PREPARATION
1
Disconnect the power cable.
2
Turn the projector upside down.
3
Remove the lamp cover.
(1) Turn the screw that fastens the lamp cover
counterclockwise until it turns freely. (The
screw will not come out.)
4
Remove the lamp cartridge
(1) Turn the 2 screws that fasten the lamp car-
tridge counterclockwise until they turn freely.
(The screws will not come out.)
Turn the projector upside down and place it on a soft cloth that has
been prepared in advance to prevent scratches. This will assist in
lamp cartridge replacement. After replacement, return the projector
to the original condition.
E-37
Replacing the Lamp Cartridge
(2) Lift the lamp cover a little and pull it off in the
direction of the arrow.
(2) Grasp the handle of the lamp cartridge, pull it
upward and remove the lamp cartridge.
