Installation Instructions Original Instructions FLEX I/O EtherNet/IP Adapters Catalog Numbers 1794-AENT, Series B Topic Page Important User Information Environment and Enclosure North American Hazardous Location Approval European Hazardous Location Approval Electrical Safety Considerations Prevent Electrostatic Discharge Special Conditions for Safe Use Overview Install Your Adapter Module Indicators...
Page 2: Important User Information
FLEX I/O EtherNet/IP Adapters Important User Information Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid-state Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid- state equipment and hard-wired electromechanical devices.
Page 3: Environment And Enclosure
FLEX I/O EtherNet/IP Adapters Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in EN/IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is not intended for use in residential environments and may not provide adequate protection to radio communication services in such environments.
Page 4: North American Hazardous Location Approval
FLEX I/O EtherNet/IP Adapters North American Hazardous Location Approval The 1794-AENT, Series B modules are Hazardous Location approved: The Following Information Applies When Informations sur l’utilisation de cet équipement en Operating This Equipment In Hazardous Locations. environnements dangereux. Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne Products marked "CL I, DIV 2, GP A, B, C, D"...
Page 5: European Hazardous Location Approval
FLEX I/O EtherNet/IP Adapters European Hazardous Location Approval The following applies to products marked • Are intended for use in potentially explosive atmospheres as defined by European Union Directive 2014/34/EU and has been found to comply with the Essential Health and Safety Requirements relating to the design and construction of Category 3 equipment intended for use in Zone 2 potentially explosive atmospheres, given in Annex II to this Directive.
Page 6 FLEX I/O EtherNet/IP Adapters WARNING: • This equipment is not resistant to sunlight or other sources of UV radiation. • This equipment shall be mounted in an ATEX Zone 2 certified enclosure with a minimum ingress protection rating of at least IP54 (in accordance with EN 60079-15) and used in an environment of not more than Pollution Degree 2 (as defined in EN 60664-1) when applied in Zone 2 environments.
Page 7: Prevent Electrostatic Discharge
FLEX I/O EtherNet/IP Adapters Prevent Electrostatic Discharge ATTENTION: This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. •...
Page 8: Overview
FLEX I/O EtherNet/IP Adapters WARNING: • If you insert or remove the module while backplane power is on, an electric arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding. •...
Page 9: Install Your Adapter Module
FLEX I/O EtherNet/IP Adapters Component Identification Network cable RJ45 connector (underside) Adapter DIN rail locking tab 24V dc connections 24V common connections Flexbus connector IP address switches Install Your Adapter Module 1794-AENT/B Mount on a DIN Rail Before Installation of the Terminal Base Units 1.
Page 10 FLEX I/O EtherNet/IP Adapters 7. Connect the adapter wiring as shown under Connecting Wiring later in this document. Mount on a Panel or Wall If mounting this adapter to a panel or wall, refer to publication 1794-IN135, Panel Mounting Kit, Cat. No. 1794-NM1/B. Mount or Replace the Adapter on an Existing System 1.
Page 11 FLEX I/O EtherNet/IP Adapters Before installing the new adapter, notice the notch on the right rear of the adapter. This notch accepts the hook on the terminal base unit. The notch is open at the bottom. The hook and adjacent connection point keep the terminal base and the adapter tight together, reducing the possibility of a break in communication over the backplane.
Page 12 FLEX I/O EtherNet/IP Adapters Connect Wiring WARNING: If you connect or disconnect the communication cable with power applied to the adapter or any device on the network, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.
Page 13 FLEX I/O EtherNet/IP Adapters IMPORTANT We recommend connecting the module to the network via a 100 MB full- duplex switch, which will reduce network collisions and lost packets, and increase bandwidth. For detailed Ethernet connection information, see these publications: • Ethernet/IP Performance and Application Guide, publication ENET- AP001 •...
Page 14 FLEX I/O EtherNet/IP Adapters thumbwheel switch. Press the + or - buttons to change the number. Valid settings are 001…254. When the switches are set to a valid number, the IP address of the adapter is 192.168.1.xxx (where xxx represents the number set on the switches). The subnet mask of the adapter is 255.255.255.0 and the gateway address is set to 0.0.0.0.
Page 15: Indicators
FLEX I/O EtherNet/IP Adapters Indicators The faceplate of the 1794-AENT adapter is provided with three bicolor indicators. Module status Network status Link status Module Status Indicators Indicator Status Description Off – Adapter does not have 24V DC power. no power Make sure power is being supplied to the adapter.
Page 16 FLEX I/O EtherNet/IP Adapters Network Status Indicators Indicator Status Description Adapter is not powered, or does not have an IP address. Off – Verify there is power and the adapter is correctly wired not powered, to the power supply. no IP address Make sure the adapter is configured.
Page 17: Specifications
FLEX I/O EtherNet/IP Adapters Specifications FLEX™ I/O EtherNet/IP Adapter - 1794-AENT Attribute Value I/O capacity 8 modules To comply with the CE Low Voltage Directive (LVD), this equipment must be powered from a source compliant with the following: Power supply Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).
Page 18 FLEX I/O EtherNet/IP Adapters FLEX™ I/O EtherNet/IP Adapter - 1794-AENT Attribute Value Power conductors, 0.34…2.5 mm (22…12 AWG) stranded copper wire rated at 75 °C (167 Wire size °F) or higher, 1.2 mm (3/64 in.) insulation max 1 – on power ports Wire category 2 –...
Page 19 FLEX I/O EtherNet/IP Adapters Environmental Specifications Attribute Value IEC 61000-4-2: ESD immunity 6 kV contact discharges 8 kV air discharges IEC 61000-4-3: 10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz Radiated RF immunity 10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz 10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz 3V/m with 1 kHZ sine-wave 80% AM from 2000…2700MHz IEC 61000-4-4:...
Page 20 FLEX I/O EtherNet/IP Adapters Certifications Certifications (when product is Value marked) European Union 2014/34/EU ATEX Directive, compliant with: • EN 60079-0; General Requirements • EN 60079-15; Potentially Explosive Atmospheres, Protection "n" • II3GExnAIICT4Gc Korean Registration of Broadcasting and Communications Equipment, compliant with: •...
Page 21 FLEX I/O EtherNet/IP Adapters Notes: Rockwell Automation Publication 1794-IN082D-EN-P - January 2019...
Page 22 FLEX I/O EtherNet/IP Adapters Notes: Rockwell Automation Publication 1794-IN082D-EN-P - January 2019...
Page 23 FLEX I/O EtherNet/IP Adapters Rockwell Automation Support Use the following resources to access support information. Knowledgebase Articles, How-to Videos, Technical Support www.rockwellautomation.com/ FAQs, Chat, User Forums, and Product knowledgebase Center Notification Updates. Local Technical www.rockwellautomation.com/global/ Support Phone Locate the phone number for your country. support/get-support-now.page Numbers Find the Direct Dial Code for your product.
Page 24 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, FLEX, Rockwell Automation, Rockwell Software and TechConnect are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
