SCOPE OF DELIVERY CPU water Block CPU Backplate mechanism Thermal grease CPU Mounting mechanism with AMD® mounting plate Fans Pump-Reservoir combo UNI Pump Bracket Compression fi ttings (120mm Fan) Radiator Coolant Tube ATx Bridging plug / 3 /...
DOZEN GOOD ADVICES FOR THE NEWCOMERS 1. In order to lower shipping costs we have decided to enclose only the after the Radiator in the water loop. coolant concentrate for liquid cooling. Therefore you need to provide 1 liter 7. Generally, for optimal performance, the Pump should be positioned before (1L) of distilled water.
GENERAL INFORMATION ON WATER BLOCK COMPATIBILITY This CPU liquid cooling unit is pre-assembled for use with modern Intel desktop socket type motherboards. By default (out of the box) this water block supports the following CPU sockets: - Intel® Socket LGA-775 - Intel®...
INSTALLING THE WATER BLOCK LGA-2011(-3) SOCKET MOTHERBOARDS STEP 1 LGA-2011 M4 Prepare the foil bag with mounting mechanism, which is enclosed with the CPU LGA-2011 M4 Thumb Screw water block delivery. Thumb Screw Install four (4) specific LGA-2011 M4 thumb screws into four M4 threaded stubs on the LGA-2011 socket integrated latch mechanism (ILM).
Page 11
STEP 3.: Take the waterblock and remove the sticker on the copper head. Align the water block over the mounting screws on the LGA-2011(-3) motherboard with pre-installed CPU. Thumb nut Before proceeding with the installation It is mandatory to remove the protective foil from the backside of the water block.
LGA-115x SOCKET MOTHERBOARDS Outer part STEP 1 If already installed, please remove the motherboard from your computer and place it on an even surface with front facing down. STEP 2 Preparing backplate rubber gasket The enclosed rubber gasket is essential part of the backplate and mount- ing system and must be used every time you install this water block on your motherboard.
Page 13
STEP 5 Cleaning the CPU: Wipe the CPU’s contact surface (by using non–abrasive cloth or Q-tip, as shown on sample photo). Non-abrasive Applying thermal compound: EK recommends blob or line method of applying the cloth enclosed EK-TIM Ectotherm thermal compound to the CPU heat spreader (IHS) - see sample photo on right.
AMD® SOCKET MOTHERBOARDS M4x14 Screws STEP 1 Replacing the mounting plate: Place the water block on a neven surface and remove the four Intel® socket AMD® socket M4x14 DIN 7991 screws attaching the copper base to the top mounting plate mounting plate using 2,5mm Allen key in counter-clockwise direction.
Page 15
STEP 4 Removing of the original plastic hold-down clamps UNC 6-32 AMD® factory backplate and the factory backplate: Screws Using Philips-head screwdriver remove the four UNC 6-32 screws securing the original plastic hold-down clamps around the socket as shown on the sketch. Re- move the original AMD®...
Page 16
STEP 7 M4 Thumb Screw Install four (4) M4 thumb screws onto your motherboard. It is mandatory to put 0.7mm plastic washer underneath each of the M4 thumb screws. Tighten the screws to the metal backplate until you reach the end of the thread. Using tools (such as pli- ers) is not recommended.
Page 17
STEP 9 Fitting Barb With EK-Supremacy Mx series water blocks it is mandatory to use the port that is nearest to the Fitting Ring center of the water block as INLET port. Mixing the ports may result in poor thermal performance of the water block.
INSTALLING THE RADIATOR AND FANS OPTION #1: UNC 6-32 x 30 screw INSTALLING THE RADIATOR AND FANS STEP 1 Install the fans on the radiator. Ideally, the radiator should either: A) receive the coldest air possible (by placing the radia- tor on the air inlet) or B) serve as an overall hot air exhaust (by placing the Radiator...
STEP 4.: Install the compression fitting on both G1/4 extender openings on the radiator. Tighten Fitting Barb the fitting barbs in clockwise direction until the gasket underneath is compressed. The installation of the radiator and radiator cooling fans is now complete. Fitting Ring OPTION #2: INSTALLING THE RADIATOR AND FANS IN...
INSTALLING THE PUMP-RESERVOIR UNIT STEP 1 The KIT comes with combined pump and reservoir unit with pre- installed anti-vibration decouplers. Pump-reservoir combo unit Take the unit and place it on the EK-UNI Pump Bracket (120mm Fan). Secure it from the bottom side using four M4x4 screws and PVC washers.
STEP 3 Secure the M4x6 screws (from the previous step) with four M4 nuts and PVC washers. Tighten them using 2,5mm Allen key with the screws. PC Chassis Make sure that the screws are holding tight but do not exag- gerate with the force applied.
Page 22
STEP 2 Visualize the tube’s routes and then measure the distance by trying to fit it into the chassis. Mark the required length with a marker. Before cutting it is recommended that you leave an additional 2 or 3 centimeters to spare. You can shorten it af- terwards.
STEP 5.: Slide the fitting ring towards the barb and tighten it in clockwise direction as far as it goes. Repeat the procedure on all the fittings in order to connect the water cooling loop. The liquid cooling loop components are now connected and the cooling cir- cuit is now complete.
CONNECTING THE FANS STEP 1 To connect all the fans to a single fan header you might need to use EK- Cable Y Splitter. With the EK-KIT S120 the Splitter cable will not be needed. For the 240 and 360 KIT version the fan splitter cable is enclosed. Connect the female connectors from the fans with male connectors on the fan splitter cable.
RECOMMENDED FILLING AND LEAK- TESTING PROCEDURE Power supply ATx cable STEP 1 EK-ATx It is mandatory to do the following: Bridging Plug 1. Disconnect all PSU power connectors (4/8-pin ESP, 24-pin ATx, PCI-express power, SATA power) in your computer. 2. Plug the EK-ATx Bridging plug (enclosed) to your 24-pin ATx PSU cable which allows jump starting your computer.
FILLING THE SYSTEM FOR THE FIRST TIME STEP 1: Preparing the cooling liquid. The coolant comes in concentrated form. In order to prepare the cooling liquid you must take a 100ml clear coolant concentrate, which is enclosed with the kit, and mix it with 900mL of distilled water. Make sure you mix the mixture properly before pouring it into the water cooling loop.
Page 27
STEP 4 When you turn on the power supply the coolant should be pushed from the reservoir to other water cooling components, therefore you have to fill the coolant continuously while the pump is running. Alternatively you can cycle (turn on and of) the power supply in few second intervals to speed up the air bleeding process.
DRAINING OF THE LOOP STEP 1 Before disassembling the water cooling loop it is mandatory turn off your computer and pull the power cord from the socket. Prepare some paper towels and stack them over the hardware. Unscrew the four M4 nuts securing the EK-UNI Pump Bracket (120mm Fan) on the PC chassis.
POSSIBILITIES OF ExPANDING THE SYSTEM The best part of custom water cooling loop is that the system can be extended and the cooling capacity can be extended almost without limitations. Rule of thumb is to use at least one 120mm radiator (section) per each water cooled component plus one ‘spare’. For example, if one is liquid cooling a CPU and a single high-performance graphics card it is recommended at least one 240mm (2x 120mm) radiator for good performance.
STEP 2 Measure the length of the tube that is needed to connect the CPU to GPU water block and the GPU water block to the pump-reservoir unit. You can use a pair of scissors or a knife to cut the tube. You may need additional tubing to connect the water block.
FREQUENTLY ASKED QUESTIONS Is this kit, namely the water block, compatible with nar- row server type LGA-2011 motherboard? How about old- What flow rates are to be expected with EK-KIT SLIM? er LGA-1366 and -755? A: This kit typically operates at about 180L/h. A: Narrow server type LGA-2011 is not supported by default –...
Upon exhausting all options please consult EK knowledge base at 3. Kink in the liquid cooling tubing: Very similar symptoms to both above http://support.ekwb.com . Raise a question through EK Support described. Thin-walled tubing may collapse easily under low radius turns or ticketing system if needed.
General ASUS Z170/X99 motherboard guide: General Gigabyte Z170/X99 motherboard guide: 1. Enter UEFI and go to QFAN Control 1. Enter UEFI and go to M.I. T . - > PC Health Status 2. Select the FAN header you wish to edit (the one that you have con- 2.
Page 34
PREVENTIVE STEPS: is normally reversible by simple flush and rinse. Cleaning the nickel plated cop- per should consists of these steps: - flush the nickel plated copper under warm water 1. Using corrosion inhibiting coolant (such as EK-Ekoolant or other - clean the surface using wet non-abrasive cloth and rinse with clean water market proven coolant) is highly recommended for any water cooling loops.
SUPPORT AND SERVICE For assistance please contact: http://support.ekwb.com/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
