MERCEDES BENZ / DODGE / FREIGHTLINER
REGISTER YOUR SYSTEM
Watch short installation videos at www.decked.com/video | Register your system at www.decked.com/warranty
FOLLOW US:
Installation Instructions Van:
VNMB07SPRT65
SPRINTER VAN
170" WHEELBASE
2007-CURRENT
TOOLS REQUIRED
• 3/8" socket
• 7/16" socket
• 7/32" hex wrench
DECKED.COM | 208.806.0251
• 1/8" hex wrench
• wire cutters
@DECKEDUSA | #DECKEDUSA
VERSION 7
INSTRUCTION VIDEOS
RC158
Advertisement
Related Manuals for DECKED VNMB07SPRT65
Summary of Contents for DECKED VNMB07SPRT65
- Page 1 • 1/8” hex wrench • 7/16” socket • wire cutters • 7/32” hex wrench REGISTER YOUR SYSTEM INSTRUCTION VIDEOS Watch short installation videos at www.decked.com/video | Register your system at www.decked.com/warranty FOLLOW US: @DECKEDUSA | #DECKEDUSA VERSION 7 DECKED.COM | 208.806.0251 RC158...
- Page 2 ▼ ASSEMBLY OVERVIEW ▼ RIGHT/PASSENGER DECK HALF LEFT/DRIVER DECK HALF AMMO CAN AMMO WINDOW CAN LID COVER FRONT AMMO CAN RULER J-HOOK C-CHANNEL ATTACHMENTS REAR AMMO CAN CENTER VERT DRAWER Page 2 | v.7 | VNMB07SPRT65 DECKED.COM | #DECKEDUSA | @DECKEDUSA...
- Page 3 ▼ HEY! TORQUE BOY: READ BEFORE YOU INSTALL DECKED ▼ 1. DECKED MUST be installed in conjunction with a 6. DON’T over tighten J-hooks during installation. bulkhead wall and/or adequate structural framework Make ‘em good and snug enough to keep the to prevent injury as a result of a traffic accident.
- Page 4 Place the shim and apply with pressure. NOTE: Step B is to be repeated on the passenger side. FRONT FOLLOW INSTRUCTIONS FOR REAR DETAILED VIEWS ON NEXT PAGE Page 4 | v.7 | VNMB07SPRT65 DECKED.COM | #DECKEDUSA | @DECKEDUSA...
- Page 5 OF VAN 1 7/8” FRONT OF VAN DETAIL C 2 1/2” Place shim in center of depressed floor bead. Front of shim extends 2 1/2”from floor beads. 2 1/2” DECKED.COM | #DECKEDUSA | @DECKEDUSA VNMB07SPRT65 | v.7 | Page 5...
- Page 6 • There are three pre-installed gaskets – one on the center vert, one on each underside of the decks where they rest on the center vert. Do yours look weird? (They should be flat.) See them here: DECKED.COM/GASKETS • Place C-channel on the inside ledges of a front ammo can and a rear ammo can.
- Page 7 CS AMMO CAN and B1 - 27 in-lb. CS AMMO CAN NYLON + RUBBER WASHERS C CHANNEL NYLON WASHERS C CHANNEL NYLON WASHERS REAR AMMO CAN AXLE FRONT C-CHANNEL ENDPLATE FRONT AMMO CAN DECKED.COM | #DECKEDUSA | @DECKEDUSA VNMB07SPRT65 | v.7 | Page 7...
- Page 8 TUBE BRACE GOES HERE 2" BOLT CORNER BRACKET FRONT WHEELS DRAWER 3 DRAWER 1 HELPFUL TIP: If you purchased drain plugs, install now (instructions are included with drain plugs). Page 8 | v.7 | VNMB07SPRT65 DECKED.COM | #DECKEDUSA | @DECKEDUSA...
- Page 9 • Install a clevis pin through each outside drawer hole and through spring; BAG HANDLE. • With DECKED logo facing outward, insert the handle ends behind the spring arms. Rotate the arms of the handle toward the clevis pins, pulling the spring arm downward. When the handle hole is lined up with the clevis pin, push the pin through the handle hole and through the inside drawer hole.
- Page 10 INSTALL: DRAWERS • Prevent acid reflux, watch this short installation video: DECKED.com/videotailgatewheels. • Install the drawer by sliding wheels into their two channels (C-channel and center vert), and slide drawer all the way forward until closed. • Install the remaining rear side wheels onto their axles; BAG WHEELS.
- Page 11 PREP TBO 1” BOLTS RECOMMENDED TORQUE: HELPFUL TIP: Bottle opener goes on the outside of the torsion brace. 1” Bolts - 27 in-lb. | 1/2” Bolts - 18 in-lb. DECKED.COM | #DECKEDUSA | @DECKEDUSA VNMB07SPRT65 | v.7 | Page 11...
- Page 12 • Repeat with J-hooks and ammo cans on drivers side. IMPORTANT: Leave all J-hook nuts loose. ✕ ✕ ✕ ✕ FRONT FRONT OF VAN OF VAN PASSENGER SIDE PASSENGER SIDE FRONT AMMO CAN REAR AMMO CAN Page 12 | v.7 | VNMB07SPRT65 DECKED.COM | #DECKEDUSA | @DECKEDUSA...
- Page 13 • Insert lock core plugs, or install locks if purchased. • Nice job. Your mother and I are very proud of you. 1/4” SCREWS LOCK CORE PLUGS RECOMMENDED TORQUE: J-hooks - 9 in-lb. DECKED.COM | #DECKEDUSA | @DECKEDUSA VNMB07SPRT65 | v.7 | Page 13...
- Page 14 You did it. Immediately post a photo of your significant other, child or canine (in no order of significance - please someone show us your pet alligator) appreciating your accomplishment. Add hashtag #DECKEDUSA | @DECKEDUSA. Page 14 | v.7 | VNMB07SPRT65 DECKED.COM | #DECKEDUSA | @DECKEDUSA...
- Page 15 (3) years from the date of the original purchase. If within three (3) years from the original date of purchase this product fails due to defect in materials or workmanship, DECKED LLC will replace any defective part at its option.
