- Page 1 IFS Skid Plate FOR Chevy/GMC Heavy Duty Trucks 2020 – Current 57060001AA Last Updated: 4-30-2024...
-
Page 2: Included Parts
PLEASE READ BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair. ©2024 AEV... - Page 3 ©2024 AEV...
- Page 4 ©2024 AEV...
-
Page 5: Vehicle Preparation
Plate and the Exhaust Skid Plate. DRW (Dually) truck variants of the Heavy-Duty truck will not support these skid plates. Align AEV IFS Skid Plate to frame mounting points ensuring all tapped/untapped holes are in place on frame points either side of the IFS. - Page 6 Utilizing a Jack Stand, lift the AEV IFS Skid Plate to correct mounting locations. Follow these steps if installing AEV Radiator Skid Plate as well. (If not skip to part B) Loosely tighten 4 rear M10 bolts and align front mount locations as best as possible, allowing the jack stand to support the unmounted front bolts.
- Page 7 Follow these steps if not installing AEV Radiator Skid. Loosely tighten 4 rear M10 bolts. Loosely tighten 2 front M10 bolts. Front of Vehicle Rear of Vehicle Figure 3 Torque Bolts to the following FT/LBS M10 42 FT/LBS ©2024 AEV...
