AnoFrame™

Parts

Instructions For Hanging

Step 1

Locate the two split rails and the
solid rail that is the same length as
the split rails.
Insert corner brackets into side
AnoFrame rails. Insert two corner
brackets into each end of the solid
side Ano rail. Insert one corner
bracket into each end of each split
side Ano rail. Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.

Step 2

Finish assembling frame by follow-
ing sequence in Fig. 3.

Step 3

Install wall mounting hangers using
a Phillips head screwdriver. A
plastic expansion anchor is sug-
gested for drywall installations.
Fig. 4

Step 4

Slide AnoFrame onto wall mount-
ing hangers. Fig 5. Insert poster.
Note: The AnoFrame shown here
is a round profile. It is available
in either square or round profile.
The AnoFrame is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameWallHangers
Incept-8.15.02
Round Profile Instruction Sheet
Corner
Brackets
AnoFrame
AnoFrame Rails
Split Rails
12AF-100
Figure 1
solid rail
solid rail
Figure 3
Wall Mounting
Hangers
06-6067
Figure 2
Figure 4
Figure 5
