• In a surface related echogram you will modify the range,
while for a bottom related echogram, you will change the
start range.
• If you press the left mouse button while using the mouse
wheel, the surface echogram will change its start value, while
the bottom related echogram will change its range.

Scope view

The Scope view is the rightmost view and shows a scope view
of the last ping corresponding to the settings in the Echogram
view.
This view draws a range of horizontal symmetrical colour lines.
The distance from the vertical center axis and the line colour
reflects the received echo amplitude. A black horizontal line
across the view indicates the current bottom view.
Related topics
Display views, introduction, page 12
→
Transceiver Settings, page 119
→
Advanced Transceiver, page 71
→
Bottom Detector, page 78
→
Colour Scale, page 81
→
Echogram, page 85
→
Surface Range, page 115
→
Echo Trace, page 84
→
