GENUINE Mazda Mobile Start
INSTALLATION INSTRUCTIONS
Thank you for purchasing a genuine Mazda accessory.
Before removal and installation, be sure to thoroughly read these instructions. Please read the contents of this
booklet in order to properly install and use the Mazda Mobile Start. Your safety depends on it.
Keep these instructions with your vehicle records for future reference.
•
There are several
WARNING and
removing the Mazda Mobile Start. Always read and follow them in order to prevent injuries, accidents, and possible
damage to the vehicle.
WARNING:
Indicates a situation in which serious injury or death could result if the warning is ignored.
CAUTION:
Indicates a situation in which bodily injury or damage to the vehicle could result if the caution is ignored.
•
For areas indicating the tightening torque in this instruction manual, tighten to the specified torque using a torque wrench. For
areas in which the tightening torque is indicated inside parentheses ( ), the tightening torque is indicated as a reference value,
however tightening using a torque wrench is not necessary.
•
Do not modify the Mazda Mobile Start.
•
Do not install the Mazda Mobile Start in any way other than described in the following instructions.
•
If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in installation.
•
If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice before using it.
•
Mazda and its suppliers are not responsible for injuries, accidents, and damage to persons and property that arise from the
failure of the dealer or installer to follow these instructions.
•
To ensure safety and reliability of the work, installation, removal and disposal work must be carried out by an Authorized
Mazda Dealership.
•
Be careful not to lose removed parts, and be sure that they are kept free from scratches, grease or other dirt.
NOTE
To the dealer
• Please turn over these instructions to the customer after installation.
To the customer
• Keep these instructions after installation. The instructions may be necessary for
installing other optional parts or removal of this accessory.
• Should the vehicle or this accessory be resold, always leave these instructions
with it for the next owner.
WARNING
CAUTION sections in this booklet concerning safety when installing or
PART NAME :
VEHICLE :
PART NUMBER :
Mazda Mobile Start (MMS)
Mazda 6
0000-8F-Z80 (MMS ECU Kit)
0000-8F-H28 (MMS Harness Kit)
[KD53-V7-629 (Hood Switch)]
1
090003-33260700
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mazda 0000-8F-H28
Summary of Contents for Mazda 0000-8F-H28
- Page 1 If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in installation. • If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice before using it. •...
-
Page 2: Installation View
1. INSTALLATION VIEW (Sold separately) Hood switch (Only for vehicles without theft-deterrent or without i-ELOOP system) TEL Antenna GPS Antenna GPS & TEL Antenna Cables MMS ECU MMS 2P Connector Harness (GND) MMS Harness LED Connector RES Diagnostic Connectors... - Page 3 MMS Key Tag adhesive tape (25 x 69mm) (25 x 25mm) : Part marked with a star mark is not used for this vehicle. « Owner's Manual HARNESS KIT (Part no. 0000-8F-H28) Part Part Name Qty. Part Part Name Qty.
-
Page 4: Before Installation
3. BEFORE INSTALLATION REQUIRED TOOLS • 10mm Socket Wrench • Scissors • Torque Wrench • Taped Flathead Screwdriver • Mat • Electrical Tape • Panel Removal Tool • Soft clean cloth • Squeegee • Glass Cleaner • Nipper • Pliers •... -
Page 5: Connection Diagram
MMS ECU RES Connector RDIG GND (M6) Connector to Connector VEHICLE CONNECTOR 20XX- MAZDA MAZDA MOBILE START (MMS) MMS Wire Vehicle Wire CONNECTORS Scotch lock connection MMS or Vehicle Terminal Insert (TERMINAL PIN) ( FEMALE PIN ) (FEMALE PIN) ( FEMALE PIN ) -
Page 6: Vehicle Disassembly
6. VEHICLE DISASSEMBLY Note • Be careful not to damage or lose any parts removed from the vehicle since they will be reused. Place the vehicle in park with the parking brake engaged. Disconnect negative battery terminal and wrap tape around it to insulate. - Page 7 Remove Glove box by detaching 2 bottom Hooks. Hook Vehicle front Hook Remove Glove box under cover in order of arrows (1) - (3). Hook A Guide C Pin B Pin B Vehicle front Hook A Passenger side lower panel removal Remove 2 Bolts.
- Page 8 A-Pillar trim removal Clip B Clip B Partially peel back the seaming welt. Dislodge the Passenger side A-pillar trim by pulling on the shaded area to disengage Clip B and A. Clip B Clip B Caution • Do not use excessive force, A-pillar could be damaged. Clip A Clip A Passenger Side A-Pillar...
-
Page 9: Hood Switch Installation
7. HOOD SWITCH INSTALLATION Note • This procedure is not necessary for vehicles with Theft-deterrent System or with i-ELOOP system because the hood switch is already installed. Remove 2 Fasteners from the Vehicle Set Plate. Fastener Guides Fastener Remove the Vehicle Set Plate. Set plate Vehicle Front Remove the Hood Latch Cover. - Page 10 Remove 2 Bolts from the Fresh air duct. Bolts Bolt tightening torque: 7.8 - 10.8 N•m (5.7 - 7.9 ft•lbf) Fresh air duct Vehicle Front Lift Fresh Air duct to remove Fastener. Fresh air duct Fastener Grille bracket Remove 1 Fastener and 2 Screws. Fastener Screw tightening torque: 4.0 - 9.8 N•m (2.9 - 5.8 ft•lbf) Screw...
- Page 11 Hook the Hood switch harness to the Hood latch and Do not let hood switch harness secure it using a wire tie (black). make contact with bolt 10. Peel the tape backings from the harness clamps and affix Harness Clamp them on the upper shroud member on 2 locations.
- Page 12 <Terminal insertion procedure> (b) Insertion terminal <Terminal insertion procedure> Vehicle wiring harness 18 pin connector Terminal Retainer Terminal Retainer (a) Remove retainer Hood switch harness (White) Terminal Terminal (c) Reinstall retainer 16. Insert the Hood switch harness (White) terminal to the [Vehicle wiring harness 18 pin connector] empty terminal of the Vehicle wiring harness 18 pin (Connector viewed from wiring harness side)
- Page 13 8. MAZDA MOBILE START INSTALLATION Degrease the MMS ECU using primer; apply primer only Double-sided to indicated areas where tape is attached on both sides. Adhesive tape Caution MMS ECU • Use 3M Promoter-4298 for primer. • When degreasing using primer, only apply primer to indicated area to prevent other parts from becoming discolored.
- Page 14 10. Plug in the MMS harness 24P connector to the MMS ECU. 11. Place the Antenna template face down on the windshield outside the vehicle, aligning the top with the headliner and the side to the passenger side A-pillar and temporarily secure it with electrical tape.
- Page 15 15. Carefully and slowly peel off the top protective sticker leaving only the GPS Film Antenna on the Windshield. Top Protective Sticker Top Protective Sticker Caution • Do not touch the GPS Film Antenna Terminal. GPS Film Antenna GPS Film Antenna After installing the GPS Film Antenna, proceed to the next step to install the TEL Film Antenna.
- Page 16 20. Cut 2 urethane foam tapes into 4 pieces of 1/2 sized urethane foam tapes. GPS Connector 21. Wrap the GPS Connector cable with 1/2 piece of urethane 3 x 1/2 Urethane Foam tape foam tape 50mm away from the GPS Connector. 22.
- Page 17 28. Tuck both Antenna cables in between the headliner and GPS Connector Cable the windshield routing them toward the passenger side A-pillar area. Vehicle Headliner TEL Antenna Cable 29. Route the Antenna cables down the passenger side A-pillar GPS & TEL Antenna Cables and secure to the vehicle harness using 4 wire ties (white).
- Page 18 34. Continue routing the Antenna cables from the A-pillar behind the IP reinforcement bar. IP reinforcement bar GPS & TEL Antenna Cables Vehicle right 35. Route the Antenna Cables behind the vehicle bracket towards the MMS ECU. GPS & TEL Antenna Cables Vehicle Bracket MMS ECU Vehicle front...
- Page 19 40. Bundle up the excess Antenna Cables and secure to the vehicle harness using 2 wire ties (white). 2 x Wire Ties (White) Vehicle Harness GPS & TEL Antenna Cables 41. Connect the LED to the MMS Harness 2P White connector. MMS Harness Complete Section 9 {MMS Registration Procedure} &...
- Page 20 9. MMS REGISTRATION PROCEDURE Make sure of the following conditions: In possession of 2 Advanced Keys that are already registered to the vehicle. Do not open any doors during MMS registration procedure. Response Response Steps MMS Registration Procedure when when it fails successful Connect the negative battery cable and close the hood.
- Page 21 10. MMS CHECK MODE The following procedure is performed to verify MMS operation after MMS registration. Make sure that MMS Registration was successful prior to proceeding. MMS check mode preparations: Place 1 Advanced Key at least 5 feet away from the vehicle and keep 1 Advanced key in your possession. Enter vehicle passenger's side and leave the door open.
- Page 22 11. REINSTALLATION / INSPECTION Disconnect the LED from the MMS Harness and discard. MMS harness Secure MMS harness LED connector and ground wire to the vehicle harness with 1 wire tie (white). Secure the RES Diagnostic connectors to the vehicle harness with 1 wire tie (white).
- Page 23 Mazda Mobile Start (MMS) INSTALLATION MAZDA 6 0000-8F-Z80 (MMS ECU Kit) INSPECTION 0000-8F-H28 (MMS Harness Kit) SHEET KD53-V7-629 (Hood Switch) Perform the following inspections. WARNING • Before starting the engine, make sure there are no persons in front of or behind the vehicle, or around the engine compartment.
