DECKED DS1 Installation Instructions Manual

Ford super duty 6’9” bed length 1999-2008
Hide thumbs Also See for DS1:
Table of Contents

Advertisement

Quick Links

Download this manual
FORD SUPER DUTY
• Adjustable wrench (that opens to about 1")
• 1/2" open end wrench
• #2 Phillip screwdriver
• 3/8" socket
Watch short installation videos at www.decked.com/video | Register your system at www.decked.com/warranty
FOLLOW US:
Installation Instructions:
6'9" BED LENGTH
1999-2008
TOOLS REQUIRED
DECKED.COM | SERVICE@DECKED.COM | 208.806.0251
DS1
• 7/16" deep socket
• 7/32" Allen wrench
• 1/2" drill bit
• Wire cutters
• 10 mm socket or open end wrench
@DECKEDUSA | #DECKEDUSA
VERSION 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS1 and is the answer not in the manual?

Questions and answers

Related Manuals for DECKED DS1

Summary of Contents for DECKED DS1

  • Page 1 • 1/2” drill bit • Wire cutters • 3/8” socket • 10 mm socket or open end wrench Watch short installation videos at www.decked.com/video | Register your system at www.decked.com/warranty FOLLOW US: @DECKEDUSA | #DECKEDUSA VERSION 4 DECKED.COM | SERVICE@DECKED.COM | 208.806.0251...

  • Page 2: Table Of Contents

    ▼ ASSEMBLY OVERVIEW ▼ RIGHT/PASSENGER DECK HALF LEFT/DRIVER DECK HALF AMMO CAN AMMO WINDOW CAN LID COVER CABSIDE AMMO RULER J-HOOK C-CHANNEL ATTACHMENTS TAILGATE AMMO CAN CENTER VERT DRAWER Page 2 | v.4 | DS1 DECKED. COM | #DECKEDUSA | @DECKEDUSA...
  • Page 3 SERVICE@DECKED.COM | 208.806.0251 | DECKED.COM/INSTALLVIDEO AMMO CAN DRAIN HOLES (TO DRILL OR NOT TO DRILL.) • Do you use a tonneau or shell over your DECKED system? There is no need to drill holes. • Does your DECKED system live outside? The ammo cans will get water in them.

  • Page 4: Prep Sd/Tun

    Make sure to SAVE THE FACTORY SUPER DUTY BOLTS, as you will need them for the DECKED brackets. • Install DECKED tie-down brackets on both sides of truck using bolts from step above; BAG PREP SD/TUN. SAVE THESE BOLTS REUSE BOLTS...

  • Page 5: C-Channel Hw

    • There are three pre-installed gaskets – one on the center vert, one on each underside of the decks where they rest on the center vert. Do yours look weird? See them here: DECKED.COM/GASKETS • Place C-channel on the inside ledges of a cabside ammo can and a tailgate ammo can.
  • Page 6 • Grab your buddy to help you lift the assembly into the passenger side of the truck bed. PASSENGER SIDE DECK HALF CS AMMO CANS C-CHANNEL HW C-CHANNEL ENDPLATE CABSIDE AMMO CAN TAILGATE AMMO CAN AXLE Page 6 | v.4 | DS1 DECKED. COM | #DECKEDUSA | @DECKEDUSA...

  • Page 7: J10

    IMPORTANT: Leave all J-hook nuts loose until entire deck is in place. CABSIDE AMMO CAN WINDOW ✕ ✕ ✕ ✕ PASSENGER SIDE PASSENGER SIDE TAILGATE AMMO CAN CABSIDE AMMO CAN DECKED. COM | #DECKEDUSA | @DECKEDUSA DS1 | v.4 | Page 7...
  • Page 8 MAKE SURE THE CENTER VERT IS IN THE CENTER OF YOUR BED; the gaps on either sidewall may not be equal because the world isn’t perfect and neither is your truck bed. • Alternately and gradually tighten all J-hooks to ensure DECKED is centered and secure. Do not tighten one side of J-hooks all the way in one step.

  • Page 9: Drawer 1

    TUBE BRACE GOES HERE 2" BOLT CORNER BRACKET WHEELS DRAWER 3 DRAWER 1 HELPFUL TIP: If you purchased drain plugs, install now (instructions are included with drain plugs). DECKED. COM | #DECKEDUSA | @DECKEDUSA DS1 | v.4 | Page 9...
  • Page 10 • Install a clevis pin through each outside drawer hole and through spring; BAG HANDLE. • With DECKED logo facing outward, insert the handle ends behind the spring arms. Rotate the arms of the handle toward the clevis pins, pulling the spring arm downward. When the handle hole is lined up with the clevis pin, push the pin through the handle hole and through the inside drawer hole.
  • Page 11 INSTALL: DRAWERS (HOPEFULLY YOU’RE STILL WEARING YOURS.) • Save yourself the headache, watch this short installation video: DECKED.com/videotailgatewheels. • Install the drawer by sliding wheels into their two channels (C-channel and center vert), and slide drawer all the way forward until closed.

  • Page 12: Final Fs

    You did it. Immediately post a photo of your significant other, child or canine (in no order of significance - please someone show us your pet alligator) appreciating your accomplishment. Add hashtag #DECKEDUSA | @DECKEDUSA. FINAL FS FINAL FS FINAL FS #DECKEDUSA | @DECKEDUSA Page 12 | v.4 | DS1 DECKED. COM | #DECKEDUSA | @DECKEDUSA...
  • Page 13 (3) years from the date of the original purchase. If within three (3) years from the original date of purchase this product fails due to defect in materials or workmanship, DECKED LLC will replace any defective part at its option.
