SUGGESTED SLIDE INSTALLATION
DECKED is providing these instructions as a courtesy to its customers. While DECKED has attempted
to ensure that these instructions are accurate and complete, DECKED makes no warranty whatsoever,
express or implied, and expressly disclaims any implied warranty of merchantability or fitness for a
particular purpose, regarding these instructions, any non-DECKED product referenced in them, or the
integration of a non-DECKED product with the DECKED system. Modifying a DECKED system may void
the applicable warranty. DECKED disclaims any liability related to these instructions. All installations
PROCEDURE
MIDSIZE TRUCKS
are made at the installer's sole risk.
Advertisement
Table of Contents
Related Manuals for DECKED Slide
Summary of Contents for DECKED Slide
- Page 1 PROCEDURE MIDSIZE TRUCKS DECKED is providing these instructions as a courtesy to its customers. While DECKED has attempted to ensure that these instructions are accurate and complete, DECKED makes no warranty whatsoever, express or implied, and expressly disclaims any implied warranty of merchantability or fitness for a particular purpose, regarding these instructions, any non-DECKED product referenced in them, or the integration of a non-DECKED product with the DECKED system.
- Page 2 · 12 — 5/16” washers CAUTION: Ignoring the sealing washers could lead to water intrusion. If you plan on using a tonneau or cap over the slide install, you can omit using the sealing washers as there won’t be a water risk.
- Page 3 Locate steel tube on deck panel that is closest to the cab. Mark center line. NOTE: Dimples indicate location of steel tubes. STEP 4 Center the slide’s cabside bottom frame holes on this line (front-to-back and left-to-right). DECKED | 2...
- Page 4 STEP 5 STEP 6 With cabside slide frame holes centered, drill Check to make sure pilot holes are centered cabside pilot holes with a 3/32” bit. (top and bottom) on steel tube. To insure hole is centered, drill gradually with a series of smaller bits (3/32,”...
- Page 5 STEP 8 Mount the cabside end of the slide frame to deck with two 2” x 5/16” #18 bolts in order shown. BOLT WASHER SLIDE FRAME WASHERS (ENOUGH TO FILL GAP, QUANTITY MAY VARY) SEALING WASHER DECK PANEL STEEL TUBE...
- Page 6 Installing slides on, or making any other modifications to, DECKED systems is entirely at the risk of the installer. We do not recommend using any slide with a capacity >1000lbs, overloading a lower rated slide, or ANY full extension slides.
