- Page 1 INSTALLATION INSTRUCTIONS HIGH SIDES D-MOUNT TIE DOWNS CROSSBARS TRAY DIVIDERS CARGOGLIDE ACCESSORIES *Trust us on this one; don’t go commando and attempt your install without reading. You’ll just cuss a bunch and create even more chaos in your truck bed.
-
Page 2: Install Notes
INSTALL NOTES All CargoGlide accessories can be installed or removed with the CargoGlide installed in a truck bed or on top of a DECKED drawer system. Please follow safe loading practices as outlined below: CG ACCESSORIES v3 | Page 2... -
Page 3: Installation
HIGH SIDES INSTALLATION TOOLS NEEDED • 5/32” Hex wrench • 7/16” Wrench or socket/ratchet • Drill and 1/8” drill bit • 5/16” socket HARDWARE • Three (3) hardware bags: BAG 1 BAG 2 BAG 3 (6) 1/2” long, (8) 7/16” long, (4) 1/2”... - Page 4 • Install the cabside High Side panel by tilting the top towards the tray and inserting the engagement tab into the rail. Rotate into place. TAB INSERTED INTO TRACK CG ACCESSORIES v3 | Page 4 DECKED.COM...
- Page 5 It is recommended to install the nuts on the INTERIOR should there be a clearance issue at the cabside bulkhead. • Install the side High Side panels by tilting towards the tray to engage the rail tab. DECKED.COM CG ACCESSORIES v3 | Page 5...
- Page 6 STEP 3: INSTALL HIGH SIDES • Install the 7/16” long hex drive screws and nuts to secure the side High Sides to the corner pieces. • Align all High Side pieces and tighten the four corner track screws (two on each side).
-
Page 7: Step 4: Install Endcaps
7/16” socket on the nut. Do not overtighten. DETAIL A. DETAIL A SEAT BOLT HEAD IN CUTOUT • Tighten the track bolts on each side High Side end. Do not overtighten. DECKED.COM CG ACCESSORIES v3 | Page 7... - Page 8 STEP 5: DRILL AND SECURE • Confirm all High Sides, corners and endcaps are securely fastened to each other and the CargoGlide rails. • Drill pilot holes through the guide holes on the left, right, and cabside High Sides with a 1/8”...
- Page 9 Downs as shown. Leave the bolt loose. 2. Insert the D-Ring Tie Down track nut into the CargoGlide track. 3. Tighten bolt to anchor in place. NOTE: The D’s must face inward on each side. DECKED.COM CG ACCESSORIES v3 | Page 9...
- Page 10 • TOTAL HARDWARE QUANTITIES ARE DEPENDENT ON ITEMS PURCHASED • Hardware included for • Hardware included for each CROSS BAR : each TRAY DIVIDER : (8) 1/2” long countersink screws (3) 1/2”long button head screws (8) T-slot nuts (3) T-slot nuts CG ACCESSORIES v3 | Page 10 DECKED.COM...
- Page 11 NOTE: If installing two Cross Bars with one being mounted on the High Sides, use the lower mounting holes on the Cross Bar foot mounted on the High Sides to keep the Cross Bars level with each other. DETAIL A. LOWER MOUNTING...
-
Page 12: Step 2: Install Cross Bar
CargoGlide side rails. • Position Cross Bar and risers over the CargoGlide side rails or High Sides. Insert the T-slot nuts into the tracks. • Position the Cross Bar where desired. Tighten the Cross Bar and T-slot nut screws. - Page 13 MOUNTING CHANNEL ON TOP DETAIL A DECKED.COM CG ACCESSORIES v3 | Page 13...
- Page 14 Insert Tray Divider T-slot nuts into Cross Bar track. • Adjust height of Tray Divider to desired level. • Tighten Tray Divider screws. • Loosen Cross Bar T-slot nuts to adjust Tray Divider position/ height as needed. CG ACCESSORIES v3 | Page 14 DECKED.COM...
- Page 15 DETAIL A LOOSEN TO ADJUST POSITION DECKED.COM CG ACCESSORIES v3 | Page 15...
- Page 16 DECKED Product, but rather issue to the DECKED Warranty and Claims original purchaser a refund equal to the purchase price paid PO Box 885 for the DECKED Product or a credit to be used towards the Ketchum, ID 83340 purchase of a new DECKED Product. warranty@decked.com...
- Page 17 CONGRATS, GAME CHANGER! YOU DID IT. Crack open a cold one of your liking, sit back and admire your work. Now get busy organizin’!
