DTS Effects and Parameters

DTS Logic 7

DTS Film

52
DTS Logic 7 combines all the features of DTS Digital with enhancements by
Lexicon and LucasFilm. This effect uses Logic 7 matrix technology to
enhance the steering between the side speakers and the rear speakers, so
sounds intended to come from behind the listener actually do come from
behind. This effect also includes the adaptive decorrelation and re-equal-
izer features of DTS THX.
DTS Logic 7 provides the ultimate in film reproduction. It brings out all the
increased excitement and spaciousness a 7 channel speaker system can
produce.
Parameter
VOCAL ENHANCE
RE-EQUALIZER
BASS ENHANCE
REAR DELAY OFFSET
SIDE LEVEL
REAR LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
The DTS Film effect decodes DTS-encoded soundtracks. It uses five discrete
full-range channels and a sixth dedicated, Low Frequency Effect (LFE)
channel. In this effect, any rear speakers present are connected in parallel
with the side speakers. This is the basic DTS effect. It does not include the
enhancements by Lexicon or LucasFilm which are available with other AC-
3 effects in the DC-1.
Parameter
VOCAL ENHANCE
RE-EQUALIZER
BASS ENHANCE
SIDE LEVEL
REAR LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
Initial Value
+0.0dB +0.0dB, +3.0dB, +6.0dB
On
OFF
5ms
+00dB OFF, -80dB to +5dB
+00dB OFF, -80dB to +5dB
+0.0dB -20.0db to0.0dB
+00dB OFF, -79dB to +5dB
Initial Value
+0.0dB +0.0dB, +3.0dB, +6.0dB
ON
OFF
+00dB OFF, -80dB to +5dB
+00dB OFF, -80dB to +5dB
+0.0dB -20.0db to +0.0dB
+00dB OFF, -79dB to +5dB
Lexicon
Range
ON, OFF
ON, OFF
0-20ms
Range
ON, OFF
ON, OFF
