Ford 2000 Grand Marquis Workshop Manual

2000 Crown Victoria/Grand Marquis Workshop Manual
SECTION 501-12: Instrument Panel and Console
REMOVAL AND INSTALLATION
Instrument Panel
Removal
CAUTION: Electronic modules are sensitive to static electrical charges. Avoid exposing any modules to static electrical charges, as this may cause damage to the
modules.
1. Remove the driver side air bag module. For additional information, refer to
2. Remove the passenger side air bag module. For additional information, refer to
3. Close the glove compartment.
4. Position the speed control servo aside.
1. Disconnect the electrical connector.
2. Remove the nuts.
3. Position the speed control servo aside.
5. Disconnect the LH engine compartment in-line electrical connector.
Release the wiring harness locators.
6. Disconnect the brake fluid sensor electrical connector.
7. Disconnect the windshield wiper motor electrical connector.
Release the wiring harness locators.
8. Disconnect the LH engine compartment in-line electrical connectors.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYA/~MUS~LEN/20/...
Section 501-20B.
Section 501-20B.
Page 1 of 17
2000 Crown Victoria/Grand Marquis Workshop Manual
Procedure revision date: 06/21/1999
8/20/2011
