ROSE DISPLAYS ANOFRAME SQUARE WITH NO HANGING Manual

AnoFrame

Parts

Instructions For assembly

Step 1

Insert corner brackets into vertical
AnoFrame sides. Fig. 1 & Fig. 2.
Note: Assembly brackets tension
tabs face towards outside of frames.
Split rail side is made up of 2 separate
pieces.

Step 2

Assemble frame following steps in
Fig. 3 sliding sides together in the
order shown.

Step 3

Insert poster. Fig 4.
Note: The AnoFrame shown here is
a square profile. It is available in
either square or round profile.
The AnoFrame is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameSQNoHanging
Revised 8.15.02
TM
Square Profile Instruction Sheet
Corner AnoFrame Rail
Brackets
AnoFrame
12AF-100
Figure 1
solid rail
solid rail
Figure 3
Split Rail
Figure 2
Figure 4
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
