DC-1 Version 3 Digital Controller
The PCM effects are compatible with two-channel input signals (analog or
digital). These effects are included in both the Dolby Digital and the DTS
versions of the DC-1.
Panorama extracts the natural ambience from recorded music and moves it
outward from the speakers, producing greater width and depth of image
and a feeling of enhanced spaciousness. This mode adds no additional
sound but expands the existing stereo image. Panorama also works with
Dolby Stereo movies, bringing the surround track outward into the room.
The location of the front speakers and the listening position are crucial to
Panorama's effectiveness and for best results your system and the DC-1
together should be set up and calibrated according to the procedure in
Chapter 2. The strength of the Panorama effect drops off as you move away
from the prime listening position, especially to the sides. Video systems
with the main loudspeakers spaced closely on either side of a TV screen will
produce a usable effect over a somewhat wider area than set-ups with a
large included angle between the speakers.
Parameter
INPUT BALANCE
CENTER LEVEL
REAR ROLLOFF
REAR DELAY
SURROUND LEVEL
BASS CONTENT
LOW FREQ WIDTH
SUBWOOFER LVL
EFFECT LEVEL
CUSTOM
The Nightclub effect generates the appropriate early reflections for stereo
simulation of many different intimate spaces, and sends the reflections to
the front, side and rear speakers.
Parameter
CENTER LEVEL
SPEECH DETECT
HALL SIZE
LIVENESS
ROLLOFF
SUBWOOFER LVL
EFFECT LEVEL
CUSTOM
Initial Value
(Centered) Full Left-Full Right
4
4.9kHz 453Hz-20.0kHz
10ms
12
MONO STEREO, MONO, BINAURAL
0
+00dB OFF, -79dB to +05dB
62
Initial Value
9
OFF
4 Meters
4
9.7kHz 453Hz-20.0kHz
+00dB OFF, -79dB to +5dB
+02dB
PCM Effects and

PCM Effects and Parameters

Range
0-15
0-32ms
0-32
-25 to +25
0-62
Range
0-15
ON/OFF
4-17 Meters
0-6
-30 to +05dB
3
Parameters

Panorama

Nightclub

35
