DECKED MG4 Installation Instructions Manual

5'2" or 6' 2” bed length for chevy colorado 2015; chevy colorado2016; chevy colorado2017; gmc canyon 2015; gmc canyon 2016; gmc canyon 2017

Advertisement

Quick Links

CHEVY COLORADO/GMC CANYON
NOTE: Most of the images in these instructions are of the short bed, but they apply to both length beds
• Adjustable wrench (that opens to about 1")
• 1/2" open end wrench
• #2 Phillips screwdriver,
• Short 7/32" hex wrench
• 7/16" deep socket
• 3/8" socket

Installation Instructions:

5'2" or 6' 2" BED LENGTH
TOOLS REQUIRED
MG3 - MG4
2015-CURRENT
• Electric drill
• 9/64" drill bit
• Drill stop
