Encore ENH916P-NWY Specifications

10/100 mbps 16-port switch

General Descriptions

Encore's ENH916P-NWY Fast Ethernet Switch is a full-featured Ethernet Switch that provides

Ethernet direct connection to the local area network or individual PC with built-in 16-port switch. It

uses advanced

chipset solutions with complete set of industry standard features for high-speed

internet access. ENH916P-NWY offers easy installation and cost-effective connection for corporate,

SOHO and residential users.

‧

Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

‧

Supports 16 10/100Mbps auto-detect Half or Full duplex switch ports

‧

Supports IEEE 802.3x Flow Control for Full Duplex modes and back pressure for Half Duplex

mode

‧

Supports automatic address learning and address aging

‧

Embeds 1.5 MB packet buffer

‧

Supports Store & Forward architecture

‧

Supports up to 4,000 MAC Address Table

‧

Supports auto MDI/MDI-X function

ENH916P-NWY

10/100 Mbps 16-PORT SWITCH

Table of Contents

Do you have a question about the ENH916P-NWY and is the answer not in the manual?

Page 1 ENH916P-NWY 10/100 Mbps 16-PORT SWITCH General Descriptions Encore’s ENH916P-NWY Fast Ethernet Switch is a full-featured Ethernet Switch that provides Ethernet direct connection to the local area network or individual PC with built-in 16-port switch. It uses advanced chipset solutions with complete set of industry standard features for high-speed internet access.
Page 2 Applications . High-speed Internet access sharing . Video-On-Demand . Telecommuting . Distance learning . Remote workgroup networking . Corporate LAN access (VPN) . Video conferencing Specifications Data Transfer Rates 10Mbps and 100Mbps IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX Protocol IEEE 802.3x Full Duplex Flow Control Connector RJ-45 x 16 Transmission Method...
