Delay Tools; Frame Delay - Lexicon 960L V2.5 - ADDENDUM Owner's Manual Addendum

Version 2.5 Software Release

Delay Tools

ZONE DELAY
The Zone Delay algorithm is intended primarily for use in
live sound applications. It provides up to eight
independent channels of delay for speaker groups. These
delays can be controlled by either absolute value
(milliseconds) or distance (feet or meters). When delays
are controlled by distance, additional parameters for
temperature and humidity are available.
additional signal processing inside the algorithm. The Zone
Delay requires 8-in/8-out configuration of the DSP card.
Parameters
Temp Set to temperature of venue.
Hum Set to relative humidity of venue.
Units Controls the mode of display.
include:
English: Distances are shown in feet and temperatures
are shown in Farenheit .
Metric: Distances
temperatures are shown in Celsius .
Time: Distances are shown in absolute time.
Temperature and humidity have no effect.
Zone1 Controls the delay time for the signal passing
from Input 1 to Output 1.
Zone2, etc. Control delay times for the other signals.
6
There is no
are shown in meters

FRAME DELAY

The Frame Delay algorithm is intended for use primarily in
video post-production applications. It allows audio to be
delayed in order to maintain synchronization with video.
The Frame Delay is available in all configurations of the
machine: Stereo, Quad, 5-channel, and 8-channel.
Parameters
FrDly Indicates the number of frames that all
channels are delayed.
Type Indicates the frame format. Formats include
24, 25, 29.97, and 30 FPS.
TrimL Trims the left input by an additional delay.
Choices include 0, 1/4, 2/4, and 3/4 inch
Frame.
TrimR, etc. Trims other inputs.
Settings
and
Lexicon, Inc.
