ROSE DISPLAYS SPIDER RING Instruction Sheet

Spider Ring™

Parts

Instructions for assembly

Important note:

Spider Rings can be attached before or after
suspending sign. If the rings need to be posi-
tioned out of reach, or if more than two cable
wraps are required per ring, wrap the cable
around the rings before sign is hung.

Step 1

Place Spider Ring onto the cable. The cable
goes inside the ring's outer groove. Fig. 1

Step 2

With the cable inside the groove, wrap it once
around the ring. Fig. 2

Step 3

While holding the ring, pull down on
cable until it pops into the groove. Fig. 3
Repeat steps 1-3 for multiple wrappings.
Note: Each wrap shortens the cable by 3".
Maximum of 6 wraps or 18" per Spider Ring.
Multiple rings can be used on each cable for
more adjustability.

Step 4

Repeat steps 1-3 for each cable used to hang
your sign.

Step 5

Slide the Spider Rings up and out of view. Fig 4
& 5. Note: To lengthen cable, unwind one
or more wraps from each Spider Ring.
The Spider Ring™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSSpiderRing
Incept-2.5.02
Spider Ring
16-0018R
Instruction Sheet
Figure 1
Figure 3
Figure 2
Figure 4
Figure 5
