  • Page 1 JinkoSolar Photovoltaic Module (UL1703) User Manual...

  • Page 2: Table Of Contents

    Contents General Information 1.1 Overview 1.2 Applicable Products 1.3 Warnings 2. Installation 2.1 Installation safety 2.2 Installation Condition 2.2.1 Climate condition 2.2.2 Site selection 2.2.3 Tilt angle selection 2.3 Mechanical Installation introduction 2.3.1 Fixation with screws 2.3.2 Fixation with clamps Wiring and connection Maintenance and care Electrical specification...

  • Page 3: General Information

    1. General Information 1.1 Overview Thanks for choosing Jinko Solar PV modules. In order to ensure the PV modules to be installed correctly, please read the following operation instructions carefully before modules are installed and used. Please remember that the products would generate electricity and certain safety measures need to be taken to avoid danger.

  • Page 4: Warnings

    This module has a Class C Fire Rating（only in Canada）or Module Fire performance type 1 (only in America) and must be installed over a roof which is with appropriate fire resistance. Before mounting the module, please consult your local building department to determine approved roofing materials.
  • Page 5 Rev. C  Electric Shock and Burn Hazard  This photovoltaic module produces Warning Electricity when exposed to the sun  To reduce the risk of electrical shocks or burns, modules may be covered with an opaque material during installation to avoid shocks or burns. ...
  • Page 6  Do not remove any part installed by Jinko Solar or disassemble the module.  All instructions should be read and understood before attempting to install, wire, operate and maintain the module.  Please don’t lift up PV modules using the attached cables or the junction box. ...

  • Page 7: Installation

    Rev. C  Do not clean the glass with chemicals.  Do not disconnect any of the modules when it is under load. 2. Installation 2.1 Installation safety  Always wear protective head gear, insulating gloves and safety shoes (with rubber soles).

  • Page 8: Installation Condition

    2.2 Installation Condition 2.2.1 Climate condition Please install the modules in the following conditions: a) Operating temperature: within –40° C(-4°F) to 85° C (185°F) b) Humidity: < 85RH%. ﹡Note: The mechanical load bearing (include wind and snow loads) of the module is based on the mounting methods.

  • Page 9: Tilt Angle Selection

    Rev. C be placed in an insulated and ventilated battery case specifically designed for the purpose. Do not install the PV module in a location where it would be immersed in water or continually exposed to water from a sprinkler or fountain etc. 2.2.3 Tilt angle selection The tilt angle of the PV module is measured between the surface of the PV module and a horizontal ground surface (Figure 1).

  • Page 10: Mechanical Installation Introduction

    2.3 Mechanical Installation introduction Solar PV modules usually can be mounted by using the following methods: screws and clamps. ﹡ Note: (1) All installation methods herein are only for reference, and Jinko Solar will not provide related mounting components, the system installer or trained professional personnel must be responsible for the PV system’s design, installation, and mechanical load calculation and security of the system.

  • Page 11: Fixation With Screws

    Rev. C 2.3.1 Fixation with screws The frame of each module has 8 mounting holes (Length* Width: 14mm*9mm) used to secure the modules to support structure. You can use the four symmetry holes close to the inner side on module frame. If excessive wind or snow load are expected, you must use all the eight mounting holes.

  • Page 12: Fixation With Clamps

    2.3.2 Fixation with clamps The applicable products only allow using clamps at long side of frames. The module clamps should not come into contact with the front glass and must not deform the frame. Be sure to avoid shadowing effects from the module clamps. The module frame is not to be modified under any circumstances.

  • Page 13: Wiring And Connection

    Rev. C Dimension(mm) Cell Module type Cell type quantity JKMXXXP-72 JKMXXXPP-72 JKMXXXP-72B ≥14 ＞2mm JKMXXXPP-72B Poly 6*12 1956*992 5~11 0.5~2mm JKMSXXXP-72 JKMSXXXPP-72 JKMxxxPP-72(Plus) JKMXXXM-72 ≥14 ＞2mm JKMXXXM-72B Mono 6*12 1956*992 5~11 0.5~2mm JKMSXXXM-72 JKMXXXP-60 JKMXXXPP-60 JKMXXXP-60B ≥14 ＞2mm JKMXXXPP-60B Poly 6*10 1650*992 5~10...
  • Page 14 maximum reverse current that a module can withstand, i.e. when one string is in shade then the other parallel strings of modules will be load by the shade string and the current will pass through to create a current circuit. Thus based on the maximum series fuse rating of module and local electrical installation criteria, make sure the modules strings in parallel for connection need to be assembled with appropriate string fuse for circuit protection.

  • Page 15: Maintenance And Care

    Rev. C ‘charge-equalizing’ device may be used to mitigate the effects of the Potential Induced Degradation (PID) phenomenon that can occur in specific environments that the array is installed in. Figure 4 above: Junction box 4. Maintenance and care a) A built up of dust or dirt on the module(s) front glass will result in a decreased energy output.

  • Page 16: Electrical Specification

    5. Electrical specification The module electrical rating are measured under Standard Test Conditions, which are 1000W/m , irradiance with AM 1.5 spectrum and 25 deg (77° F) ambient temperature. The module might produce more or less voltage or current than rating value in uncertainty condition.
  • Page 17 Rev. C 5.1. Electrical specifications JKMxxxP-72, JKMxxxPP-72, JKMxxxP-72B JKMxxxPP-72B (xxx=250-320) Series polycrystalline solar modules Module Type JKMxxxP-72, JKMxxxPP-72, JKMxxxP-72B ,JKMxxxPP-72B xxx = Maximum Power at (Pmax, Wp) Maximum Power 34.2 34.5 34.7 34.9 35.0 35.2 35.3 35.5 35.8 36.2 36.6 36.8 37.0 37.2...
  • Page 18 5.2. Electrical specifications of JKMxxxM-72 and JKMxxxM-72B (xxx=250-320) Series polycrystalline solar modules Module Type JKMxxxM-72, JKMxxxM-72B xxx = Maximum Power at (Pmax, Wp) Maximum Power Voltage 34.8 35.0 35.3 35.6 35.9 36.1 36.3 36.5 36.7 36.8 37.0 37.2 37.4 37.6 37.8 (Vmp, V) Maximum Power...
  • Page 19 Rev. C 5.3. Electrical specifications of JKMxxxP-60 ,JKMxxxPP-60 , JKMxxxP-60B and JKMxxxPP-60B (xxx=200-265) Series polycrystalline solar modules Module Type JKMxxxP-60, JKMxxxPP-60 , JKMxxxP-60B, JKMxxxPP-60B xxx = Maximum Power at (Pmax, Wp) Maximum Power Voltage 28.2 28.4 28.6 28.8 29.0 29.2 29.4 29.6 29.8...
  • Page 20 5.4. Electrical specifications of JKMxxxM-60 and JKMxxxM-60B (xxx=200-280) Series Monocrystalline solar modules JKMxxxM-60, JKMxxxM-60B Module Type Maximum Power at (Pmax, Wp) Maximum Power 28.2 28.4 28.6 28.8 29.0 29.2 29.4 29.6 29.8 30.1 30.5 30.8 30.9 31.2 31.4 31.6 31.8 Voltage (Vmp, V) Maximum...
  • Page 21 Rev. C 5.5 Electrical specifications of JKMSxxxP-72 and JKMSxxxPP-72 (xxx=250-320) Series Polycrystalline solar modules Module Type JKMSxxxP-72, JKMSxxxPP-72 xxx= Maximum Power at STC (Pmax, Wp) Maximum Power Voltage 32.5 32.8 33.0 33.2 33.3 33.4 33.5 33.7 34.0 34.4 34.8 34.9 35.2 35.3 35.5...
  • Page 22 5.6. Electrical specifications of JKMSxxxM-72 (xxx=250-320) Series polycrystalline solar modules Module Type JKMSxxxM-72 xxx= Maximum Power at STC (Pmax, Wp) Maximum Power Voltage 34.8 35.0 35.3 35.6 35.9 36.1 36.3 36.5 36.7 36.8 37.0 37.2 37.4 37.6 37.8 (Vmp, V) Maximum Power Current 7.18...
  • Page 23 Rev. C 5.7. Electrical specifications of JKMSxxxP-60 and JKMSxxxPP-60 (xxx=200-265) Series polycrystalline solar modules Module Type JKMSxxxP-60, JKMSxxxPP-60 xxx= Maximum Power at STC (Pmax, Wp) Maximum Power 26.8 27.0 27.2 27.4 27.6 27.2 27.9 28.1 28.3 28.6 29.0 29.3 29.5 29.8 Voltage (Vmp, V)
  • Page 24 5.8. Electrical specifications of JKMSxxxM-60 (xxx=200-280) Series Monocrystalline solar modules Module Type JKMSxxxM-60 xxx= Maximum Power at STC (Pmax, Wp) Maximum Power Voltage 28.2 28.4 28.6 28.8 29.0 29.2 29.4 29.6 29.8 30.1 30.5 30.8 30.9 31.2 31.4 31.6 31.8 (Vmp, V) Maximum Power Current...

  • Page 25: Disclaimer Of Liability

    Rev. C 6. Disclaimer of Liability Because the use of the manual and the conditions or methods of installation, operation, use and maintenance of photovoltaic (pv) product are beyond Jinko’s control, Jinko does not accept responsibility and expressly disclaims liability for loss, damage, or expense arising out of or in any way connected with such installation, operation, use or maintenance.
  • Page 26 Note - 24 -...

  • Page 27: Contact Us

    Jinko solar Import and Export co., LTD Xuri District, Shangrao Economic Development Zone, Jiangxi Province, CHINA Postcode: 334100 Tel: +86-793-8618987 Fax: +86-793-8461152 Customer Service：cs@jinkosolar.com Jinko Solar USA 495 Market Street, Suite 2200, San Francisco, CA 94105 Tel:+(415) 402 0502 Fax: +(415) 402 0703 us@jinkosolar.com Jinko Solar Canada Co., Ltd.
  • Page 28 Zhejiang Province, China 314416 Shanghai, China 200127 Tel: +86 21 6061 1799 Tel:+86 793 858 8188 Tel: +86 573 8798 5678 Fax: +86 21 6876 1115 Fax:+86 793 846 1152 Fax: +86 573 8787 1070 www.jinkosolar.com | Technic Support: technic@jinkosolar.com | After-sales: cs@jinkosolar.com...
