GENUINE Remote engine start
INSTALLATION INSTRUCTIONS
Thank you for purchasing a genuine Mazda accessory.
Before removal and installation, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly install and use the Remote engine
start. Your safety depends on it.
Keep these instructions with your vehicle records for future reference.
There are several
installing or removing the Remote engine start. Always read and follow them in order to prevent injuries,
accidents, and possible damage to the vehicle.
WARNING:
Indicates a situation in which serious injury or death could result if the warning
is ignored.
CAUTION:
Indicates a situation in which bodily injury or damage to the vehicle could result if the
caution is ignored.
For areas indicating the tightening torque in this instruction manual, tighten to the specified torque using
a torque wrench. For areas in which the tightening torque is indicated inside parentheses ( ), the
tightening torque is indicated as a reference value, however tightening using a torque wrench is not
necessary.
 Do not modify the Remote engine start.
 Do not install the Remote engine start in any way other than described in the following instructions.
 If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in
installation.
 If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice
before using it.
 Mazda and its suppliers are not responsible for injuries, accidents, and damage to persons and property
that arise from the failure of the dealer or installer to follow these instructions.
 To ensure safety and reliability of the work, installation, removal and disposal work must carried out by
an Authorized Mazda Dealership.
 Be careful not to lose removed parts, and be sure that they are kept free from scratches, grease or
other dirt.
PART NAME:
VEHICLE:
PART NUMBER:
NOTE
To the dealer
 Please turn over these instructions to the customer after installation.
To the customer
 Keep these instructions after installation. The instructions may be necessary
for installing other optional parts or removal of this accessory.
 Should the vehicle or this accessory be resold, always leave these instructions
with it for the next owner.
 When the remote engine start is removed, clear the remote engine start
information programmed to the vehicle by following the clearing procedure for
the advanced key in the workshop manual. In addition, after clearing, the
advanced key has to be programmed again.
WARNING
WARNING and
CAUTION sections in this booklet concerning safely when
Remote engine start
MAZDA CX-9
C960 V7 620
TK78 V7 630A (HARNESS KIT)
[KD53 V7 629A (Hood Switch)]
(CONTOROLLER KIT)
1
ZZ092-00915
(ZZ092-00916)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C960 V7 620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mazda C960 V7 620

  • Page 1  Do not modify the Remote engine start.  Do not install the Remote engine start in any way other than described in the following instructions.  If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in installation.
  • Page 2: Installation View

    1. PARTS ▼ Installation view (Sold separately) Hood switch (Only for vehicle without theft-deterrent or without i-ELOOP system) Antenna harness RES ECU Harness Harness (GND wire)
  • Page 3 ▼ Parts list Note  Verify that the kit includes all the following parts and that the parts are not dirty, scratched, or damaged.  CONTOROLLER KIT (Part No. C960 V7 620) Part Part name Qty. Part Part name Qty.
  • Page 4: Before Installation

    2.BEFORE INSTALLATION REQUIRED TOOLS  ☆Socket wrench ☆Torque wrench ☆Tape-wrapped flathead screwdriver ☆Nipper ☆Electrical vinyl tape ☆Soft clean cloth ☆Pliers ☆Scale ☆IPA (Isopropyl alcohol) ☆Primer (3M Promoter-4298) ☆Mat WARNING When the negative battery is Before performing any work, When connecting/dis- Make sure the connector is connected during operation, may park the vehicle on level ground,...
  • Page 5 3.CONNECTION USING ELECTRO-TAP ■ Branch connection procedure using electro tap Accessory Terminal Electro tap part wiring 1. Completely insert the vehicle wiring harness, which is to be harness connected, into the guide groove. 2. Completely insert the accessory part wiring harness into the guide groove.
  • Page 6: Connection Diagram

    4.CONNECTION DIAGRAM KIT ACCESSORY ELECTRO TAP Insert to empty terminal Figure shows connector viewed from harness side.
  • Page 7 5.PART REMOVAL CAUTION  Be careful not to damage or lose any parts removed from the vehicle since they will be reused. Negative battery cable disconnection Negative battery cable 1. Set the selector lever to the P position. (AT vehicles only) WARNING ...
  • Page 8 [2] Hood latch protector removal Flathead screwdriver 1. Insert a tape-wrapped flathead screwdriver into the Hood latch protector position shown in the figure. 2. Move the tape-wrapped flathead screwdriver in the direction of arrow (1) shown in the figure to press the hood latch protector tab, and lift the tab up in the direction of arrow (2) and detach its tab from the hood latch.
  • Page 9 [5] Relay and fuse block upper cover removal Relay and fuse block upper cover 1. While pressing the relay and fuse block upper cover hook in the direction of the arrow (1) shown in the figure, lift up the relay and fuse block upper cover in the direction of the arrow (2) to detach the relay and fuse block upper cover hook from the relay and fuse block middle cover tab.
  • Page 10 3. Hold the shaded area shown in the figure, move the front scuff plate in the direction of the arrow in the order of (1), (2) and remove it while detaching clips from the inner panel, and pull out the pins. Clip Front scuff plate Clip...
  • Page 11 Passenger-side front side trim removal 1. Partially peel back the seaming welt. Seaming welt Vehicle front 2. Remove the cap nut. Cap nut Front side trim Vehicle front 3. Pull the front side trim out of the stud bolt. 4. Hold the shaded area shown in the figure, move the Clip front side trim in the direction of the arrow, and detach the clip.
  • Page 12 Dashboard under cover removal 1. With the end of the hook pressed out in the direction of arrow (1) shown in the figure, move the dashboard panel under cover in the direction of End of hook arrow (2) and detach the hooks and pins. Hook Guide CAUTION...
  • Page 13 4. Pull down the glove compartment in the direction of the arrow (1). 5. Pull the glove compartment in the direction of the Hook arrow (2) and remove it while detaching hooks. Glove compartment Vehicle front Glove compartment Hook Passenger-side lower panel Passenger-side A-pillar trim removal 1.
  • Page 14 3. Cut the lead wire connecting clip A and grommet Grommet using a nipper. Nipper Lead wire Clip A A-pillar trim Vehicle front 4. Pull the A-pillar trim in the direction of the arrow shown in the figure while detaching the guides. A-pillar trim Guide Vehicle front...
  • Page 15: Hood Switch Installation

    6. HOOD SWITCH INSTALLATION Note  This procedure is not necessary for vehicles with the theft deterrent or with i-ELOOP system because the hood switch is already installed. 1. Install the hood switch to the hood latch and secure it Do not let hood switch harness using the supplied screw.
  • Page 16 5. Apply the mount base to the shroud panel and secure the hood switch harness with a tie wrap (Black). Hood switch harness 6. Route the hood switch harness along the vehicle Shroud panel wiring harness and secure it using a tie wrap (Black) at 1 location.
  • Page 17 8. Insert the hood switch harness (White) terminal to [ Vehicle wiring harness 18 pin connector ] the empty terminal of the vehicle wiring harness 18 (Connector viewed from wiring harness side) pin connector (terminal CAUTION  When connecting a terminal to a connector, always refer to the following <Terminal insertion procedure>.
  • Page 18 10. Route the hood switch harness along the vehicle wiring harness and secure it using a tie wrap (Black) at 1 location. Vehicle wiring harness Hood switch harness Vehicle front ▲ Tie wrap (Black) 1P 7.PREPARATION FOR REMOTE ENGINE START INSTALLATION 1.
  • Page 19 8.REMOTE ENGINE START INSTALLATION 1. Degrease the RES ECU installation position using RES ECU IPA, and affix double-sided adhesive tape of the installation position RES ECU. Vehicle front RES ECU 【INSTALLATION OF THE HARNESS】 ①  Secure the antenna harness to the vehicle wiring harness using tie wraps (White).
  • Page 20 ➁  Connect the harness to the vehicle wiring harness.  Secure the harness to the vehicle wiring harness and dashboard member using a tie wraps (White).  Secure the antenna harness and harness to the vehicle wiring harness using a tie wrap (White).
  • Page 21 ➂  Connect the antenna harness and harness to the RES ECU.  Pass the tie wrap (White) through the RES ECU hole and secure the antenna harness to the RES ECU at one point.  Bundle the antenna harness and harness together at one point with a tie wrap (White).
  • Page 22: Operation Check

    2. Perform the Engine start operation with the remote control, and verify the vehicle engine is started. 3. If Steps 1 to 2 cannot be completed successfully, refer to the "Troubleshooting manual" issued by Mazda. ※ The troubleshooting manual is posted on the site for servicing personnel.
