  • Page 1 JinkoSolar Photovoltaic Module Installation Manual...

  • Page 2: Table Of Contents

    Contents General Information 1.1 Overview 1.2 Warnings 2. Installation 2.1 Installation Safety 2.2 Installation Condition 2.2.1 Climate Condition 2.2.2 Site Selection 2.2.3 Tilt Angle Selection 2.3 Mechanical Installation Introduction 2.3.1 Mounting with Bolts 2.3.2 Mounting with Clamps 3 Wiring and Connections Maintenance and Care 4.1 Visual Inspection 4.2 Cleaning...

  • Page 3: General Information

    1. General Information 1.1 Overview Thanks for choosing Jinko Solar PV modules. In order to ensure the PV modules are installed correctly, please read the following installation instructions carefully before modules are installed and used. Please remember that these products generate electricity and certain safety measures need to be taken to avoid danger.
  • Page 4  All instructions should be read and understood before attempting to install, wire, operate and maintain the module. Don’t lift up PV modules using the attached cables or the junction box.   Do not touch live terminals with bare hands. Use insulated tools for electrical connections. ...

  • Page 5: Installation

     Do not disconnect any of the modules when under load.  When looking at PV modules with anti-reflection (AR) coating technology, it will be normal to see some cells with a slight color difference at different angles. Modules with LRF(light reflective film) and without LRF should not be built in the same array or roof.

  • Page 6: Installation Condition

    done in a way to avoid the connector from scratching or impacting the back sheet of the module.  Do not touch the junction box and the end of the interconnect cables (connectors) with bare hands during installation or under sunlight, regardless if the PV module is connected to or disconnected from the system.

  • Page 7: Tilt Angle Selection

    guidelines concerning installation, operation and maintenance recommendations. In general, the battery (or battery bank) should be away from the main flow of people and animal traffic. Select a battery site that is protected from sunlight, rain, snow, debris, and is well ventilated. Most batteries generate hydrogen gas when charging, which can be explosive.

  • Page 8: Mounting With Bolts

    refer to the mentioned module type in this manual) and negative (or upward) pressure of 1600Pa. This design load was then tested with a safety factor of 1.5 times. So Jinko modules are tested under a maximum downward pressure of 5400Pa and upward pressure of 2400Pa. When mounting modules in snow-prone or high-wind environments, special care should be taken to mount the modules in a manner that provides sufficient design strength while meeting local code requirements.
  • Page 9 Max. Design Pressure: 3600Pa (positive ) Max. Design Pressure: &1600Pa (negative) mechanical load 3600Pa (positive ) &1600Pa Note：The installation method is based (negative) mechanical load Module type on the internal results in Jinko. Module dimensions(mm) Height of the frame（mm） Group 1 1650*992 &...
  • Page 10 1868*1008 & 1865*1005 Group 36 1840*998 & 1841*1002 Group 38 1842*1021 & 1842*1024 Group 40 1855*1029 & 1855*1032 Group 42 1868*1034 & 1878*1032 Group 44 1868*1034 & 1878*1032 1842*1021 & 1842*1024 Group 48 1855*1029 & 1855*1032 Height of the frame（mm） Group 23 2113*995 &...
  • Page 11 Max. Design Pressure: 3600Pa (positive ) &1600Pa (negative) mechanical load Module type Module dimensions(mm) Height of the frame（mm） Group 1 1650*992 & 1665*1002 Group 2 1665*992 & 1684*1002 Group 3 1650*992 & 1665*1002 Group 4 1665*992 & 1684*1002 Group 5 1650*992 &...
  • Page 12 1842*1021 & 1842*1024 Group 40 1855*1029 & 1855*1032 Group 42 1868*1034 & 1878*1032 Group 44 1868*1034 & 1878*1032 1842*1021 & 1842*1024 Group 48 1855*1029 & 1855*1032 Height of the frame（mm） Group 23 2113*995 & 2113*998 Group 25 2130*1002 & 2139*1008 Group 27 2130*1002 &...
  • Page 13 Max. Design Pressure: 1067Pa (positive ) &1067Pa (negative) mechanical load Module type Module dimensions(mm) Height of the frame（mm） Group 1 1650*992 & 1665*1002 Group 2 1665*992 & 1684*1002 Group 3 1650*992 & 1665*1002 Group 4 1665*992 & 1684*1002 Group 5 1650*992 &...

  • Page 14: Mounting With Clamps

    Group 39 2168*1021 & 2168*1024 & 2182*1029 & 2182*1032 Group 41 2194*1034 & 2205*1032 Group 43 2194*1034 & 2205*1032 Group 47 2168*1021 & 2168*1024 & 2182*1029 & 2182*1032 Table 3: Mechanical dimensions for bolt fitting method (NEX) Note：The installation method of bolt fitting (NEX) is based on the experimental results in Jinko. According to IEC 61215 for a maximum positive design loading of below 1067Pa, and negative design loading 1067Pa, with 1.5 times safety factor.
  • Page 15 Middle modules Fringe modules Figure 5: PV module installed at the side with Clamp fitting method When installing modules using clamps on the long side of the frame, the applicable product types and installation locations are shown in figure 6 and table 4. When installing modules using clamps on the short side of the frame, the applicable product types and installation locations are shown in figure 7 and table 5.
  • Page 16 2.3.2.1 Clamp Mounting on Long Sides of the Frames Figure 6: Installation of clamps on long side of frames 3600Pa (positive ) &1600Pa (negative) 3600Pa (positive ) mechanical load Max. Design Pressure: &1600Pa (negative) Note：The installation Module type mechanical load method is based on the internal results in Jinko.
  • Page 17 Height of the frame（mm） Group 10 1956*992 & 1979*1002 Group 11 1987*992 & 2008*1002 Group 12 1956*992 & 1979*1002 Group 13 1987*992 & 2008*1002 Group 14 1956*992 & 1979*1002 Group 15 1987*992 & 2008*1002 L/4± 50mm( L is the Group 16 1956*992 &...
  • Page 18 Group 43 2194*1034 & 2205*1032 2168*1021 & 2168*1024 & Group 47 2182*1029 & 2182*1032 Table 4: Mechanical dimensions of modules installed with clamps on long side of frame According to IEC 61215 for a maximum positive design loading of below 3600Pa, and negative design loading 1600Pa, with 1.5 times safety factor 2.3.2.2 Clamp Mounting on Short Sides of the Frames Figure 7: Installation of clamps on short side of frames...
  • Page 19 Group 10 1956*992 & 1979*1002 Group 11 1987*992 & 2008*1002 Group 12 1956*992 & 1979*1002 Group 13 1987*992 & 2008*1002 Group 14 1956*992 & 1979*1002 Group 15 1987*992 & 2008*1002 Group 16 1956*992 & 1979*1002 Group 17 1987*992 & 2008*1002 1987*992 &...
  • Page 20 2.3.2.3 Clamp Mounting on Long & Short Sides Figure 8: Installation methods of clamps on long and short sides Max. Design 1600Pa (positive ) &1600Pa 1600Pa (positive ) &1600Pa (negative) Pressure: (negative) mechanical load mechanical load Module type Module dimensions(mm) Height of the frame（mm）...
  • Page 21 1672*992 & 1704*1008 Group 20 1704*1008 Group 22 1684*1002 Group 30 1704*1008 Group 46 1684*1002 Height of the frame（mm） 1956*992 & Group 10 1979*1002 1987*992 & Group 11 2008*1002 1956*992 & Group 12 1979*1002 1987*992 & Group 13 2008*1002 1956*992 & Group 14 1979*1002 L/4±...
  • Page 22 1840*998 & Group 38 1841*1002 1842*1021 & 1842*1024 & Group 40 1855*1029 & 1855*1032 1868*1034 & Group 42 1878*1032 1868*1034 & Group 44 1878*1032 1842*1021 & 1842*1024 & Group 48 1855*1029 & 1855*1032 Height of the frame（mm） 2113*995 & Group 23 2113*998 2130*1002 &...
  • Page 23 2168*1021 & 2168*1024 & Group 47 2182*1029 & 2182*1032 Table 6: Mechanical dimensions of modules installed with clamps on short side of frame Note：The installation method of clamps on long and short sides is based on the internal results in Jinko. According to IEC 61215 for a maximum positive design loading of below 1600Pa, and negative design loading 1600Pa, with 1.5 times safety factor.

  • Page 24: Wiring And Connections

    Group 41 2194*1034 & 2205*1032 Group 43 2194*1034 & 2205*1032 Table 7: Mechanical dimensions when modules installed at long side with Clamp fitting method According to IEC 61215 for a maximum positive design loading of below 3600Pa, and negative design loading 1600Pa, with 1.5 times safety factor.
  • Page 25 Figure 10：Ground installation of PV modules f) Follow the requirements of applicable local and national electrical codes. g) These modules contain factory installed by pass diode .If these modules are incorrectly connected to each other, the bypass diodes, cable or junction box may be damaged. h) The cable of the junction box is defined as L, as showed below in Figure 11.

  • Page 26: Maintenance And Care

    System voltage≥N*Voc[1+TCVoc* (Tmin-25)] Where module numbers in series Open circuit voltage (refer to product label or data sheet) TCVoc Temperature coefficient of open circuit voltage (refer to product label or data sheet) Tmin Minimum ambient temperature 4. Maintenance and Care It is required to perform regular inspection and maintenance of the modules, especially during the warranty period.

  • Page 27: Inspection Of Connector And Cable

    presents a shock hazard. e) Never use chemicals when cleaning modules as this may affect the module warranty and energy output. 4.3 Inspection of Connector and Cable It’s recommended to implement the following preventive maintenance every 6 months: a) Check the sealing gels of the junction box for any damage. b) Examine the PV module(s) for signs of deterioration.

  • Page 28: Appendix1： Applicable Products

    Appendix 1： Applicable Products This document is applicable to the series of solar modules as listed below: With 6” poly and mono c-Si: Group 1 ① ② ③ JKMxxxPP JKMxxxPP-60(Plus) JKMS xxxPP-60 JKMSxxxPP-60-J ④ JKMxxxPP-60-V JKMxxxPP-60(Plus) -V JKMSxxxPP-60-V JKMSxxxPP-60-V-J (xxx=260~290,in increment of 5) Group 2 ⑤...
  • Page 29 JKMSxxxM-60H-V-MX3 JKMSxxxM-60HB-V-MX3 JKMSxxxM-60H-MX3 JKMSxxxM-60HB-MX3 (xxx =270~340,in increment of 5) JKMSxxxM-60HL-V-MX3 JKMSxxxM-60HBL-V-MX3 JKMSxxxM-60HL-MX3 JKMSxxxM-60HBL-MX3 (xxx =270~340,in increment of 5) Group 9 JKMxxxM-60H-TV JKMxxxM-60HL-TV JKMxxxM-60H-T JKMxxxM-60HL-T (xxx =315~355,in increment of 5) JKMxxxN-60H-TV JKMxxxN-60HL-TV JKMxxxN-60H-T JKMxxxN-60HL-T (xxx =315~355,in increment of 5) Group 10 JKMxxxPP-72 JKMxxxPP-72(Plus) JKMSxxxPP-72...
  • Page 30 (xxx =335~395,in increment of 5) JKMSxxxM-72L-V-MX3 JKMSxxxM-72BL-V-MX3 JKMSxxxM-72L-MX3 JKMSxxxM-72BL-MX3 (xxx =335~395,in increment of 5) Group 17 JKMSxxxM-72H-V-MX3 JKMSxxxM-72HB-V-MX3 JKMSxxxM-72H-MX3 JKMSxxxM-72HB-MX3 (xxx =335~395,in increment of 5) JKMSxxxM-72HL-V-MX3 JKMSxxxM-72HBL-V-MX3 JKMSxxxM-72HL-MX3 JKMSxxxM-72HBL-MX3 (xxx =335~395,in increment of 5) Group 18 JKMxxxM-72H-TV JKMxxxM-72HL-TV JKMxxxM-72H-T JKMxxxM-72HL-T (xxx =375~425,in increment of 5) JKMxxxN-72H-TV JKMxxxN-72HL-TV...
  • Page 31 JKSN3-CCCA-xxx JKSN3-CHCA-xxx (xxx =345~370,in increment of 5) Group 29 JKMxxxM-72H-MBB-TV JKMxxxM-72H-MBB-T (xxx =385~405,in increment of 5) Group 30 JKMxxxM-60H-MBB-TV JKMxxxM-60H-MBB-T (xxx =320~335,in increment of 5) Group 31 JKMxxxM-78H-V JKMxxxM-78H (xxx =405-445,in increment of 5) Group 32 JKMxxxM-66H-V JKMxxxM-66H (xxx =340-375,in increment of 5) Group 33 JKMxxxM-78H-TV JKMxxxM-78H-T...
  • Page 32 Group 42 JKMxxxM-6RL3-T JKMxxxM-6RL3-TV-J JKMxxxM-6RL3-T-J JKMxxxM-6RL3-TV (xxx = 355~395,in increment of 5) Group 43 JKMxxxN-7RL3-T JKMxxxN-7RL3-TV-J JKMxxxN-7RL3-T-J JKMxxxN-7RL3-TV (xxx = 425~470,in increment of 5) Group 44 JKMxxxN-6RL3-TV JKMxxxN-6RL3-T JKMxxxN-6RL3-TV-J JKMxxxN-6RL3-T-J (xxx = 355~395,in increment of 5) Group 45 JKMxxxN-72H-MBB-V JKMxxxN-72H-MBB (xxx = 385~425,in increment of 5) Group 46 JKMxxxN-60H-MBB-V...

  • Page 33: Appendix2：Electrical Specifications

    glass: D facial: D Appendix 2：Electrical Specifications Rated Rated Max. Maximum Maximum Maximum Open- Short- Max. output Module Power at Power Power circuit circuit output current Type STC (Pmax, Voltage(Vmp Current(I Voltage(Vo Current(Is voltage (Optimized mp, A) c,V) c,A) (Optimize ) [A]: d) [V]: 31.1...
  • Page 34 32.6 9.21 40.1 9.98 32.8 40.3 10.07 40.5 10.15 33.2 9.49 40.7 10.23 33.4 9.59 40.9 10.31 33.6 9.68 41.1 10.5 33.8 9.77 41.3 10.61 9.86 41.5 10.73 34.2 9.95 41.7 10.82 34.4 10.03 41.9 10.91 34.6 10.12 42.1 11.00 31.4 38.4 9.29...
  • Page 35 33.68 9.95 40.73 10.53 33.88 10.04 40.84 10.64 34.07 10.13 40.94 10.73 34.16 10.25 41.1 10.82 34.32 10.35 41.2 10.93 37.4 8.56 45.3 9.21 37.6 8.66 45.5 9.28 37.8 8.74 45.8 9.35 8.82 46.1 9.43 Group 10 38.2 8.91 46.5 9.54 38.4 8.99...
  • Page 36 39.3 9.29 48.1 9.95 12.0 37.2 39.5 9.37 48.4 10.02 12.0 37.2 39.7 9.45 48.7 10.09 12.0 37.2 39.9 9.53 10.16 12.0 37.2 38.4 8.72 46.9 9.79 38.7 8.79 47.1 9.81 38.9 8.87 47.3 9.85 39.1 8.94 47.5 9.88 39.3 9.04 47.8 9.93...
  • Page 37 39.62 9.84 48.14 10.17 39.83 9.92 48.26 10.23 40.01 48.35 10.32 40.19 10.08 48.45 10.42 40.38 10.16 48.56 10.51 40.5 10.25 48.64 10.61 40.65 10.33 48.74 10.7 39.32 9.54 48.1 10.07 39.43 9.64 48.2 10.17 39.53 9.74 48.31 10.26 39.64 9.84 48.4 10.36...
  • Page 38 34.03 40.17 10.3 34.15 9.81 40.32 10.36 34.28 9.92 40.47 10.42 34.4 10.03 40.62 10.48 42.97 9.31 9.99 43.13 9.39 52.1 10.05 43.25 9.48 52.2 10.11 43.42 9.56 52.3 10.17 43.57 9.64 52.4 10.23 Group 23 43.73 9.72 52.5 10.29 43.88 9.80 52.60...
  • Page 39 37.32 10.05 44.70 10.44 37.44 10.15 44.80 10.55 43.3 9.24 10.05 43.41 9.33 52.1 10.1 43.53 9.42 52.2 10.15 43.64 9.51 52.3 10.2 Group 27 43.75 52.4 10.25 43.86 9.69 52.5 10.3 43.97 9.78 52.6 10.35 44.08 9.87 52.7 10.40 44.18 9.96 52.80...
  • Page 40 36.87 9.63 43.49 10.41 36.97 9.74 43.58 10.48 37.06 9.85 43.66 10.55 37.15 9.96 43.75 10.62 37.24 10.07 44.02 10.69 42.90 9.44 51.55 10.15 43.03 9.53 51.58 10.20 43.20 9.61 51.61 10.28 43.35 9.69 51.64 10.36 43.50 9.77 51.67 10.44 43.66 9.85 51.70...
  • Page 41 37.02 9.59 43.70 10.69 37.12 9.70 43.72 10.78 37.21 9.81 43.75 10.87 37.30 9.92 43.83 10.96 37.39 10.03 43.92 11.05 37.48 10.14 44.01 11.14 37.57 10.25 44.11 11.23 43.23 9.37 51.55 10.01 43.3 9.47 51.58 10.11 43.37 9.57 51.61 10.21 Group 37 43.44 9.67...
  • Page 42 42.92 10.02 51.30 10.81 42.99 10.12 51.40 10.90 43.06 10.22 51.50 10.99 43.13 10.32 51.60 11.08 43.19 10.42 51.70 11.17 43.25 10.52 51.80 11.26 43.32 10.62 51.90 11.35 43.38 10.72 52.00 11.44 43.44 10.82 52.10 11.53 36.49 9.73 43.32 10.45 36.55 9.85 43.41...
  • Page 43 39.86 9.91 48.20 10.54 39.96 10.01 48.35 10.60 40.06 10.11 48.50 10.66 40.16 10.21 48.65 10.72 40.26 10.31 48.80 10.78 40.35 10.41 48.95 10.84 40.44 10.51 49.10 10.90 33.03 9.69 39.95 10.40 33.13 9.81 40.08 10.46 33.24 9.93 40.21 10.52 33.37 10.04 40.34...
  • Page 44 Note ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ -42-...
  • Page 45 Zhejiang Province, China 314416 Tel: +86 21 5183 8777 Tel:+86 793 858 8188 Tel: +86 573 8798 5678 Fax: +86 21 5180 8600 Fax:+86 793 846 1152 Fax: +86 573 8787 1070 www.jinkosolar.com | Technic Support: technic@jinkosolar.com | After-sales: cs@jinkosolar.com...
