Standard (ATX) connection setup
This section describes how to connect your monitors to a standard (ATX) Matrox graphics card.
Connector overview
TV output adapter
Composite video
connector
* Matrox Millennium P650 and P690 products include 2 DVI-to-HD15 adapters, but no dual-monitor cable. For Millennium
P650, TV output adapters are sold separately (see http://shopmatrox.com).
Note:
monitor that uses digital input, usually a
flat panel monitor) to your Matrox
product, your monitor must have a DVI
connector.
If you have an analog monitor (a monitor
that uses analog input) with a DVI
connector and you want to connect it to
an HD-15 connector, you'll need a separate adapter. If this adapter isn't included with your
monitor, contact your monitor vendor.
Some monitors with DVI connectors support both digital and analog input. If you're using
one of these monitors with your Matrox product, make sure it's configured to use the
correct type of input. For more information, see your monitor documentation.
6 Matrox graphics card – User Guide
HD-15 connector
( )
2
*
S-video connector
To connect a digital monitor (a
Dual-monitor cable
*
(DVI-to-HD15)
HD-15 connector
( )
1
DVI connector
(digital)
Secondary ( ) connector (DVI)
B
Main (
connector
DVI-to-HD15
*
adapter
HD-15 connector
(analog)
DVI connector
(analog/digital)
)
A
(DVI)
