Instrument cluster overview
1. Voltmeter
2. Speedometer
3. Service reminder indicators and
indicator lights
4. Tachometer
5. Engine oil pressure gauge
6. Engine coolant temperature gauge
2004 L/C100 from Aug '03 Prod. (OM60A04U)
7. Odometer and two trip meters
8. Trip meter reset knob
9. Fuel gauge
5
