DECKED LADDER Installation

CAB
• Rest the folded ladder on a table or hard surface so that you can read the instructions on the bottom of the first rung.
• While holding the top rung, pull the bottom rung from the ladder assembly until both the bottom and middle rungs lock in place.
• Set the ladder on the ground vertically next to the passenger side of your Tool Box.
• Raise both arms and extend them up and over the edge of the Tool Box to meet with the mounting discs.
• Using a 5/32" hex wrench, install the hardware in the order shown, DETAIL A. Repeat on opposite side. Tighten until snug - DO NOT OVERTIGHTEN.
• Return the ladder to the Tool Box by collapsing the rungs and folding back into place.
USING THE LADDER:
STEP 1
"CLICK"
▼ WARNING DON'T DO THIS ▼
FOLLOW US:
DECKED.COM | #DECKEDUSA | @DECKEDUSA
LADDER INSTALLATION
A
STEP 2
PLACE LADDER ON SOLID GROUND
WITH BOTH RUNGS LOCKED INTO
PLACE (LADDER STEPS 1-3). FAILURE
TO DO THIS COULD ALLOW LADDER
TO SWING INTO TRUCK AND CAUSE
DAMAGE TO THE VEHICLE
LADDER
BRACKET
NOTE: The ladder brackets must be facing down.
STEP 3
"CLICK" AGAIN
@DECKEDUSA | #DECKEDUSA
TOOLS NEEDED:
• 5/32" hex wrench
DETAIL A
POSITION LADDER
VERTICALLY TO
SOLID GROUND
WATCH LADDER INSTRUCTIONAL VIDEOS:
DECKED.COM/LADDER
TBFDL | v.1 | Page 1
