Details the maximum 50° forward tilt for the unit and precautions for severe conditions.
Vinyl Covers
Vinyl Cover Application
Instructions on correctly fitting vinyl covers to create a seal and options for removal.
Rigging Options - Brute Force 6
Suspension Requirements
Mandates at least two points of suspension and the use of secondary safety precautions.
Rigging Options - Brute Force 4
Spigot/Pin Mounting Safety
Emphasizes secondary safety and warns against excessive side loading on suspension spigots.
Fan Unit - Connection
Fan Unit Wiring
Procedure for connecting the fan unit, including disconnecting power and replacing the back panel.
Brute Force 6 Connection Options
Three Mains Feed (115V) RGBW
Connection diagram for three mains feeds, 115V, RGBW X1 (384 Channels), with cable options.
Brute Force 6 Connection Options
Three Mains Feed (115V) CineQ 8bit
Connection diagram for three mains feeds, 115V, CineQ 8bit X1 (512+256 Channels), with cable options.
Brute Force 6 Connection Options
Two Mains Feed (230V) RGBW
Connection diagram for two mains feeds, 230V, RGBW X1 (384 Channels), with cable options.
Brute Force 6 Connection Options
Two Mains Feed (230V) CineQ 8bit
Connection diagram for two mains feeds, 230V, CineQ 8bit X1 (384+384 Channels), with cable options.
Brute Force 4 Connection Options
115V Feed CineQ/RGBW
Connection diagram for 115V feed, CineQ 8bit (512) & RGBW X1 (256 Channels), with cable options.
Brute Force 4 Connection Options
230V Feed CineQ 8bit
Connection diagram for 230V feed, CineQ 8bit X1 (512 Channels), with cable options.
Disclaimer
Product Use and Warranty
Information on product accuracy, warranty, and potential alterations due to R&D.
