Encore ENH924-AUT User Manual
24-port fast ethernet switch
Hide thumbs
Also See for ENH924-AUT:
- Features (2 pages) ,
- User manual (12 pages) ,
- Specifications (3 pages)
Related Manuals for Encore ENH924-AUT
Summary of Contents for Encore ENH924-AUT
-
Page 1: User Guide
ENH924-AUT 24-Port Fast Ethernet Switch User Guide... - Page 2 FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 3: Unpacking Information
1. Unpacking Information The device is a powerful, high-performance Fast Ethernet switch, with all 24 ports capable of 10 or 100Mbps auto-negotiation operation (NWay), which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode. It is ideal for micro-segmenting large networks into smaller, connected subnets for improved performance, enabling the bandwidth demanding multimedia and imaging applications. -
Page 4: Led Definition
2. LED Definition Please refer to the following table for LED definition 24 Ports 19-inch Model Status Operation Steady Green Power is on Power Power is off Steady Green The port is connected Blinking Green The port is transmitting/receiving Link/Act data. -
Page 5: Network Application
3. Station Connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then system is ready. -
Page 6: Specification
Specification IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX Standard IEEE 802.3x full duplex operation and flow control 24 10/100Mbps RJ-45 Fast Ethernet Interface Ports Auto MDI/MDI-X（Auto crossover） Uplink 10/100Mbps & Full/Half duplex mode Network Speed auto detection MAC Address Table 8K MAC entries Memory 156Kbytes Internal Power supply...
