Mazda CX-7 2015 Installation Instructions Manual

PART NUMBER (s):
0000-8F-M40
NOTE: BOTH VEHICLE IGNITION KEYS ARE REQUIRED AT TIME OF
INSTALLATION. DO NOT BEGIN INSTALLATION WITHOUT BOTH
KEYS.

HOOD SAFETY SWITCH KIT CONTENTS

P/N: 0000-8F-H03
Hood Safety
Switch
(QTY 1)
Locking
Washer
(QTY 2)
Wire Tie IDC Wire Tap
(QTY 2) (QTY 2)
IMMOBILIZER INTERFACE KIT CONTENTS
P/N: 0000-8F-H05A
Immobilizer Interface Adhesive Primer
Module and Harness (QTY-1)
(QTY-1)

TOOLS REQUIRED

SAFETY GLASSES
ELECTRICAL TAPE
WIRE CUTTERS
PLIERS
ALCOHOL or GLASS CLEANER
#2 PHILLIPS SCREWDRIVER
POWER DRILL
9/32" DRILL BIT
FIBER STICK
10 mm SOCKET AND RATCHET
1/4" SOCKET AND DRIVE
3/8" DRIVE TORQUE WRENCH
3/8" DRIVE 10mm SOCKET
HI-TEMPERATURE SILICONE
GENUINE ACCESSORIES
INSTALLATION INSTRUCTIONS
REMOTE START SYSTEM
1/4" Self
Remote Start
Drilling Screws
Control Module
(QTY 2)
(QTY-1)
P/N: 0000-8F-Z01
MAZDA
GENUINE ACCESSORIES
Vehicle Remote Start System
Owner's Manual
Featuring PowerCode Technology TM
TM For the Ultimate in Comfort, Convenience and Security
Owners
Manual
(QTY 1)
2- Sided Tape
(QTY-1)
0

VEHICLE PREPARATION

1. CLEAN HANDS
2. OPEN DRIVER'S DOOR WINDOW
3. RECORD RADIO STATION PRESETS
4. SET PARKING BRAKE
5. ENSURE VEHICLE WILL START UTILIZING THE IGNITION KNOB & VALET
KEY (SMART-KEY EQUIPPED VEHICLES ONLY)
6. DISCONNECT AND ISOLATE NEGATIVE BATTERY TERMINAL
7. VEHICLE MUST BE AT ROOM TEMPERATURE

KIT CONTENTS

DNA Card Remote Start
(QTY-1) Transmitters
(QTY-2)
P/N: 0000-8F-M21 P/N: 0000-8F-Z02
WARNING: / AVERTISSEMENT
This vehicle is equipped with a remote controlled engine starter.
To reduce the risk of serious Injury or death, switch engine starter
system into service mode and disconnect the vehicle battery
before performing any service on the vehicle.
Ce véhicule est doté d'un démarreur à distance. Pour réduire les
risques de blessures graves ou mortelles, mettre le démarreur à
distance en mode service et débrancher la batterie du véhicule
2 sec. avant d'effectuer des travaux d'entretien sur celui-ci.
5X
2 sec.
30
sec.
Underhood
Wallet
Sticker
Card
(QTY 1)
(QTY 1)
P/N: 0000-8F-Z12
Programming
Button
(QTY 1)
P/N: 0000-8F-Z03

PARTS BAG CONTENTS

Wire Tie
(QTY-10)
1
®
APPLICABLE MODELS
2007-UP > MAZDA CX-7
ALL MODELS
Dipole Antenna
(QTY-1)
P/N: 0000-8F-Z10
(QTY - (1) 5 AMP)
(QTY - (7) 15 AMP)
Long Wire
Tie
(QTY 4)
PVC Foam IDC Wire Tap
Tape (QTY-8)
(QTY 1)
P/N: 0000-8F-Z13
4280246 Rev. B 11/10
Remote Start
Wire Harness
(QTY-1)
P/N: 0000-8F-M41
Mini Fuses
