Instruction Manual and Parts List
for Portable Compressors
XA186 Dd
XAS186 Dd
XATS156 Dd
Instruction manual for portable compressors
XAHS146 Dd
XAVS136 Dd
................................................................................
ATLAS COPCO – PORTABLE AIR DIVISION
B-2630 AARTSELAAR BELGIUM
PAGE
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XATS156 Dd and is the answer not in the manual?

Questions and answers

Related Manuals for Atlas Copco XATS156 Dd

Summary of Contents for Atlas Copco XATS156 Dd

  • Page 1 Portable Compressors XA186 Dd XAHS146 Dd XAS186 Dd XAVS136 Dd XATS156 Dd PAGE Instruction manual for portable compressors ................Registration code Collection: Tab: Printed matter N¡ ATLAS COPCO – PORTABLE AIR DIVISION 2950 1122 00 EN B-2630 AARTSELAAR BELGIUM 1998 -12...
  • Page 2 XAS136/186 Dd...

  • Page 3: Table Of Contents

    NSTRUCTION ANUAL Congratulations on the purchase of your Atlas Copco compressor. It is a solid, safe and reliable machine, built according to the latest technology. Follow the instructions in this booklet and we guarantee you years of troublefree operation. Please read the following instructions carefully before starting to use your machine.
  • Page 4 XAS136/186 Dd ONTENTS ONTENTS 4. Maintenance 6. Problem solving ..............................................Use of service paks Alternator precautions ................................Preventive maintenance schedule for the compressor ..................7. Available options Lubrication oils ........................................Oil level check .................... 4.4.1 Check engine oil level ................

  • Page 5: Safety Precautions For Portable Compressors

    In addition, a warning sign bearing a legend such as ãwork in progress; do not startÒ shall be attached to the starting The policy of Atlas Copco is to provide the users of their equipment with safe, equipment. On engine-driven units the battery shall be disconnected and reliable and efficient products.

  • Page 6: Ð Safety During Use And Operation

    Never play with compressed air. Never apply it to your skin or direct an AFETY DURING USE AND OPERATION air stream at people. Never use it to clean dirt from your clothes. When using it to clean down equipment, do so with extreme caution and use eye To lift a unit, all loose or pivoting parts, e.g.

  • Page 7: Ð Tool Applications Safety

    Support the drawbar and the axle(s) securely if working underneath the PECIFIC SAFETY PRECAUTIONS unit or when removing a wheel. Do not rely on jacks. Make sure that no tools, loose parts or rags are left in or on the unit. Batteries 10 Before clearing the unit for use after maintenance or overhaul, check that The electrolyte in batteries is a sulphuric acid solution which is fatal if it...

  • Page 8: Ð Safety Valve

    11 For maximum safety and efficiency of the lifting apparatus all lifting Draining of condensate shall be performed regularly when vessel is in members shall be applied as near to perpendicular as possible. If required, use. a lifting beam shall be applied between hoist and load. Installation, design and connections should not be changed.

  • Page 9: Leading Particulars

    7 bar The new braking system consists of an integrated parking brake and (non-silenced version XA186 Dd). The XATS156 Dd is built for a nominal effective working pressure of overrunbrake. When driving backwards the overrunbrake is not 10.3 bar.

  • Page 10: Markings And Information Labels

    Read the instruction manual before starting. Danger, heat flat. Service every 24 hours. Warning ! Electrocution hazard. Part under pressure. Atlas Copco compressor oil. Do not stand on outlet valves. PAROIL M PAROIL Atlas Copco engine oil. Start-Stop indication of switch.

  • Page 11: Main Parts

    NSTRUCTION ANUAL ARTS Fig. 2.2 Main parts of XAS136/186 Dd (adjustable towbar, brakes and roadsignalisation are options) Alternator Oil Filter (engine) Air Filter (compressor element) Filler Cap (engine oil) Oil Level Gauge Air Filter (engine) Prop Filler Cap (fuel tank) Regulating Valve Air Outlet Valves Filler Cap (water)

  • Page 12: Air Flow

    XAS136/186 Dd OMPRESSOR EGULATING YSTEM OAD CONDITION Fig. 2.3 Air filter (compr. element) Check Valve Non Return Valve Speed Regulator Drain Plug Oil Cooler Safety Valve Air filter (engine) Engine Oil Filter Temperature Switch Air Outlet Valves Oil Level Gauge Unloader Assembly Air Receiver Filler Plug...

  • Page 13: Oil System

    NSTRUCTION ANUAL . 2.3) . 2.3) IL SYSTEM ONTINUOUS REGULATING SYSTEM The system comprises: The system comprises: AR/OS Air receiver/oil separator Regulating valve Oil cooler Unloader assembly Oil filter Speed regulator The lower part of the air receiver (AR) serves as oil tank. The compressor is provided with a continuous regulating system.

  • Page 14: Operating Instructions

    XAS136/186 Dd OPERATING INSTRUCTIONS ARKING TOWING AND LIFTING INSTRUCTIONS Safety precautions The operator is expected to apply all relevant safety precautions, including those mentioned on the pages 5 - 8 of this book. Attention: Ð Before putting the compressor in to use, check the brake system Fig.

  • Page 15: Lifting Instructions

    NSTRUCTION ANUAL 3.1.3 L IFTING INSTRUCTIONS EFORE STARTING 1. Before initial start-up, prepare battery for operation if not already done. See section 4.7. 2. With the compressor standing level, check the level of the engine oil. Add oil, if necessary, to the upper mark on dipstick. Consult the Engine Operation Manual for the type and viscosity grade of the engine oil.

  • Page 16: Starting/Stopping

    XAS136/186 Dd TARTING TOPPING H1 H2 H3 H4 0 0 0 0 H7 H8 H5 H6 Fig. 3.8 Control panel Hourmeter LED (green) Preheat (option) Circuit breaker button LED (red) Charge indication Working pressure gauge LED (red) Compressor outlet temperature Loading valve LED (red) Engine coolant temperature...

  • Page 17: Maintenance

    When servicing, replace all disengaged packings, e.g. gaskets, O-rings, washers. Order Service Paks at your local Atlas Copco dealer. For engine maintenance refer to Engine Operation Manual. The maintenance schedule has to be seen as a guideline for units operating in a duty environment typical to compressor applications.

  • Page 18: Lubrication Oils

    XAS136/186 Dd UBRICATION OILS IL LEVEL CHECK It is strongly recommended to use Atlas Copco branded lubrication Never mix oils of different brands or types. oils for both compressor and engine. Use only non-toxic oils where there is a risk of inhaling Mineral compressor oil PAROIL M: delivered air.

  • Page 19: Oil And Oil Filter Change

    (3) frequently. Keep the coolers (1), (2) and (3) clean to maintain the cooling In this case, contact Atlas Copco. efficiency. Steam cleaning in combination with a cleansing agent may be Run the compressor until warm. Close the outlet valve(s) (5) and applied.

  • Page 20: Battery Care

    It guarantees that all necessary parts are replaced at the same time which improves the uptime of the unit. 4.7.2 E LECTROLYTE The order numbers of the Service Kits are listed in the Atlas Copco Parts List (ASL). Read the safety instructions carefully Contact Atlas Copco.

  • Page 21: Adjustments And Servicing Procedures

    NSTRUCTION ANUAL ADJUSTMENTS AND SERVICING PROCEDURES DJUSTMENT OF THE CONTINUOUS REGULATING SYSTEM Fig. 5.1 The working pressure is determined by the tension of the spring in Tabel the regulating valve (RV). This tension can be increased to raise the Z1 Ð Z2 pressure and decreased to lower it by turning the adjusting wheel clockwise and anti-clockwise respectively.

  • Page 22: Air Filter Engine/Compressor

    5.2.2 R ECOMMENDATIONS The air receiver is tested according to official standards. Regularly The Atlas Copco air filters are specially designed for the have inspections carried out in conformity with local regulations. application. The use of non-genuine air filters may lead to severe damage of engine and/or compressor element.

  • Page 23: Fuel System

    NSTRUCTION ANUAL UEL SYSTEM RAKE OPTION ADJUSTMENT Before jacking up the compressor, connect it to a towing vehicle or attach a weight of minimum 50 kg to the towbar. 5.6.1 B RAKE SHOE ADJUSTMENT Check the thickness of the brake lining. Remove both black plastic plugs (5).

  • Page 24: Test Procedure Of Brake Cable Adjustment

    XAS136/186 Dd 5.6.2 T 5.6.3 B EST PROCEDURE OF BRAKE CABLE ADJUSTMENT RAKE CABLE ADJUSTMENT 1. Check if the towing eye rod of the overrun brake mechanism is in the outmost position. 2. Check if the adjustable towbar (= option) is in the actual towing position.

  • Page 25: Problem Solving

    4. Never operate the engine without the main or voltage sensing cables connected in the circuit. AVAILABLE OPTIONS The XA186 Dd, XAS186 Dd, XATS156 Dd, XAHS146 Dd and XAVS136 Dd can be delivered with following options: Vessel type: EURO ASME...

  • Page 26: Technical Specifications

    XAS136/186 Dd TECHNICAL SPECIFICATIONS ORQUE VALUES OMPRESSOR ENGINE SPECIFICATIONS 8.1.1 F OR GENERAL APPLICATIONS Compressor type XAVS136 Dd The following tables list the recommended torques applied for general XAHS146 Dd applications at assembly of the compressor. XATS156 Dd XA(S)186 Dd For hexagon screws and nuts with strength grade 8.8 Designation Unit...

  • Page 27: Conversion List Of Si Units Into British Units

    Manuf. year/Baujahr/Année de fabrication Height 1661 1661 Weight (ready to operate) 1670 1725 MADE BY ATLAS COPCO AIRPOWER n.v. WILRIJK, BELGIUM 1615 6945 00 At reference conditions, if applicable, and at normal shaft speed, unless otherwise stated Data Measured according to Tolerance 11.

  • Page 28: Circuit Diagram

    XAS136/186 Dd CIRCUIT DIAGRAM The compressor is equipped with a negative earthed system. Fig. 10.1 Circuit diagram (Nr. 9822 0893 12) Circuit breaker (10A) Control module Battery Hourmeter Alternator Glowplug Starter solenoid Compressor temperature switch Auxiliary start relay Engine temperature switch Cold start relay Engine oil low pressure switch Starter motor...
  • Page 29 XA(S)186 Dd 5000 A: Altitude Hoogte Altitude 4000 Hšhenlage Altitud 7bar(e) Hšjd 3000 Altitudine H¿yde (mbar) H¿jde over havet 2000 À „fiÌÂÙÚÔ Altitude Korkeus merenpinnasta 1000 1013 T: Temperature Temperatuur Temperature (¡C) Temperature Temperatura Temperatur Temperatura Temperatur Temperatur XATS156 Dd £ÂÚÌÔÎÚ·Û›·˜...
  • Page 30 XAHS146 Dd 5000 A: Altitude Hoogte Altitude 4000 Hšhenlage Altitud 12bar(e) Hšjd 3000 Altitudine H¿yde (mbar) H¿jde over havet 2000 À „fiÌÂÙÚÔ Altitude Korkeus merenpinnasta 1000 T: Temperature 1013 Temperatuur Temperature (¡C) Temperature Temperatura Temperatur Temperatura Temperatur Temperatur XAVS136 Dd £ÂÚÌÔÎÚ·Û›·˜...
