STEP 1:
Place rubber pads on bed rails.
(1) per side.
PLACE RUBBER PAD OVER
INSIDE LEDGE OF BED RAIL
STEP 3:
Open the Tool Box lid to be sure it doesn't hit the cab of truck
under any circumstances. Make sure there is adequate
distance between the lid and any cab mounted cameras,
lights or other important bits.
Shift the Tool Box toward the tailgate as needed.
STEP 4:
Install (2) bed rail clamps on each side of the Tool Box using one location as close to the tailgate as possible and one location
as close to the cab as possible. NOTE: Outermost clamp locations vary per vehicle depending on the topology of the bed rails.
Secure clamps with bolts, washers and nuts in order shown. Tighten all four bolts.
Test tightness by closing Tool Box lid and pulling on the handles, L-R and front to back.
Tool Box should not move on the bed rails.
DECKED.COM | 208-806-0251
TOOL BOX INSTALLATION
(2) BOLTS, (2) WASHERS PER SIDE
(OUTERMOST HOLE LOCATIONS
VARY DEPENDING ON VEHICLE)
STEP 2:
Unless you've experienced radiation exposure (allowing
you to mutate into The Hulk) grab a friend to help you lift
the Tool Box into place on top of the rubber pads. Center
the Tool Box L-R between the bed rails and align square
to the bed on both sides.
TEAM LIFT
TEAM LIFT
REQUIRED
REQUIRED:
slide
(2) CLAMPS, (2) NUTS PER SIDE
(OUTERMOST HOLE LOCATIONS
VARY DEPENDING ON VEHICLE)
TOOLS NEEDED:
• 3/8" socket
• Ratchet
WARNING
SHIFT TOOL BOX
AS NEEDED FOR
CAB CLEARANCE
TBFDL | v.1 | Page 1
