Placement Guide

G
Use this information as a guide to find out about the screen size when the projector is placed at a
certain location, or to find out the approximate size of a screen that will be required.
G
The projection distance over which focussing is adjustable is 1.20 m (3.9 feet) to 9.44 m (30.97
feet). The projector should be placed within this range.

Screen Size and Projection Distance

8 0
6 0
"
4 0
"
2 6
"
AUD
IO
VIDE O
PC
Lens surface of
the main unit
Screen Size Designation (Inches)
2 0
1 8
0 "
1 5
0 "
1 2
0 "
1 0
0 "
"
0 "
E-10
Height from center
of lens to top edge
of the projection
h 1
Height from center
of lens to bottom
edge of the projec-
tion
h 2
Unit: m (feet)
