PCM 81
External Memory Card
Connector: Accepts PCMCIA Type I
cards, 68 pins
Standards: Conforms to PCMCIA
2.0 / JEIDA 4.0
Card Format: Supports up to 1MB
SRAM (attribute memory
not required)
Control Interface
MIDI: 5-pin DIN connectors
provided for MIDI IN,
THRU, and OUT
Footswitch: 1/4 inch T/R/S phone
jack provided for 2
independent momentary
footswitches
System detects normal-
open, or normal-closed
on power up
Foot Controller: 1/4 inch T/R/S phone
jack provided for
footpedal (100Ω
minimum, 10kΩ
maximum impedance)
General
Dimensions:
Width: 19.0 inches (483mm)
Height: 1.75 inches (45mm)
Depth: 12.0 inches (305mm)
19 inch rack mount
standard, 1U high
Weight:
Net: 6.4 lbs (2.9 kg)
Shipping: 9.5 lbs (4.3 kg)
Power 100-240 VAC, 50-60Hz,
Requirements: 35 W, 3-pin IEC power
connector
RFI/ESD: Conforms to FCC Class B,
EN55022 Class B (CE),
IEC 801-2, IEC 801-3
Environment:
Operating 32 to 104˚F
Temperature: (0 to 40˚C)
Storage -22 to 167˚F
Temperature: (-30 to 70˚C)
Humidity: Maximum 95% without
condensation
Appendix
Note:
Unless otherwise noted, all audio
specifications assume rear-panel
switch set to BAL, input level
control is set for unity gain (0dB),
and analog I/O connections wired
for balanced configuration.
Specifications subject to
change without notice.
