GENUINE REMOTE ENGINE START
Thank you for purchasing a genuine Mazda accessory.
Before use, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly use the Remote Engine
Start. Your safety depends on it.
After using this instruction manual, store it in a place where it can be easily located.
Note, consult your authorized Mazda dealer, or a dealer appointed store, for proper
vehicle installation of the Remote Engine Start.
If the vehicle equipped with this product, or the product itself, is sold, transferred or
loaned to another party, be sure to give this instruction manual to the new owner, so he
or she can use this product safely and correctly.
<Safe and correct use of the product>
Various warnings and cautions are displayed in this manual to assist you in the safe
and correct use of the product and as precautions against you or others being injured,
or the product being damaged.
Depending on the degree of possible injury or damage that may be incurred,
precautionary items have been divided into 'Warnings' and 'Cautions' and illustrated
with symbols to depict the nature of the precautionary content.
WARNING
CAUTION
ADVICE
NOTE
USER'S INSTRUCTIONS
Parts number
A WARNING indicates a situation in which serious injury or
death could result if the warning is ignored.
A CAUTION indicates a situation in which bodily injury or
damage to objects, or both, could result if the caution is
ignored.
Always follow the ADVICE noted to ensure vehicle safety
and performance. Vehicle damage could result, or proper
performance may be compromised if the advice is ignored.
A NOTE indicates information or a point related to vehicle
usage. Vehicle damage could result, or proper
performance may be compromised if the note is ignored.
：BCKA V7 620
No. : ZZ092-00971
GB
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mazda BCKA V7 620
Summary of Contents for Mazda BCKA V7 620
- Page 1 Start. Your safety depends on it. After using this instruction manual, store it in a place where it can be easily located. Note, consult your authorized Mazda dealer, or a dealer appointed store, for proper vehicle installation of the Remote Engine Start.
-
Page 2: Table Of Contents
CONTENTS 1. Remote Engine Start features ..............3 2. Safety precautions .................. 3 3. General information ................6 4. Operating precautions ................7 5. Part names ..................... 9 6. Basic functions for Remote Engine Start ..........10 7. Low battery warning & replacement directions ........12 8. -
Page 3: Remote Engine Start Features
1. Remote Engine Start features The Remote Engine Start allows the user to start the engine of a vehicle from a remote location using a remote control. The user can turn on the air conditioner / heater beforehand so the ... - Page 4 WARNING Do not start up the engine using the Remote Engine Start when parked on an incline. If the vehicle were to move unintentionally due to the engine vibration, jolt, etc., it could result in a serious accident. Performing safe maintenance and inspection. When performing vehicle inspection and ...
- Page 5 WARNING Fire prevention. Do not start the engine when the vehicle is near something flammable (oil or dry grass). Otherwise, the high temperature from the exhaust fumes or exhaust pipe could cause a fire. Do not start the engine while the vehicle is ...
-
Page 6: General Information
Guidelines and RSS-102 of the ISED radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. -Consult your authorized Mazda dealer for installation of the remote control engine engine starter system. -
Page 7: Operating Precautions
4. Operating precautions Usage Environment The remote control signal (or the response signal from the controller) may not reach the controller (or the remote control) if there are strong radio waves transmitting nearby, or if there are obstacles blocking the signal. The engine may be slow to start during severe cold weather conditions. - Page 8 Remote Control Handling Instructions The remote control is a sensitive electronic device similar to a cellular telephone. Please follow the handling instructions below to avoid damage to or breakdown of the remote control. Avoid storing or using the remote control in places that expose it to direct sunlight, ...
-
Page 9: Part Names
5. Part names ■ Remote Control CAUTION Keep the remote control out of the reach of children. Otherwise, they may swallow the lithium battery accidentally and choke. Do not drop the remote control or hit it against something hard. Otherwise, it ... -
Page 10: Basic Functions For Remote Engine Start
6. Basic functions for Remote Engine Start Engine Start & Stop Function The remote control is equipped with engine start, engine stop and automatic stop (set with timer) functions. In addition, the engine start operation will perform when conditions outlined on page 13 are Engine start →... - Page 11 Car Find Function When using the remote control to carry Car find out car find operations, the hazard warning lights will flash twice and the horn will sound twice to allow you to confirm the location of the vehicle. This function is useful for finding your Directions for car find vehicle in places such as large car...
-
Page 12: Low Battery Warning & Replacement Directions
7. Low battery warning & replacement directions If the battery power is depleted, the LED light (red) turns on when a switch is pressed and battery power depleted is indicated. In this case, as battery replacement will be required soon, replace the batteries with new ones according to the following procedure. -
Page 13: Basic Operations
8. Basic operations Engine Start Conditions When using the Remote Engine Start, be sure to always check the start conditions listed below beforehand. Even if just one of the conditions has not been satisfied, the device will interpret this as a hazard and will not operate. -
Page 14: Engine Start Operation
8-1. Engine start operation Operation Indication Press START switch while LED light (green) is flashing (approx. 3 Press F switch seconds) LED light color: Engine start Green Engine not started* or Press switches until sound is heard. Communication error ... -
Page 15: Engine Stop Operation
8-2. Engine stop operation Operation Indication Press STOP switch while LED light (green) is flashing Press F switch (approx. 3 seconds) LED light color: Engine stop Green Engine not stopped* or Communication error Press switches until sound is heard. ... -
Page 16: Warm Up Time Check
8-3. Warm up time check Operation Indication Press START switch while LED light (green) is flashing (approx. 3 seconds) Press F switch LED light color: See table below Press switches until sound is heard. Release F switch when beep sound is heard The remaining time until the engine turns off automatically is indicated by the number of times the LED light flashes. -
Page 17: Warm Up Time Settings
8-4. Warm up time settings Operation Indication Press START switch Press switch while and STOP switch at LED light (green) same time until LED flashes (approx. 3 light (green) flashes seconds) LED light color 10-minute warm- Press the 10 minutes START and Green STOP... -
Page 18: Engine Start Operation With Rear Defrost Start Up
8-5. Engine start operation with rear defrost start Up When the engine is started using this operation, the rear defrost operates. Operation Indication Press F switch Press START switch Press F switch while while LED light LED light color LED light (green) is (green) is flashing flashing (approx. -
Page 19: Car Find Function
8-6. Car find function If this operation is carried out when the engine is stopped or after the engine has been started by remote control, the vehicle's hazard warning lights will flash twice and the horn will sound twice. Operation Indication Press F switch LED light color... -
Page 20: Troubleshooting
check the following items in the table below. If the error or problem persists, do not try to repair the device by yourself. Consult with the authorized Mazda dealer where you purchased the vehicle or device. Problem Check Item... - Page 21 Problem Check Item Troubleshoot The wipers do not The wipers will not operate when the operate when the engine is started with Remote Engine engine is started with Start, even if the wiper switch is at the ― Remote Engine Start "AUTO"...
- Page 22 Problem Check Item Troubleshoot Rear defrost does Did you make a mistake Refer to the "Engine start operation with not operate by with the "Engine start with rear defrost start Up" section on P.18. remote control rear defrost start Up" operation operation on the remote control?
- Page 23 Problem Check Item Troubleshoot Remote control Have the batteries run Replace the batteries with new ones. operating distance is out? (Refer to P.12) short Are you too far from the Approach the vehicle and try operating vehicle? the remote control. Is there something Move and try operating the remote blocking the signal...
-
Page 24: Servicing
If you are having a problem with the device, first re-read this instruction manual again to troubleshoot the problem or issue. If the problem or issue does not improve, consult with the authorized Mazda dealer where you purchased the vehicle or device. If you lose the remote control, contact the authorized Mazda dealer where you purchased the vehicle or device. - Page 25 MEMO...
- Page 26 MEMO...
- Page 27 MEMO...
- Page 28 Request for Dealer Performing Installation Service Be sure to explain the device operation to the customer. Quick Reference Manual ・To start the engine LED (green) illuminates Press Press Within 3 seconds ・To stop the engine LED (green) illuminates Press Press Within 3 seconds Note that some contents of this instruction manual may not match the ...
