Status Annunciators

Measurement
12
READY
HOLD
ATC
ERR
Units of
mV
Indicators
R.mV
pH
ºC
ºF
Appears when the reading is stable
Appears in Setup mode and Calibration mode to
indicate that the relay function is frozen
Appears when Automatic Temperature Compensation
(ATC) is enabled.
Not visible when Manual Temperature Compensation
(MTC) is enabled.
Flashes if the temperature probe is faulty in its ATC
mode. (Refer Page 26)
Appears when an error occurs
Electrode annunciator. Appears when viewing
electrode properties or during calibration error
Buffer annunciator. Appears in calibration mode
Millivolt. Appears in ORP measurement/calibration
modes (Refer Page 14 & 22)
Relative Millivolt
Appears in pH measurement/calibration modes (Refer
Page 14 & 17)
Temperature in Celsius (Refer Page 26)
Temperature in Fahrenheit (Refer Page 26)
