DC-1 Version 3 Digital Controller
5.1 Logic 7 combines all the features of Dolby Digital AC-3 with enhance-
ments by Lexicon and LucasFilm. This effect uses Logic 7 matrix technology
to enhance the steering between the side speakers and the rear speakers, so
sounds intended to come from behind the listener actually do come from
behind. This effect also includes the adaptive decorrelation and re-equal-
izer features of THX 5.1.
5.1 Logic 7 provides the ultimate in film reproduction. It brings out all the
increased excitement and spaciousness a 7 channel speaker system can
produce.
Parameter
AC-3 STATUS (display only — not user adjustable)
COMPRESSION
VOCAL ENHANCE
RE-EQUALIZER
BASS ENHANCE
REAR DELAY OFFSET
SIDE LEVEL
REAR LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
The Dolby Digital effect decodes Dolby AC-3 encoded soundtracks. Unlike
analog Dolby surround decoding, Dolby Digital uses five discrete full-
range channels and a sixth dedicated, Low Frequency Effect (LFE) channel.
In this effect, any rear speakers present are connected in parallel with the
side speakers. This is the basic Dolby AC-3 effect. It does not include the
enhancements by Lexicon or LucasFilm which are available with other AC-
3 effects in the DC-1.
Parameter
AC-3 STATUS (display only — not user adjustable)
COMPRESSION
VOCAL ENHANCE
BASS ENHANCE
SIDE LEVEL
REAR LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
Initial Value
OFF OFF, ON, AUTO
+0.0dB +0.0dB, +3.0dB, +6.0dB
ON
OFF
5ms
+00dB OFF, -80dB to +5dB
+00dB OFF, -80dB to +5dB
+0.0dB -10.0dB to0.0dB
+00dB OFF, -79dB to +5dB
Initial Value
OFF OFF, ON, AUTO
+0.0dB +0.0dB, +3.0dB, +6.0dB
OFF
+00dB +5 to -80dB, Off
+00dB OFF, -80dB to +5dB
+0.0dB -10.0dB to +0.0dB
+00dB OFF, -79dB to +5dB
AC-3 Effects and Parameters

5.1 Logic 7

Range
ON, OFF
ON, OFF
0-20ms

Dolby Digital

Range
ON, OFF
