Thx 5.1; Effect Parameters - Lexicon DC-1 V3 Owner's Manual

AC-3 Effects and Parameters

THX 5.1

AC-3 Effect
Parameters
48
This effect provides THX 5.1 Cinema enhancements for film soundtracks
recorded in the Dolby Digital format. This processing compensates for the
acoustical differences between large mixing theaters and the typically
smaller home environment. In this effect the side and rear speakers are
driven in parallel when you designate side speakers as STANDARD
(LARGE or SMALL) in the Speaker Configuration menu.
Parameter
AC-3 STATUS (display only — not user adjustable)
COMPRESSION
RE-EQUALIZER
SIDE LEVEL
LFE MIX LEVEL
SUBWOOFER LVL
CUSTOM
AC-3 STATUS displays the current status of incoming AC-3 data. The
displayed items are not user adjustable.
BASS ENHANCE derives stereo bass to provide low frequencies that are
noticeably less localizable and more spacious in the playback room.
Note that results will vary depending on room acoustics and the low
frequency capacity of the surround speakers. As side and/or rear speakers
are used for bass enhancement, the effectiveness is improved with speakers
capable of reproducing reproducing low frequencies (LARGE). Using
speakers that are not capable of producing low frequencies (<80Hz) may
cause damage to them.
CENTER DLY SAMPLES adjusts the time offset of the center channel. The
appropriate value is +0 unless you know that the center channel is not
properly timed, as well as the amount by which it is off.
CENTER MIX adjusts the level of the center channel applied to the two-
channel downmix. The appropriate value for film is 16. The appropriate
value for music is 11.
COMPRESSION enhances the intelligibility of Dolby Digital material at
low volume levels (-6dB or lower). When set to AUTO, this control auto-
matically limits peak signals and boosts low level signals. The amount of
compression increases proportionately as volume is decreased. This is quite
useful when listening to Dolby Digital soundtracks at low output levels.
When set to ON, full compression is applied, regardless of volume.
Initial Value
OFF OFF, ON, AUTO
ON
+00dB OFF, -80dB to +5dB
+0.0dB -10.0dB to 0.0dB
+00dB OFF, -79dB to +5dB
Lexicon
Range
ON, OFF
