Preface
Use this parts catalog to identify illustrations and part numbers for
individual FRUs for the OptraImage 725.

How To Use This Parts Catalog

•
SIMILAR ASSEMBLIES: If two assemblies contain a majority of
identical parts, they are shown on the same list. Common parts
are shown by one index number. Parts peculiar to one or the other
of the assemblies are listed separately and identified by
description.
•
NS: (Not Shown) in the Asm-Index column indicates that the part
is procurable but is not pictured in the illustration.
