Summarization of Contents
Getting Started
Unpacking and Inspection
Inspect packaging and printer upon receipt. Retain materials for potential reshipment.
Equipment Checklist
Lists all included items such as printer, CD, cables, power supply, and accessories.
Printer Parts
Front View
Illustrates and labels the front components of the printer.
Rear View
Illustrates and labels the rear components of the printer, including interfaces.
Setup
Setting Up the Printer
Step-by-step guide for placing the printer, connecting cables, and plugging in the power.
Loading Label Stock
Instructions for inserting a label spindle and feeding the label roll correctly.
Peel-Off Installation Assembly (Option)
Guide for installing the optional peel-off module, involving screw removal and harness connection.
Loading Label for Peel-off Mode (Option)
Steps to thread and load labels when the optional peel-off module is installed.
External Label Roll Mount Installation (Option)
Instructions for attaching and using an external label roll mount.
Cutter Module Installation (Option)
Guide for installing the optional cutter module, involving disassembly and component connection.
Loading Label in Cutter Mode
Steps for loading labels when the optional cutter module is installed.
Diagnostic Tool
Utility for exploring settings, changing configurations, and troubleshooting.
Setting Ethernet by Diagnostic Utility (Option)
Guide to configuring Ethernet settings using the diagnostic utility via USB, RS-232, or Ethernet interfaces.
Install Memory Card
Instructions for installing an SD card into the printer's main board.
Power on Utilities
Gap/Black Mark Sensor Calibration
Steps to calibrate the gap/black mark sensor sensitivity for accurate media detection.
Gap/Black Mark Calibration, Self-test, Dump Mode
Procedure for calibration, running self-test, and entering dump mode.
Printer Initialization
Process to clear DRAM and restore printer settings to their default values.
Set Black Mark Sensor as Media Sensor and Calibrate the Black Mark Sensor
Steps to configure the black mark sensor as the media sensor and calibrate it.
Set Gap Sensor as Media Sensor and Calibrate the Gap Sensor
Steps to configure the gap sensor as the media sensor and calibrate it.
Skip AUTO.BAS
Method to interrupt the AUTO.BAS program execution during printer power-on.
Maintenance
Cleaning
Presents tools and methods for cleaning the printer's print head, platen roller, and exterior.
Troubleshooting
LED Status
Lists common problems based on LED status and provides recovery procedures.
Print Quality
Details common issues affecting print quality and their corresponding solutions.
LED and Button Operation
LED
Describes the meaning of different LED colors and their illumination states.
Button Operation
Explains the functions of the printer's button for feeding, pausing, and other operations.
