Data Projector
VP - 1
USER'S MANUAL (Simplified Edition)
Introduction
Congratulations on your purchase of the OLYMPUS VP-1 data projector.
Please read the USER'S MANUAL (Simplified Edition) and the USER'S MANUAL (CD-
ROM Edition) carefully and use the projector properly. After reading, please store in a safe
place.
IMPORTANT
Digital Light Processing, DLP™, Digital Micromirror Device and DMD are all trademarks of Texas
Instruments.
IBM,VGA,XGA are trademarks and registered trademarks of International Business Machines Cor-
poration.
SVGA is a registered trademark of Video Electronics Standards Association.
TMDS is a trademark of Silicon Image Inc.
Macintosh is a trademark of Apple Computer Inc.
Other names of companies and products mentioned are trademarks and registered trademarks of the
respective companies.
TM
, ® and © marks are not used in this document.
E-1
